- Page 1 G-CONNECT IRREGULAR DESK TO CREDENZA TOP ASSEMBLY INSTRUCTIONS Questions? Call Toll Free 1-844-2GEBESA or email warranty@gebesa.com...
- Page 2 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP TOOLS Wood screw Leveler Hand bolt Hand bolt 8 x 1” 1” x 1/4” 1/2” x 1/4” 1 1/2” x 1/4” Front duct Worksurface stiffener Structural stiffener Lateral duct Plastic screw REQUIRED ASSEMBLY TOOLS...
- Page 3 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP PARTS “O” leg Worksurface...
- Page 4 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Adjust until completely balanced REQUIRED ASSEMBLY TOOLS NOT INCLUDED...
- Page 5 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Use pressure to attach the structural stiffener (C) using the plastic screw (K) on the flange of the “O” leg (A).
- Page 6 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Insert the front duct (B) in the leg’s slots (A).
- Page 7 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Insert the lateral duct (E) over the previously assambled structure and repeat steps 2 and 3.
- Page 8 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Attach the stiffener (F) to the worksurface (D) using the 8 x 1” wood screws (J).
- Page 9 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Attach the worksurface (D) to the structure (BC) using the hand bolts (H) holding it from the sliding mechanism (E) attached to the “O” leg (A).
- Page 10 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP STEPS Add the hand bolt (I) to the structure (C) to avoid the worksurface (D) sliding. In order for the worksurface to slide, loose the hand bolt.
- Page 11 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP FINAL VIEW Front view...
- Page 12 G-CONNECT | IRREGULAR DESK TO CREDENZA TOP FINAL VIEW Side view Bottom view...
