- Page 1 User Guide SIB064 64 Channel PMT Interface Board Hamamatsu H8500D series Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
- Page 3 Vertilon reserves the right to change this product without prior notice. No responsibility is assumed by Vertilon for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent and proprietary information rights of Vertilon Corporation.
- Page 4 SIB064 PMT Interface Board H8500D Series - 2 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
-
Page 5: Table Of Contents
Constant Fraction Discriminator........................12 Zero Slope Discriminator ..........................14 Top and Bottom Views..........................15 Component Locations and Functions .......................16 SIB Connector Pinout ..........................18 Mechanical Information..........................19 - 3 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... - Page 6 Table 2: Connectors ..........................17 Table 3: Jumpers, Switches, and Pots..................... 17 Table 4: Test Points..........................17 Table 5: Sensor Interface Board (SIB) Connectors.................. 18 - 4 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
-
Page 7: General Safety Precautions
To avoid electric shock, fire hazard, or damage to the product, do not apply a voltage to any input outside of its specified range. Electrostatic Discharge Sensitive Electrostatic discharges may result in damage to the SIB064. For these reasons, the SIB064 board is intended to be operated in a user’s conductive instrument enclosure. Do Not Operate in Wet or Damp Conditions To avoid electric shock or damage to the product, do not operate in wet or damp conditions. -
Page 8: Product Overview
PhotoniQ on a high voltage cable to a dedicated connector on the SIB064. For applications utilizing the last dynode output of the H8500D, the SIB064 includes a two stage high speed preamplifier whose output is available on an SMB connector. When critical timing and triggering are required, this output can be connected to a separate high performance external discriminator. -
Page 9: Figure 1: Functional Block Diagram
AMP4 ANODES HAMAMATSU H8500D VERTILON SIB064 8 X 8 MULTIANODE H8500D PMT PHOTOMULTIPLIER TUBE SENSOR INTERFACE BOARD Figure 1: Functional Block Diagram - 7 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 10: Specifications
(DY12). Threshold Jitter (V : 50mV) psec set to 15mV above the baseline. Fraction set to 0.50. - 8 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 11: Table 1: Specifications
(all comparators disabled) DIMENSIONS Width Length (not including SMB connectors which extend past PCB edge) Thickness (printed circuit board only) Table 1: Specifications - 9 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 12: High Voltage Interface
SIB064 and PhotoniQ include a high voltage cable that provides up to 1400 volts of negative bias to the H8500D cathode, and a trigger cable that supplies the trigger to the PhotoniQ from one of the SIB064’s three discriminators. -
Page 13: Photomultiplier Tube Anode Circuits
Photomultiplier Tube Anode Circuits The 64 anode signals (P1 – P64) from the H8500D PMT are routed directly on the SIB064 to two specialized connectors referred to as sensor interface board (SIB) connectors. Anodes P1 to P32 route to SIB connector J1 and anodes P33 to P64 route to SIB connector J2. -
Page 14: Constant Fraction Discriminator
), the CFD can be made to trigger at any reasonable percentage of the pulse height maximum. The SIB064 ships with a standard fixed delay of 5 nsec (other delays of up to 10 nsec can be ordered separately) and seven preset fractions from 0.12 to 0.50 that are selectable using an on-board micro-rotary switch (SW2). - Page 15 User Guide LAST DYNODE PREAMP OUTPUT RESET POINT DELAY FRACTION THRESHOLD POINT AMP3 TRIGGER POINT Figure 6: Constant Fraction Discriminator Timing - 13 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
-
Page 16: Zero Slope Discriminator
SW1-3 to the “OPEN” position. LAST DYNODE PREAMP OUTPUT RESET POINT THRESHOLD POINT AMP4 TRIGGER POINT ZERO Figure 7: Zero Slope Discriminator Timing - 14 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 17: Top And Bottom Views
Sensor Interface Board Connector (J1) High Voltage Section Sensor Interface Board Connector (J2) H8500D Socket Connectors Leading Edge Discriminator Output (J5) 10. H8500D High Voltage Input - 15 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 18: Component Locations And Functions
LEAD ZERO GAIN R113 R115 R116 R114 R112 AMP3 R118 R119 R120 PREAMP ZERO LEAD AMP4 Figure 9: Component Locations and Functions - 16 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 19: Table 2: Connectors
Description Main +5V power to the SIB064 supplied by the PhotoniQ through SIB connectors J1 and J2. Anode bias and reference voltage to the SIB064 supplied by the PhotoniQ through SIB connectors J1 and J2. +MID Baseline voltage for last dynode signal processing chain. Nominally +2.5V. -
Page 20: Sib Connector Pinout
SIB Connector Pinout The SIB064 connectors and cables are fully compatible with all Vertilon PhotoniQ systems. For applications utilizing data acquisition systems other than Vertilon’s PhotoniQ series, the pinout for connectors J1 and J2 is provided in Table 5 as a reference. -
Page 21: Mechanical Information
Mechanical Information Mounting Hole 4.22 mm 4 pl. 84.00 6.00 25.00 OPEN ALL DIMENSIONS IN MILLIMETER Figure 10: FEM Printed Circuit Board Dimensions - 19 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... - Page 22 SIB064 PMT Interface Board H8500D Series Vertilon Corporation has made every attempt to ensure that the information in this document is accurate and complete. Vertilon assumes no liability for errors or for any incidental, consequential, indirect, or special damages including, without limitation, loss of use, loss or alteration of data, delays, lost profits or savings, arising from the use of this document or the product which it accompanies.
