A-Frame Roofs
Age Group:
2-12 Years
Recommended Crew:
Minimum 2-4 People
Tools Required for Assembly:
T-30 TORX Bit
3/16" x 6" Drill Bit
Tape Measure
Level
High Speed 3/8" electric drill w/ clutch
Installation Time:
15 minutes – 30 minutes
DATE: 4/23/2014
This space intentionally left blank.
Installation Guideline
A-FRAME ROOFS INSTALLATION GUIDELINES
Page 1
Advertisement
Table of Contents
Related Manuals for Terra Bound Solutions Standard A-Frame
Summary of Contents for Terra Bound Solutions Standard A-Frame
- Page 1 A-Frame Roofs Installation Guideline Age Group: 2-12 Years Recommended Crew: Minimum 2-4 People Tools Required for Assembly: T-30 TORX Bit 3/16” x 6” Drill Bit Tape Measure Level High Speed 3/8” electric drill w/ clutch Installation Time: 15 minutes – 30 minutes This space intentionally left blank.
- Page 2 A-Frame Roofs Installation Guideline Standard Hardware 5/16” x 5” RSS 1/4” x 2-1/2” #10 x 2-1/2” 5/16” x 4” RSS 5/16” x 3-1/8” 5/16” x 2-1/2” Stainless RSS Stainless R4 Stainless Stainless RSS Stainless RSS Stainless NOT TO SCALE! DATE: 4/23/2014 A-FRAME ROOFS INSTALLATION GUIDELINES Page 2...
- Page 3 A-Frame Roofs Installation Guideline Standard A-Frame Roofs Standard A-Frame Roof Mushroom A-Frame Roof Parlor A-Frame Roof Ramshackle A-Frame Roof This space intentionally left blank. DATE: 4/23/2014 A-FRAME ROOFS INSTALLATION GUIDELINES Page 3...
- Page 4 A-Frame Roofs Installation Guideline Pre-Installation Check Check off all items received, against the packing list. Notify your local sales representative immediately of any items that are missing or that may be damaged. Before beginning your playground installation, make sure that you have reviewed “Playtopia’s Installation Guideline Manual”...
- Page 5 A-Frame Roofs Installation Guideline A-Frame Roof Assembly Min. of 60” Height When installing any roof whether A-Frame or Rotomolded roof, the roof must be installed so that the platform of the deck (A) needs to be a minimum of 60” from the lowest point of the roof top (B). DATE: 4/23/2014 A-FRAME ROOFS INSTALLATION GUIDELINES Page 5...
- Page 6 A-Frame Roofs Installation Guideline A-Frame Roof Assembly Contd. The A-Frame roof is made so that the outside face of the When the roof is lowered onto the posts. The tops of the posts (A) posts (A) mount flush with the inside face of the A-Frame will rest on the underside (B) of the A-Frame roof and support the framing (B).
- Page 7 A-Frame Roofs Installation Guideline A-Frame Roof Assembly Contd. When the A-Frame roof is ready to be fastened, pre-drill through each pilot hole with a 3/16” bit located at each corner and then fasten 5/16”x 3-1/8” RSS SS Screws , at each corner, through the pilot holes and into the post. This space intentionally left blank.
- Page 8 A-Frame Roofs Installation Guideline Double A-Frame Roof Assembly The Double A-Frame roof is fastened in the exact same manner as the single A-Frame, however the hardware quantities are different. When the Double A-Frame roof is ready to be fastened, pre-drill through each pilot hole with a 3/16” bit located at each (12) corner and at the center of the A-Frame side frame, then fasten 5/16”x 3-1/8”...
