- Page 1 User Guide SIB164B 64 Channel PMT Interface Board Hamamatsu H7546B / H12428 Series Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
- Page 2 Vertilon reserves the right to change this product without prior notice. No responsibility is assumed by Vertilon for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent and proprietary information rights of Vertilon Corporation.
- Page 3 User Guide - 3 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com...
-
Page 4: Table Of Contents
SIB164B PMT Sensor Interface Board for Hamamatsu H7546B / H12428 Series Table of Contents General Safety Precautions ........................6 Product Overview ............................. 7 Specifications ............................9 Typical Setup ............................11 High Voltage Interface ..........................11 Photomultiplier Tube Anode Circuits ....................12 Last Dynode Preamplifier ........................ - Page 5 Figure 7: Zero Slope Discriminator Timing ....................15 Figure 8: Top and Bottom Views ......................16 Figure 9: Component Locations and Functions ..................17 Figure 10: SIB164B Printed Circuit Board Dimensions ................20 List of Tables Table 1: Specifications ..........................10 Table 2: Connectors ..........................
-
Page 6: General Safety Precautions
To avoid electric shock, fire hazard, or damage to the product, do not apply a voltage to any input outside of its specified range. Electrostatic Discharge Sensitive Electrostatic discharges may result in damage to the SIB164B. For these reasons, the SIB164B board is intended to be operated in a user’s conductive instrument enclosure. Do Not Operate in Wet or Damp Conditions To avoid electric shock or damage to the product, do not operate in wet or damp conditions. -
Page 7: Product Overview
PMT’s cathode is supplied directly from the PhotoniQ on a high voltage cable to a dedicated connector on the SIB164B. For applications utilizing the last dynode output of the PMT, the SIB164B includes a two stage high speed preamplifier whose output is available on an SMB connector. -
Page 8: Figure 1: Functional Block Diagram
SIB164B PMT Sensor Interface Board for Hamamatsu H7546B / H12428 Series INPUT HIGH VOLTAGE INTERFACE HVMON PREAMP GAIN AMP2 AMP3 DY10 DY11 DISCRIMINATOR THRESHOLD DY12 SELECT GAIN C in R in TRIG AMP1 COMP PULSE GAIN WIDTH AMP4 ANODES HAMAMATSU... -
Page 9: Specifications
(DY12). Gain set to Jitter (V : 80mV) nsec high, pulse width set to medium wide, threshold set to 10%. - 9 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 10: Table 1: Specifications
SIB164B PMT Sensor Interface Board for Hamamatsu H7546B / H12428 Series Description Units Notes TRIGGER OUTPUT Output Impedance Logic High Output Level +4.3 +4.8 = -32mA) Logic Low Output Level +0.2 +0.6 = 32mA) POWER Supply Voltage +4.9 +5.0 +5.1... -
Page 11: Typical Setup
SIB164B and PhotoniQ include a high voltage cable that provides up to 1000 volts of negative bias to the H12428 cathode, and a trigger cable that supplies the trigger to the PhotoniQ from one of the SIB164B’s two discriminators. In an alternative configuration when precision timing or coincidence detection is required, an external discriminator with coincidence logic can be placed between the SIB164B preamplifier output and the PhotoniQ trigger input. -
Page 12: Photomultiplier Tube Anode Circuits
Photomultiplier Tube Anode Circuits The 64 anode signals (P1 – P64) from the PMT are routed directly on the SIB164B to two specialized connectors referred to as sensor interface board (SIB) connectors. Anodes P1 to P32 route to SIB connector J1 and anodes P33 to P64 route to SIB connector J2. -
Page 13: Figure 5: Sib164B Dialog Box
User Guide Figure 5: SIB164B Dialog Box - 13 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 14: Leading Edge Discriminator
Referring to Figure 6, negative going pulses from the preamplifier are compared to the discriminator threshold that is set through the SIB164B dialog box in the PhotoniQ GUI. A logic high (for positive polarity control) is generated on the trigger output (SMB connector J5) after a small delay (t from when the pulse first crosses the threshold, V . -
Page 15: Zero Slope Discriminator
) to arm the discriminator after which the trigger output fires when the AMP4 signal again crosses the baseline. LAST DYNODE PREAMP OUTPUT AMP4 BASELINE LEVEL THRESHOLD TRIGGER POINT POINT TRIG OUT Figure 7: Zero Slope Discriminator Timing - 15 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 16: Top And Bottom Views
SIB164B PMT Sensor Interface Board for Hamamatsu H7546B / H12428 Series Top and Bottom Views Figure 8: Top and Bottom Views High Voltage Input (J3) Trigger Output (J5) Preamp Output (J6) External Input (J7) Sensor Interface Board Connector (J1) High Voltage Section... -
Page 17: Component Locations And Functions
User Guide Component Locations and Functions 2 3 4 Figure 9: Component Locations and Functions - 17 - Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070 Fax: (978) 692-7010 www.vertilon.com... -
Page 18: Table 2: Connectors
HVMON Attenuated version of –HV used for indirectly monitoring PMT cathode bias. Anode bias and reference voltage to the SIB164B supplied by the PhotoniQ through SIB connectors J1 and J2. +MID Baseline voltage for last dynode signal processing chain. Nominally +2.0V. -
Page 19: Sib Connector Pinout
SIB Connector Pinout The SIB164B connectors and cables are fully compatible with all Vertilon PhotoniQ systems. For applications utilizing data acquisition systems other than Vertilon’s PhotoniQ series, the pinout for connectors J1 and J2 is provided in Table 5 as a reference. -
Page 20: Mechanical Information
SIB164B PMT Sensor Interface Board for Hamamatsu H7546B / H12428 Series Mechanical Information Mounting Hole 4.22 mm 4 pl. 84.00 25.00 6.00 6.00 32.00 2 3 4 102.00 44.00 19.00 15.00 ALL DIMENSIONS IN MILLIMETER Figure 10: SIB164B Printed Circuit Board Dimensions... - Page 21 Vertilon reserves the right to change this product without prior notice. No responsibility is assumed by Vertilon for any infringements of patents or other rights of third parties which may result from its use.
