SPECIFICATION
Power supp y l
DC 12V or 24V
Operation Current
12V/850mA;24V/450mA
12V/
Holding Current
Delay Time
0/5/10/15sec.
NO/COM(0.1A@30VDC)
Door status sensor
NO/NC/COM(0.1A@30VDC)
Lock status sensor
Holding Force
2600Lbs(1200kg)
Magnetic distance(max.)
3mm
Red shows locked; Green shows unlocked
LED
182L X 30W X 25D(mm)
Lock Size
182L X 30W X 23.6D(mm)
Armature Plate
Weight
1.2kg
DIMENSION
WIRING DIAGRAM
Lock
Shear Lock
Model: YM-2400SL
400mA;
24V/280mA
Red(+)
Black(-)
Door Release
Button
Model
9 PIN Connection
Color
DC 12V
Red
Purple
Purple wire of the light
Green
Door Positions Sensor NO
Brown
Lock Positions Sensor NC
Gary
Lock Positions Sensor COM
Time Delay
POWER
ON
TIMER
15
0
30
SECOND
Power Supply
R
EMC
tested
Germany
Black
GND
Orange
Orange wire of the light
※
Dangling
Blue
Lock Status Sensor NO
White
Door Status Sensor COM
0S
5S
10S
DOOR
OPEN
FAIL
12VDC
FAIL
PUSH
SAFE
0.5A
BUTTON
LOCK
SECURE
PB
NC COM NO
MAINS
DIGITAL ACCESS KEYPAD
KEY
1 2 3
ARMED
4 5 6
7 8 9
DOOR
BELL
0 #
*
Keypad
15S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yli Electronic YM-2400SL
Summary of Contents for Yli Electronic YM-2400SL
- Page 1 Shear Lock tested Germany Model: YM-2400SL SPECIFICATION Model Power supp y l DC 12V or 24V 9 PIN Connection Color Operation Current 12V/850mA;24V/450mA DC 12V Black 12V/ 400mA; 24V/280mA Holding Current Delay Time 0/5/10/15sec. Purple Orange Purple wire of the light Orange wire of the light NO/COM(0.1A@30VDC)
- Page 2 THE COMMENTARY OF HOLES A:The Solid Door B:The Hollow Door The hole of screws Installation drawing The hole of screws Installation drawing Lock Lock The hole of screws The hole of screws Armature Armature Door frame Door frame C:Use The Extended Plate THE COMMENTARY OF INSTALLATION Step1:Confirm the position of installation Step2:Paste the sticker...
