Lionel No. 256
O-Gauge
Electric Locomotive
OPERATOR'S MANUAL (CONTEMPORARY)
Compatibility
This engine will negotiate O-31 diameter
curves, including M.T.H.'sRealTrax,
ScaleTrax or traditional tubular track.
It is also compatible with most
standard AC transformers.
(See page 17 for a complete list of
compatible transformers and wiring
instructions.)
Passenger Station Announcement
PLEASE READ BEFORE USE AND SAVE
Advertisement
Table of Contents
Related Manuals for MTHTrains Lionel Trains 256
Summary of Contents for MTHTrains Lionel Trains 256
- Page 1 ® by M.T.H. Electric Trains Lionel No. 256 O-Gauge Electric Locomotive OPERATOR’S MANUAL (CONTEMPORARY) Compatibility This engine will negotiate O-31 diameter curves, including M.T.H.'sRealTrax, ScaleTrax or traditional tubular track. It is also compatible with most standard AC transformers. (See page 17 for a complete list of compatible transformers and wiring instructions.) Passenger Station Announcement...
-
Page 2: Table Of Contents
Table of Contents Set Up Checklist......................Lubrication....................... Checking the Battery..................Coupler......................Basic Operation......................Activating Features................... Proto-Sound 3.0 Operating Instructions..............Activating Proto-Sound 3.0 Conventional Mode Features......Freight Yard Sounds (FYS)................Speed Control....................Locking Locomotive Into A Direction............Reset To Factory Default................. Automatic Sound Effects................. -
Page 3: Set Up Checklist
Set Up Checklist - Lubricate the locomotive - Apply power to run as described in the Basic Operating Section of this manual. Lubrication You should lubricate the engine to prevent it from squeaking. Use light household oil and follow the lubrication points marked “L” in DO NOT DO NOT Fig. -
Page 4: Coupler
second charging wait time ONLY applies to conventional AC track power. Once the headlight shuts off, the engine will play its start-up sounds and all the lights will come back on, simultaneously. Smoke too if you have it turned on. The capacitors hold enough charge to play the full shut-down sounds. - Page 5 Direction - Your train is programmed to start in neutral. The train will always cycle neutral-forward-neutral-reverse with each press and release of the direction button. The engine is programmed to restart in neutral each time the track voltage is turned off for 25 seconds or more. Cycle Phases Neutral Reverse...
-
Page 6: Proto-Sound 3.0 Operating Instructions
Proto-Sound 3.0 Operating Instructions This manual contains the operating instructions for Proto-Sound 3.0 in conventional mode only. Instructions for accessing DCS command mode features accompany the DCS Remote Control System equipment. Activating Proto-Sound 3.0 Conventional Mode Features Proto-Sound 3.0 features are activated by sequences of Bell and Horn button pushes described below. -
Page 7: Freight Yard Sounds (Fys)
Freight Yard Sounds (FYS) or Passenger Station Announcements (PSA): Your engine is equipped with a sound package of either freight yard or passenger station sounds that you can play. Each sequence described below will play as long as it is left on, randomly generating sounds, but be sure to allow approximately 30 seconds between the button pushes described below to allow the FYS/PSA sufficient time to run through each sequence. -
Page 8: Speed Control
Speed Control M.T.H. engines equipped with Proto-Sound 3.0 have speed control capabilities that allow the engine to maintain a constant speed up and down grades and around curves, much like an automobile cruise control. You can add or drop cars on the run, and the engine will maintain the speed you set. -
Page 9: Locking Locomotive Into A Direction
Locking Locomotive Into a Direction You can lock your engine into a direction (forward, neutral, or reverse) so that it will not change directions. To do this, put the engine into the direction you want (or into neutral to lock it into neutral), run it at a very slow crawl (as slowly as it will move without halting), and quickly but firmly tap the Horn button once followed by three quick taps of the Bell button, allowing approximately ½... -
Page 10: Maintenance
Maintenance Lubricating and Greasing Instructions The engine should be well oiled and greased in order to run properly. Regularly lubricate all axles and pickup rollers to prevent squeaking. DO NOT DO NOT Use light household oil, such as that found in M.T.H.'s maintenance OVER OIL OVER OIL kit. -
Page 11: Cleaning The Wheels, Tires And Track
The headlight is easy to remove and replace when it burns out. The bulb(s) simply unscrew from their sockets. Replacement LED bulbs are available directly from the M.T.H. Parts Department. (Order online: www.mthtrains.com, e-mail: parts@mthrailking.com,Fax: 410-423-0009, Phone 410-381-2500, Mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532). - Page 12 Traction Tire Replacement Instructions Your locomotive is equipped with two neoprene rubber traction tires. While these tires are extremely durable, they may occasionally need replacement. To install the new traction tires: 1. Make sure the old tire has been completely removed from the groove in the drive wheel, using a razor blade or small flathead screwdriver to pry away any remains.
-
Page 13: Troubleshooting Proto-Sound® 3.0 Problems
Troubleshooting Proto-Sound® 3.0 Problems Although Proto-Sound® 3.0 has been designed and engineered for ease of use, you may have some questions during initial operation. The following table should answer most questions. If your problem cannot be resolved with this table, contact M.T.H. for assistance (telephone: 410-381-2580;... - Page 14 Lock-out Solution The engine maybe locked into the neutral I can't get the engine to run after I power position. Follow the procedure in the "Lock up the transformer. It sits still with the into a Direction" section to unlock the diesel and compressor sounds running.
- Page 15 Start-up Solution This is normal. You have to hit the Start-Up When I apply power to the track my button. engine doesn't do anything. No lights, no sound, no nothing. Check to see if that section of track has power. Use a voltmeter or a lit passenger car, not your tongue.
- Page 16 Lights Solution One of my lights is out. Check that you haven't turned it off with the DCS controller. You have independent control over lights on your engine Could be the same reason as “One of my None of my lights are on. lights is out”...
-
Page 17: Transformer Compatibility And Wiring Chart
Transformer Compatibility and Wiring Chart Proto-Sound 3.0 is designed to work with most standard AC transformers. The chart below lists the many compatible transformers. Note that many of the operational commands described in these instructions require a bell button, so if your transformer does not have its own bell button, you should consider adding one to get the full benefit of the system. -
Page 18: Additional Features Accessible With The Dcs Remote Control System
Additional Features Accessible With The DCS Remote Control System (Additional equipment required) While conventional mode operation of a Proto-Sound® 3.0 engine yields wonderfully realistic sound and several train control features, command mode operation allows the user to access a world of command functions never before accessible to O Gauge railroaders. -
Page 19: Service & Warranty Information
M.T.H. Electric Trains. The manufacture date of an item can be verified on the item's detail page “shipping date field” on the M.T.H. website (www.mthtrains.com). This warranty does not cover damages caused by improper care, handling, or use. Transportation costs incurred by the customer are not covered under this warranty.
