Block Climber
Age Group:
2-12 Years
Recommended Crew:
Minimum 1-2 People
Tools Required for Assembly:
T-30 TORX Bit
3/16" x 6" Drill Bit
Post Hole Digger / Shovel / Auger
Tape Measure
Level
High Speed 3/8" electric drill w/ clutch
Installation Time:
15 minutes – 30 minutes
Concrete Required:
1.1781 cu ft. per post
Note: Concrete must have a minimum rating of 2,500 psi and must be mixed per
manufacturers recommendation.
DATE: 4/23/2014
This space intentionally left blank.
Installation Guideline
BLOCK CLIMBER INSTALLATION GUIDELINES
Page 1
Advertisement
Related Manuals for Terra Bound Solutions Playtopia Block
Summary of Contents for Terra Bound Solutions Playtopia Block
- Page 1 Block Climber Installation Guideline Age Group: 2-12 Years Recommended Crew: Minimum 1-2 People Tools Required for Assembly: T-30 TORX Bit 3/16” x 6” Drill Bit Post Hole Digger / Shovel / Auger Tape Measure Level High Speed 3/8” electric drill w/ clutch Installation Time: 15 minutes –...
-
Page 2: Standard Hardware
Block Climber Installation Guideline Standard Hardware 5/16” x 5” RSS 1/4” x 2-1/2” #10 x 2-1/2” 5/16” x 4” RSS 5/16” x 3-1/8” 5/16” x 2-1/2” Stainless RSS Stainless R4 Stainless Stainless RSS Stainless RSS Stainless NOT TO SCALE! DATE: 4/23/2014 BLOCK CLIMBER INSTALLATION GUIDELINES Page 2... - Page 3 Block Climber Installation Guideline Standard Block Climbers Block Climber shown is for 48” platform height. Side view of Block Climber DATE: 4/23/2014 BLOCK CLIMBER INSTALLATION GUIDELINES Page 3...
- Page 4 Block Climber Installation Guideline Pre-Installation Check Check off all items received, against the packing list. Notify your local sales representative immediately of any items that are missing or that may be damaged. Before beginning your playground installation, make sure that you have reviewed “Playtopia’s Installation Guideline Manual”...
- Page 5 Block Climber Installation Guideline Block Climber Assembly The Playtopia Block Climber is made so that top outer lip of the climber (A) meets flush against the bottom lip of the deck platform (B). Post removed to show Block Climber location.
- Page 6 Block Climber Installation Guideline Block Climber Assembly Contd. When the Block Climber is ready to be fastened pre-drill through the 2 mounting holes located on the underside of the climber as shown with a 3/16” bit. Fasten 5/16”x 3-1/8” RSS SS Screws - through each side - and into the post until the block climber is secured in place.
- Page 7 Block Climber Installation Guideline Block Climber Assembly Contd. Once your block climber is fastened to the posts locate the block climber support legs (A) and ready them for assembly to the inside of the block climber frame. Place one support leg inside the block climber frame and fasten (2) 5/16”...
- Page 8 Block Climber Installation Guideline Block Climber Footer Safety Surfacing Concrete Footer For standard post footer requirements see page 11. DATE: 4/23/2014 BLOCK CLIMBER INSTALLATION GUIDELINES Page 8...
- Page 9 Block Climber Installation Guideline Block Climber Footer 24” Block Climber 32” Block Climber 40” Block Climber 48” Block Climber DATE: 4/23/2014 BLOCK CLIMBER INSTALLATION GUIDELINES Page 9...
- Page 10 Block Climber Installation Guideline 56” Block Climber 64” Block Climber 72” Block Climber DATE: 4/23/2014 BLOCK CLIMBER INSTALLATION GUIDELINES Page 10...
