Magliner Caddy Cart Assembly Instructions

www.magliner.com

Caddy Cart

Table of Contents:

Parts List ..................................... 2

Assembly Instructions ............2-4

For safe, efficient product use, Magline recommends inspecting

equipment regularly and replacing damaged components immediately.

Table of Contents

Need help?

Do you have a question about the Caddy Cart and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS Caddy Cart Table of Contents: Parts List ........2 Assembly Instructions ....2-4 For safe, efficient product use, Magline recommends inspecting equipment regularly and replacing damaged components immediately. www.magliner.com...
Page 2 PARTS LIST Item Description Qty. Part No. TOOLS REQUIRED Handle Varies • (1) #3 PHILLIPS SCREWDRIVER Frame (with black caps) 302956 • (2) 1/2" OPEN END WRENCH • (1) 7/16” OPEN END WRENCH RH wheel bracket 302954 • (1) SMALL HAMMER LH wheel bracket 302953 •...
Page 3 ASSEMBLE THE AXLE AND WHEELS. STEP 2: Slide the axle through the wheel brackets so that it is centered between the brackets. Make sure the two center most holes in the axle align with the grooves in the wheel bracket for easier installation of the roll pin. Using a small hammer, install the two roll pins into these holes so that they are centered onto the axle.
Page 4 Fasten with four 1/4”-20 x 1-1/2" long pan head screws and four 1/4"-20 hex lock nuts. Securely tighten screws to 50-60 in.-lbs. torque. 80105 Figure 5 80675 Handle YOU ARE NOW READY TO PUT YOUR MAGLINER CART TO WORK. www.magliner.com Magline, Inc., 1205 West Cedar Street, Standish, MI 48658 • (800) 624-5463 • (989) 512-1000 B9337 © Copyright 2020 Magline, Inc.
