Installation, Operating and Servicing
Instructions
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
________________________________
_______
A34/103 R2
WASTESTATION COMPACT
THREE PHASE MODEL (415V-50HZ) F79/703
ECN 4839 MAY 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IMC F79/703
Summary of Contents for IMC F79/703
- Page 1 WASTESTATION COMPACT THREE PHASE MODEL (415V-50HZ) F79/703 Installation, Operating and Servicing Instructions Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ ________________________________ _______ A34/103 R2 ECN 4839 MAY 2021...
-
Page 2: Table Of Contents
MAINTENANCE ....................15 USAGE ........................ 16 CIRCUIT DIAGRAM: WASTESTATION COMPACT 415V-3 PHASE-50Hz ..17 PARTS LIST – MACERATOR ................18 PARTS LIST F79/703 WasteStation Compact ............ 19 SPARES ......................19 FAULT DIAGNOSIS .................... 20 ORDERING SPARE PARTS ................21 FURTHER INFORMATION ................. 21... -
Page 3: Machine Dimensions
MACHINE DIMENSIONS 150 MAX SERVICES BURR SIDE DOWN UNLESS OTHERWISE STATED TOLERANCE ± REVISION No OVERALL DIM TITLE ANGULAR TOLERANCE ± 1° ©2021 LINCAT LTD F79/240 WAS MENSIONS IN mm S OTHERWISE WHISBY ROAD, LINCOLN, LN6 3QZ 12/02/21 F79/24 DATE X dimension Y dimension Saved as \\master1\Solid Edge\Product Assembl... - Page 4 View on Rear of Machine Showing Connections for Services HOT WATER COLD WATER CONNECTION CONNECTION SERIAL No. LABEL WASTE ELECTRICAL OUTLET SUPPLY CONDUIT CONTROL BOX DIMENSIONS P a g e...
-
Page 5: Introduction
This machine is to be operated by trained personnel only. MODEL INFORMATION There is currently one 3 Phase version: - F79/703 with motor (size combined) 4.1kW Please read these instructions carefully for trouble-free installation and operation. Please observe these instructions carefully. -
Page 6: Installation Options
FOR THE INSTALLER These Instructions contain important information designed to help the user obtain the maximum benefit from the investment in an IMC WasteStation Compact. Please read them carefully before starting work, and consult with the supplier in the event of any queries. -
Page 7: Order Of Connection For All Installation Options
ORDER OF CONNECTION FOR ALL INSTALLATION OPTIONS Install in the following sequence: Adjust height and level to leave a gap of 100mm between the floor and underside of machine chassis. Reconnect the locknut to the large cable gland on the rear panel, remove side panel for access. -
Page 8: Waste Outlet Connection
Copper pipe and compression fittings should be used, but plastic tubing is acceptable to most drainage authorities. IMC WasteStations must have an independent waste pipe, which does not also serve sinks, dishwashers and similar equipment. It is imperative that the waste pipe from the... -
Page 9: Electrical Connection
ELECTRICAL CONNECTION All electrical work must be carried out by a qualified electrician and in accordance with the IET Codes of Practice. Examine the rating plate located on the rear panel (next to the mains inlet) to ensure that the characteristics shown are correct for the supply available. The supply cable fitted is the minimum required for connection to the mains supply. -
Page 10: Machine Ratings
The supply to the machine must also be protected by a 30mA RCD (type A, curve B) such as IMC part number G76/043, which may be purchased separately from the Lincat Spares Department (contact details shown on final page of this document) WARNING: This machine must be earthed WARNING: This machine must not be PAT tested under any circumstances. -
Page 11: Operation Of Machine
OPERATION OF MACHINE During the operation of the machine certain indicator lights will be illuminated on the front control box these give an indication of what operation the machine is carrying out. MACHINE RUNNING MODES & INDICATOR LIGHTS When the machine is running the button lights on the front of the machine will be constantly lit or flash, the meaning of this is explained below. -
Page 12: Initial Operation
By the time the knob is fully unscrewed and the safety baffle open, the rotor in the grinding chamber will have completely stopped. When these checks, tests and adjustments are completed, the IMC WasteStation Compact is ready for use. -
Page 14: Normal Operation
Food Waste Disposers can jam under overload or if unsuitable materials are placed inside. IMC machines are designed to withstand this and no damage will normally result, as the machine will switch itself off. It is necessary to clear the jam as follows: Switch off at the mains isolating switch. -
Page 15: Note
Daily: Clean down thoroughly after use especially inside the hopper. Unscrew the safety interlock knob and open the baffle to gain access internally Cleaning is assisted by the use of a low-pressure spray, an IMC Pre-Rinse Spray or a Reel-Kleen retractable hose reel. -
Page 16: Usage
ELECTRICITY SUPPLY AND WATER SUPPLY ARE TURNED OFF AT THE MAIN SUPPLY AND WATER STOPCOCK. USAGE 1 THE IMC WASTESTATION COMPACT IS DESIGNED FOR THE DISPOSAL AND DEWATERING OF FOOD WASTE. DO NOT PUT CLING FILM, LIQUID FAT, STRING, CLOTH, PLASTIC, WIRE, GLASS, CORK, STYROFOAM, BOILING WATER, HOT SOUP, HOT LIQUID, BONES OR METAL OBJECTS INTO THE MACHINE. -
Page 17: Circuit Diagram: Wastestation Compact 415V-3 Phase-50Hz
CIRCUIT DIAGRAM: WASTESTATION COMPACT 415V-3 PHASE-50HZ... -
Page 18: Parts List - Macerator
PARTS LIST – MACERATOR 18 | P a g e... -
Page 19: Parts List F79/703 Wastestation Compact
PARTS LIST F79/7030 WASTESTATION COMPACT PART No. DESCRIPTION S79/043 Hopper Interlock Switch Assembly S79/273 Baffle Assembly Full A21/052 Single Aerocatch Emergency Stop ‘Switch Only’ G45/121 J03/165 Solenoid Valve (X1) S78/106 Dewaterer Complete Assembly 3PH S60/002 Macerator Assembly 3PH A19/034 Adjustable Foot A09/034 Pump Full Assembly 879269... -
Page 20: Fault Diagnosis
FAULT DIAGNOSIS Machine does not start Cause Action Electrical supply is not turned on. Switch on supply. The mains isolator is switched off or RCD has Call site electrician to switch on the isolator or tripped reset the RCD. If problem persists contact service personnel Waste bin is full (flashing red light) Empty and then replace the bin... -
Page 21: Ordering Spare Parts
For installations outside the UK please contact your supplier. For information on IMC spares and service support (if applicable), please call Lincat on +44 (0) 1522 875520. Alternatively, contact us via email: Lincat Spares Desk E-mail: spares@Lincat.co.uk...
