HP Compaq 6005 Pro Product End-Of-Life Disassembly Instructions page 2

Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
1.3 Markings for plastic parts greater than 25 grams
Plastic Part Name
Main Bezel
Fan Duct
Fan Holder
System Fan
Frame_ADDA
System Fan
Frame_DELTA
Chassis Stand
DC Fan Frame_ADDA
DC Fan Frame_DELTA
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Description #1 Philips Screw Driver
Description #2 Diagonal cutting pliers
Description #3 Long nose pliers
Description #4 Unsolder tool
Description #5 Solder machine
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
EL-MF877-00
Template Revision B
-
PSU (Acbel ,Delta , Liteon ) and System fan
containing brominated flame retardants,
Mother board
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
-
-
-
Plastic Part
Description
Main bezel of desktop
product
System fan holder of
desktop product
Fan holder of desktop
product
System Fan Frame of
desktop product
System Fan Frame of
desktop product
Chassis Stand of
desktop product
DC Fan Frame of
desktop or tower
product
DC Fan Frame of
desktop or tower
product
PSG instructions for this template are available at
ISO 11469:2000 Plastic
Weight (grams) Part Mark
89g >ABS<
58.7g >PC+ABS FR(40)<
44.9 >PC+ABS FR(40)<
45g >PBT-GF30 FR(17)<
45g >PBT-GF30-FR(17)<
78.0g >ABS<
40g
>PBT-GF30 FR(17)<
40g
>PBT-GF30-FR(17)<
EL-MF877-01
0
TBC
0
0
0
0
Optional:
Tool Size (if
applicable)
100mm
130mm
NA
NA
230mm
Page 2
