Cooper Lighting AMETRIX SSIxx Installation Instructions

ŽŽ ‘›˜ž
‘ŽœŽ ’—œŠ••Š’˜— ’—œ›žŒ’˜—œ ŸŠ•’ ’‘ ‘Ž Š‹˜ŸŽ –Ž›’¡ œ¢•Žœ
J-box gasket
J-box
(by others)
Mounting plate
Appropriate fasteners
(by others)
(x4)
Fixture and ballast
assembly

Preparing Fixture for Mounting

Ballast
enclosure
1. To mount fixture, begin by removing both #10-32
x 5/8" pan head screws and remove shroud.
2. While supporting fixture, remove all three #10-32
x 1/2" Pan head screws from behind ballast
enclosure.
3. Pull fixture from mounting plate and store in a
safe place.
ADY080110 REV A(ECN080444)
˜ž— ‘›˜ž

Exploded View and Part Call-out

Additional bracing/ structure may be required to support fixture.
#10-32 x 1/2"
Pan head screws
(x3)
#10-32 x 1/2"
Pan head screws
(x2)
šžŠ›Ž ‘›˜ž
#10-32 x 1/2"
Pan head screws
(x3)
Attention:
Installing Mounting Plate
J-box
(by others)
1. Using dimensions provided on page 3, install
mounting plate over j-box using appropriate
fasteners(by others).
2.
Ensure gasket seals J-box.
—œŠ••Š’˜— —œ›žŒ’˜—œ
‘ŽŽ ˜
12 3/4"
Small, OUTDOOR
SSIxx
(Shroud, Integral)
Š›—’—
Ž˜›Ž œŠ›’— Š—¢ ˜›” Ž—œž›Ž
‘Š Š•• œ˜ž›ŒŽœ ˜ ™˜ Ž› Š›Ž ž›—Ž ˜
˜›” –žœ –ŽŽ •˜ŒŠ• —Š’˜—Š• Œ˜Žœ Š— ‹Ž
™Ž›˜›–Ž ‹¢ Š ŒŽ›’’Ž Ž•ŽŒ›’Œ’Š—
#10-32 x 1/2"
Pan head screws
(x2)
Integral Shroud
(wedge)
Gasket
Mounting
plate
••
