0403.24/LED
U P O Z O R E N J E
0722
Upute za uporabu sadrže osnovne informacije o proizvodu.
Montaža, instaliranje, uporaba i održavanje trebaju biti
izvedeni prema ovoj Uputi kako bi bio osiguran siguran rad
unutar nazivnih karakteristika. Ovu Uputu nadopunjuju
nacionalni Pravilnici i norme. Odgovorna osoba korisnika je
dužna osigurati njihovo provođenje. Neprovođenje može
umanjiti protueksplozijsku zaštitu uređaja i dovesti u
opasnost ljude, imovinu i okoliš. Svako neispravno i
nedozvoljeno postupanje kao i nepoštivanje odredbi ove
Upute isključuje svaku odgovornost proizvođača.
Prije ugradnje/puštanja u pogon:
-Pažljivo pročitati cijelu Uputu za uporabu,
-Izvršiti odgovarajuću obuku odgovornog osoblja,
-Provjeriti da je sadržaj ove Upute u potpunosti
razumljiv odgovornim osobama,
-Uvjeriti se da su primijenjeni svi zahtjevi nacionalnih Pravilnika
i posebne sigurnosne mjere ukoliko postoje.
U slučaju nejasnoća:
-Kontaktirati proizvođača.
Tijekom pogona:
-Osigurati da ove Upute za uporabu i druge radne upute
korisnika budu vidljivo istaknute i dostupne odgovornom
osoblju cijelo vrijeme,
-Provjeravati provođenje ove Upute i svih drugih
sigurnosnih uputa korisnika.
Medarska 69, Zagreb, Croatia
Made in Croatia
Upute za uporabu
User manual
W A R N I N G
The user manual contains basic information about the
product. Mounting, installation, usage and maintenance
should be carried out under this user manual to provide and
ensure safe operation within the nominal characteristics. This
user manual complements national Regulation and Standards.
The responsible person shall ensure their implementation.
Failure off implement this user manual can reduce explosion
protection and endanger people, property and the
environment. Any improper and illegal actions as well as non-
compliance with the provisions of this user manual excludes
all responsibility by manufacturer side.
Before installation/commissioning:
-Carefully read all instructions,
-Execute proper training of responsible personnel,
-Check that the contents of these instructions is fully
understandable by the responsible personnel,
-Make sure that all the requirements and national Regulations as
well as all special security measures are applied.
In lack of understanding:
-Contact the manufacturer.
During operation:
-Ensure that this user manual and other work instructions are
available to the responsible staff at all times,
-Check the implementation of these instructions and all other
safety user's instructions.
Doc. No.: TEPEx.RS.082
Ver: 2
Date: 08. 2022.
1
