Kennel Club Playground
Recommended Crew:
Minimum 1-2 People
Tools Required for Assembly:
T-30 TORX Bit
3/16" x 6" Drill Bit
Post Hole Digger / Shovel / Auger
Tape Measure
Level
High Speed 3/8" electric drill w/ clutch
Installation Time:
6 to 8 hours
Concrete Required:
1.8 cu ft. per post
Note: Concrete must have a minimum rating of 2,500 psi and must be mixed per
manufacturers recommendation.
REVISED DATE: 5/5/2016
20020 Hickory Twig Way
Phone: 281-288-6693
contact@terraboundsolutions.com
Email:
Web: www.terraboundsolutions.com
This space intentionally left blank.
Installation Guideline
●
Spring, Texas 77388
●
Fax: 281-288-2870
KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE
Page 1
Advertisement
Related Manuals for Terra Bound Solutions Kennel Club Playground
Summary of Contents for Terra Bound Solutions Kennel Club Playground
- Page 1 6 to 8 hours Concrete Required: 1.8 cu ft. per post Note: Concrete must have a minimum rating of 2,500 psi and must be mixed per manufacturers recommendation. This space intentionally left blank. REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 1...
-
Page 2: Standard Hardware
5/16” x 5” 1/4” x 2-1/2” #10 x 2-1/2” 5/16” x 4” 5/16” x 3-1/8” 5/16” x 2-1/2” Stainless Stainless Stainless Stainless RSS Stainless RSS Stainless N OT T O SCALE! REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 2... - Page 3 HARDWARE IS TO BE FASTENED REQUIRES PRE- DRILLING TO ENSURE PROPER INSTALLATION AND STRUCTURAL INTEGRITY. WE ARE NOT RESPONSIBLE FOR INSTALLATION OR STRUCTURAL ISSUES THAT ARISE FROM NOT PRE-DRILLING ATTACHMENTS. This space intentionally left blank. REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 3...
- Page 4 Dog A-Frame Roof (x1) 10’ Posts (x4) Dog Crawl (x1) Square Deck (x2) Barrier Panel (x4) Dog Ramp (x2) Dog Leap Bar (x2) Dog House Crawl (x4) 6’ Posts (x4) REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 4...
- Page 5 The footer holes should be 12” in diameter by 18” deep. It is highly recommended the concrete not be set until the completion of the Kennel Club assembly. REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 5...
- Page 6 Once your posts are in dry fitted and placed in the footer holes, begin to install the Kennel Club deck platforms as shown below. The deck heights should be installed so that the tops of the deck surface should be 40” from the ground surface. 40” High REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 6...
- Page 7 Supporting the deck from underneath, fasten the platform using (8) 5/16”x3-1/8” RSS screws (2 per corner) through the 2x3 deck frame and into the 4x4 post. Repeat the previous steps on the remaining deck platform. 5/16” x 3-1/8” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 7...
- Page 8 4x4 posts (A). The tops of the panels rest directly up against the underside of the deck platform frame (B). REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 8...
- Page 9 With the panels in place fasten (6) 2-1/2” RSS Screws (3 per side) through the Dog House Crawl panel and into the 4x4 posts. Repeat the previous steps on the remaining 3 Dog House Crawl Panels until all are fastened in place. 5/16” x 2-1/2” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 9...
- Page 10 (C) should align flush with the outside of the 4x4 posts. Once in place fasten (4) 5/16” x 2-1/2” RSS Screws (2 per side) through the barrier panel and into the post. 5/16” x 2-1/2” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 10...
- Page 11 Pre-drill through the panel plastic (D) and into the post then proceed to fasten one 5/16” x4” RSS screw per corner, through the panel and into the post as shown below. 5/16” x 4” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 11...
- Page 12 4x4 posts align with the tops of the A-Frame roof side support (F). Ensure that it is level and plumb before proceeding to fasten in place. REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 12...
- Page 13 With the roof in place proceed to fasten (4) 5/16” x 3-1/8” RSS Screws (1 per side) through the pre-drilled holes shown below and into the 4x4 posts. 5/16” x 3-1/8” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 13...
- Page 14 The measurement below is a guide only and can be adjusted as necessary. The placement of the leap bars should be centered on to the 4x4 post. 8-16” Height REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 14...
- Page 15 Once leveled and at the preferred height, fasten the Leap Bars to the 4x4 posts using (4) 5/16” x 3-1/8” RSS Screw (2 per side) through the leap bar collar and into the 4x4 post. 5/16” x 3-1/8” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 15...
- Page 16 (G) are flushed to the outside face of the 4x4’s. The top of the mounting board (H) should be positioned flush with the top of the deck platform surface. REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 16...
- Page 17 With the ramp in the proper position and height fasten (4) 5/16” x 3-1/8” RSS screws (2 per side) through the mounting board and into the 4x4 posts. Repeat this step for the remaining ramp. 5/16” x 3-1/8” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 17...
- Page 18 Fasten (4) 5/16” x 3-1/8” RSS screws (1 per leg) through the outside of the frame and into the 2x3 leg support. Repeat the same steps on the remaining ramp. 5/16” x 3-1/8” RSS Screw REVISED DATE: 5/5/2016 KENNEL CLUB PLAYGROUND INSTALLATION GUIDELINE Page 18...
