  • Page 1 User Guide SIB2316 2 x 16 Channel SiPM Interface Board SensL SPMArray2 Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 3 Vertilon reserves the right to change this product without prior notice. No responsibility is assumed by Vertilon for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent and proprietary information rights of Vertilon Corporation.
  • Page 4 SIB2316 Sensor Interface Board SensL SPMArray2 - 4 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 5: Table Of Contents

    Zero Slope Discriminator ..........................14 Coincidence Detector ..........................15 Setup ................................16 Specifications............................18 Top and Bottom Views..........................20 Component Locations and Functions .......................21 SIB Connector Pinout ..........................23 Mechanical Information..........................24 - 5 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 6 Figure 7: Coincidence Detector Timing....................15 Figure 8: Top and Bottom Views......................20 Figure 9: Component Locations and Functions ..................21 Figure 10: SIB2316 Printed Circuit Board Dimensions ................24 List of Tables Table 1: Specifications..........................19 Table 2: Connectors ..........................22 Table 3: LEDs and Switches........................
  • Page 7: General Safety Precautions

    To avoid electric shock, fire hazard, or damage to the product, do not apply a voltage to any input outside of its specified range. Electrostatic Discharge Sensitive Electrostatic discharges may result in damage to the SIB2316. For these reasons, the SIB2316 board is intended to be operated in a user’s conductive instrument enclosure. Do Not Operate in Wet or Damp Conditions To avoid electric shock or damage to the product, do not operate in wet or damp conditions.
  • Page 8: Product Overview

    PC for display or further signal processing. The negative high voltage bias to the SPMArray2s is generated on the SIB2316 and can be trimmed for matching the two arrays. For applications such as PET imaging that require pulse timing pickoff, circuitry included within the high voltage bias generator monitors the total current delivered to the 16 elements of each SPMArray2.
  • Page 9: Figure 1: Functional Block Diagram

    VBIAS B ADJ IN15 IN16 SENSL SPMArray2 VERTILON SIB2316 16 ELEMENT DUAL SENSL SPMArray2 SILICON SENSOR INTERFACE BOARD PHOTOMULTIPLIER Figure 1: Functional Block Diagram - 9 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 10: Typical Setup

    SPMArray2s are positioned to detect incoming light from a scintillator crystal or optical assembly and connected to the SIB2316 by two FPC cables. The sensor interface board cable connects the 32 detector outputs from the SIB2316 to a Vertilon PhotoniQ IQSP480 or IQSP580 32 channel data acquisition system. The trigger output from the SIB2316 supplies the trigger to the PhotoniQ when coincident pulses exceeding a user-programmed energy threshold are detected on the SPMArray2 devices.
  • Page 11: Detector Common Anode Bias

    SIB2316 and may cause permanent damage to it or the device itself. The figure below illustrates how the detector bias is applied to a common anode SPMArray2 by the SIB2316. Since the SIB2316 supports up to two SPMArray2s, the board contains two instances of the circuitry shown in the figure. An FPC cable for each SPMArray2 carries the 16 cathode signals and common anode signal to the SIB2316.
  • Page 12: Spmarray2 Cathode Connections

    Regardless of the connectors used, the 16 cathode signals (IN01 – IN16) from each SPMArray2 are routed on the SIB2316 to SIB connector J3 as shown in Figure 4. The cathode signals from device A are AC coupled and map to inputs P1 through P16 on the connector, and likewise cathode signals from device B are AC coupled and map to inputs P17 through P32.
  • Page 13: Figure 5: Sib2316 Dialog Box

    User Guide Figure 5: SIB2316 Dialog Box - 13 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 14: Zero Slope Discriminator

    ) so that only events exceeding the threshold result in a signal on ZSD — all other events are ignored. The energy threshold adjustment to the SIB2316 is provided through the SIB cable so that the user can vary the threshold using the SIB2316 dialog box in the PhotoniQ graphical user interface.
  • Page 15: Coincidence Detector

    SPMArray2. This is done by setting Trigger Type in the dialog box to Level. - 15 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010...
  • Page 16: Setup

    SPMArray2 Connection Turn off the bias to the SIB2316. Connect an SPMArray2 to channel A of the unit using an FPC cable. Connection to the SIB2316 can be made using either the top side (J1) or bottom side (J9) FPC connector. Reapply the bias and reconfirm that the bias voltage to the detector is correct.
  • Page 17 User Guide Coincidence Triggering Connect a second SPMArray2 to the channel B FPC connector on the SIB2316. The channel B coincidence LED, LD4 will blink red if particles exceeding the energy threshold are detected. Set the coincidence window to the desired time.
  • Page 18: Specifications

    3dB Bandwidth (Bandwidth = Med Low) 3dB Bandwidth (Bandwidth = Low) 0.71 Trigger Threshold Range Relative to maximum pulse height in discriminator chain - 18 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 19: Table 1: Specifications

    DIMENSIONS Width 84.0 Length 102.0 (not including SMB connectors which extend past PCB edge) Thickness (printed circuit board only) Table 1: Specifications - 19 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 20: Top And Bottom Views

    13. SPM Array B Coincidence Detector LED 14. Preamp B Output (J8) 15. SPMArray2 B Bottom Side FPC Connector (J10) 16. SPMArray2 A Bottom Side FPC Connector (J9) - 20 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 21: Component Locations And Functions

    Component Locations and Functions C107 C111 C106 C110 C108 C112 C100 C101 C113 C114 C104 C115 C103 Figure 9: Component Locations and Functions - 21 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 22: Table 2: Connectors

    HVMON Reserved for indirectly monitoring detector bias through the SIB cable. Main +5V power to the SIB2316 supplied by the PhotoniQ through SIB connector J3. Bias voltage on detector cathode coupling capacitor. Supplied through SIB connector J3, nominally +0.250V. +VTH Energy threshold voltage to discriminators A and B.
  • Page 23: Sib Connector Pinout

    SIB Connector Pinout The SIB2316 connectors and cables are fully compatible with all Vertilon PhotoniQ systems. For applications utilizing data acquisition systems other than Vertilon’s PhotoniQ series, the pinout for connector J3 is provided in Table 5 as a reference.
  • Page 24: Mechanical Information

    84.00 6.00 33.50 6.00 19.90 102.00 19.00 19.90 26.40 10.00 9.70 ALL DIMENSIONS IN MILLIMETER Figure 10: SIB2316 Printed Circuit Board Dimensions - 24 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
  • Page 25 User Guide Vertilon Corporation has made every attempt to ensure that the information in this document is accurate and complete. Vertilon assumes no liability for errors or for any incidental, consequential, indirect, or special damages including, without limitation, loss of use, loss or alteration of data, delays, lost profits or savings, arising from the use of this document or the product which it accompanies.
