1. MANUFACTURER
TEP Ex d.o.o.
Prilaz dr. Franje Tuđmana 6 HR-49210 ZABOK
Tel:
+385 49 222 900
Web:
www.tepex.hr
2. GENERAL SAFETY INFORMATIONS
The user manual contains basic information about the product. Mounting, installation, usage and maintenance
should be carried out under this user manual to provide and ensure safe operation within the nominal
characteristics. This user manual complement national Regulation and Standards. The responsible person shall
ensure their implementation. Failure off implement this user manual can reduce explosion protection and
endanger people, property and the environment. Any improper and illegal actions as well as non-compliance with
the provisions of this user manual excludes all responsibility by manufacturer side.
Before installation/commissioning:
- Carefully read all instructions,
- Execute proper training of responsible personnel,
- Check that the contents of these instructions is fully understandable by the responsible personnel,
- Make sure that all the requirements and national Regulations as well as all special security measures are applied.
In lack of understanding:
- Contact the manufacturer.
During operation:
- Ensure that this user manual and other work instructions are available to the responsible staff at all times,
- Check the implementation of these instructions and all other safety user's instruction
USER MANUAL FOR EXPLOSION PROTECTED
PENDANT LIGHTING FITTING / LIGHT SWITCH,
Doc. No: TEPEx.RS.0
W A R N I N G !
TYPE PLFM ...-.
Ver : 0
Date: 01.2020.
1
1
2
2
2
3
4
5
5
6
7
7
7
7
Advertisement
Table of Contents
Related Manuals for Tepex PLFM 100 Series
Summary of Contents for Tepex PLFM 100 Series
-
Page 1: Table Of Contents
USER MANUAL FOR EXPLOSION PROTECTED d.o.o. PENDANT LIGHTING FITTING / LIGHT SWITCH, Medarska 69, Zagreb, Croatia TYPE PLFM …-. tel. 049 222 900, fax 049 426 450 e-mail: tepex@tepex.hr Doc. No: TEPEx.RS.0 Ver : 0 Date: 01.2020. www.tepex.hr CONTENT Manufacturer General safety information’s Purpose... -
Page 2: Purpose
II 2D Ex tb IIIC Db for diameter cable Ø7-15 mm in accordance EN 62444 Certificate: FIDI 19 ATEX 0003X - two Ex eb / tb TEPEx plugs, II 2G Ex eb IIC Gb II 2D Ex tb IIIC Db in accordance EN 62444... -
Page 3: Type
Tightening torque: - screws of Ex eb terminal 0,8 Nm - screws of Ex e cover of junction box 0,8 Nm - pressure nut of cable gland 2,5 Nm - 230V/50Hz 70/50W 1,00/0,76A λ=0,37 t =130°C ΔT=70/50K in Ballast: accordance EN 61347, Vossloh Schwabe, GmbH Light switch: - Dasy 010-2 12V AC/DC - Dasy 010-2 24V AC/DC... -
Page 4: Mounting And Installation
Table of light sources: Temp. 0 MAX class Nominal Lamp Another (dust) Model code Max. wattage Luminous flux OSRAM type PHILIPS type (gas marking voltage holder supplier =40°C T =40°C GE Lighting - 100 W 230V 1340 lm 130°C Rough Service GLS - Clear PLFM 116 W Osram... -
Page 5: Dimension
Type PLFM 70 HSE is factory wired for High pressure sodium source of 70W and connection diagram is shown in the following figure: plava 1 mm plava 1 mm plava 1 mm ž.z. 1 mm ž.z. 1 mm smeða 1 mm smeða 1 mm smeða 1 mm 230V/50Hz... -
Page 6: Spare Part And Accessories
All the repairs are performed by the manufacturer or the manufacturer's authorized personal and the original parts must be provided according to the product documentation, all in accordance with EN 60079-19. If repair or any other procedure are performed on the product by unauthorized person, all producer responsibility for the product and the warranty and the manufacturer's declaration of conformity becomes invalid. -
Page 7: 11. Responsibility And Authorization
11. RESPONSIBILITY AND AUTHORIZATION This instruction is the basic information about the product. It is completed by the corresponding national laws and regulations. Production, use, certification and supervision are determined at the national level: a) Regulations concerning equipment and protective systems intended for use in potentially explosive atmospheres EU directive ATEX 2014/34/EU b) Regulations on minimum requirements for safety and health protection of workers and technical inspection of facilities, equipment, installations and equipment in hazardous areas EU directive 1999/92/EC (ATEX 137). - Page 8 natpisnom pločicom na kućištu, tip PLFM 70 HSE-3: - marking plate with technical data on housing and inside housing:...
