RSA Lighting Combo Mini CM1B Specification Sheet

Combo mini recessed wall accent one (1) light 60o adjustable new construction housing - 7.13” height 12v bi-pin base mr16 lamp 75 watts max

Advertisement

Quick Links

Recessed adjustable trim suitable
for wall wash and wall accent
applications.
Ultra low profile trim flange for
minimum ceiling architecture
interference. Provides a sleek,
architectural look.
Trim has a durable powder coat
finish.
Inside of trim and lamp holder fin-
ished with flat black powder coat
for reduced lamp glare.
Trim is retained in housing with
heavy duty torsion spring clip.
All ComboMini™ fixtures can
accept up to two (2) optical
accessories per lamp.
Housing Construction:
Plaster frame and housing are 18
gauge CRS with durable powder
coat finish.
Integral electronic transformer
with 14 gauge CRS galvanized J-
Box assembly. External thermal
protection. UL listed for through
branch wiring for 8 #12, 90ºC sup-
ply conductors or 60ºC supply
conductors for end of run.
Type:
Combo Mini Recessed Wall Accent
o
One (1) Light 60
Adjustable
New Construction Housing - 7.13" Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
7.125"
4.75"
5.5"
1.625"
Provided with two (2) 14 gauge steel
butterfly type brackets for black iron
installations.
Vent holes in housing (1/2" diameter)
provide cooler operation.
Item #
Description
CM1W
Combo Mini Recessed Wall Accent
CM1B
One Light 60º Adjustable
CM1S
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice.
Project:
18.125"
7.125"
60º Locking Adjustability
4.535"
4.188" x 2.445"
Lamp adjusts 60º for variable beam placement.
Housing adjusts in plaster frame to accommo-
date various ceiling thicknesses.
Finish
White
Black
Silver
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: 818-349-3031 • www.rsalighting.com
CM1W
CM1B
CM1S
6.75"
4.25"
7.688"
Voltage / Wattage
12V / 75W Max.
CM2
