Page 2: Table Of Contents
Installation Manual Power Type Thermostat Application Guide Battery Power Description Hardwire (Common Wire) Gas or Oil Heat Hardwire (Common Wire) with Electric Furnace Battery Backup Heat Pump (No Aux. or Emergency Heat) Heat Pump (With Aux. or Emergency Heat) Multi-Stage Systems This product must be installed Heat Only Systems by a trained, experienced... - Page 3 Installation Manual Specifications ° ° ° ° The display range of temperature ....32 F to 99 F ( 0 C to 40 ° ° ° ° The control range of temperature ....41 F to 90 F (S C to 32 Load rating ..............
-
Page 4: Installation Tips
Installation Tips Wall Locations The thermostat should be installed approximately 4 to 5 feet above the floor. Select an area with average temperature and good air circulation. Do not install thermostat: • Near hot or cold air ducts • In direct sunlight •... - Page 5 Installation Tips Subbase Installation G) Horizontal Mount Installation Tip: • ® Vertical Mount Electrical Hazard Failure to disconnect the power before beginning to install this product can @� cause electrical shock or equipment ����/ ��� CD# damage. • Mercury Notice All of our products are mercury free.
- Page 6 Installation Tips Mount Thermostat Align the tabs on the subbase with corresponding slots on the back of the thermostat, then push gently until the thermostat snaps in place. .nn� ... it ·UU WAKE...
- Page 7 Installation Tips Battery Installation Battery installation is optional if thermostat is hardwired (Rand C terminal connected to 24V �F,1@@ power). � ------ -n- ..__, Important: High quality alkaline batteries are recommended. Rechargeable batteries or low quality batteries do not guarantee a 1-year life span. Insert 2 AAA I �...
- Page 8 Installation Tips About The Badge Gently slide a screwdriver into the bottom edge of the badge and turn the screwdriver counter clockwise. The badge is held on by a magnet in the well of ttie battery door and should pry off easily. DO NOT USE FORCE.
-
Page 9: Thermostat Quick Reference
Thermostat Quick Reference Getting to know your thermostat &' SunMonTueWe FriSatf'6\ 8 • a a-a lt • .-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·-·) □□. □ t.=· f rtt 1► >) WAKE LEAVE RETURN SLEEP 111111111111111111 � � �: ° n=t n !171�• I 11 I -•- H �... -
Page 10: Wiring
Wiring Wiring Caution: 1. If you are replacing a thermostat, � Electrical Hazard make note of the terminal connections on the thermostat Failure to disconnect the power before beginning to install this that is being replaced. In some product can cause electrical cases the wiring connections will shock or equipment damage. - Page 11 Wiring Wiring Tips & RC Terminal s CTerminal For single transformer systems, leave the The C (common wire) terminal does jumper wire in place between RH and RC. not have to be connected when the Remove jumper wire for two transformer thermostat is powered by batteries.
-
Page 12: Wiring Diagrams
Wiring Diagrams & Power supply Factory-installed jumper. Remove only when installing on 2-transformer systems. Use e ither O or B terminals for change over valve. & Use a small piece of wi r e (not supplied) to connect Wand Y terminals. &... - Page 13 Wiring Diagrams & Typical 1 H/1 C Heat Pump System �L2 & �L1 HOT @@]_ & COMPRESSOR RELAY �@ & � �@ COOL CHANGE OVER VALVE �@ FAN RELAY HEAT CHANGE ..�@ OVER VALVE �@ �@...
- Page 14 Technician Setup 1. Press MENU button 2. Press and hold TECHNICIAN SETUP button for 3 seconds. This 3 second delay is designed so that homeowners do not accidentally access the installer settings. 3. Configure the installer options as desired using the table below. 4.
-
Page 15: Technician Setup Programming
Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps This feature allows the installer to You can select the minimum 1\11 TI\ I 1- nl\Jt(J select the minimum run time for compressor run time from "off': I I .L I \I 1_ 1_11 II the compressor. - Page 16 TI\IITT r1,111 I TI\IITT LUUL L .ll l.l I Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps The swing setting often called The heating swing setting is H[FIT S��IN[, ° "cycle rate': "differential" or adjustable from 0.2 to 2 .
- Page 17 Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps F for Fahrenheit Select F for Fahrenheit read out °C □ ° or select C for Celsius read out. , □ C for Celsiust . - =- ° You can select either 12 or 24 Use the D or key to select hour clock setting.
-
Page 18: Wiring Diagrams
Wiring Diagrams Typical Heat-Only System With Fan L1 HOT HEAT RELAY Typical 1 H/1 C System: 2 Transformer FAN RELAY & c;:::::, REMOVE JUMPER � L1 HOT & �· COMPRESSOR RELAY �- FAN RELAY ..� L HEAT RELAY � L 1 HOT &... - Page 19 Wiring Diagrams Typical Heat-Only System RC@@ L1 HOT R& RH@@ C @@ 6�----- @@H------4 HEAT RELAY Typical Cool-Only System ...,__ _ fA RC @@ ..,___ _____ Ll HOT --t----, RH @@ ltj'I � COMPRESSOR t------4 ..,.----11 � \S'I RELAY FAN RELAY...
- Page 20 Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps Select GAS for systems that , _ :er·,::, 1-1-, 1 - control the fan during a call for □ FRN OPERRTI heat. Operation Select ELEC to have the Elec thermostat control the fan during a call for heat.
- Page 21 Technician Setup LCDWill Show Adjustment Options Default Tech Setup Steps The display light can be configured to operate 2 differet 'AUTO' - Any key ON ways. To come on only when the light key is pressed, when any AUTO 'ON' - Always ON key is pressed ,or stay on ALL of Display Light the time.
- Page 22 rnn, rn 11 . 1 Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps □ Use the or C!Jk � until the You can configure the system desired application is ashing. switch for the particular HEAT SYSTEM SET application: System Heat - Off - Cool,...
- Page 23 Technician Setup LCD Will Show Adjustment Options Default Tech Setup Steps A Note About Keypad Lockout: The function of activating your lockout choice takes place after you have exited tech setup. To lock or unlock the keypad hold down the for 3 seconds.
- Page 24 Programming Set Time (If using programming) 1. Press the MENU button 2. Press SET TIME Day of the week will be flashing. Use the [±] or to select the current day of the week. 4. Press NEXT The current hour will be flashing. Use the [±] or to s elect the current hour.
- Page 25 Programming Set Program Schedule To customize your 5+ 1 1 program schedule, follow these steps Weekday: 1. Select HEAT or COOL with the system switch. Note: You have to program heat and cool each separately. Press the MENU button (If menu does not appear first press RUN SCHED) Press SET SCHED.
- Page 26 Programming Saturday: for the Saturday WAKE time period, LEAVE Repeat steps thru time period, RETURN time period, and for the Saturday SLEEP time period. Sunday: Repeat steps 4 thru 7 for the Sunday WAKE time period, LEAVE time period, RETURN time period, and for the Sunday SLEEP time period.
- Page 27 Programming To customize your 7 Day Program schedule, follow these steps: Select using the system key. You have to HEAT or COOL Note: program heat and cool each separately. 2. Press MENU Press Monday will be displayed and the SET SCHED. Note: WAKE icon will be shown.
- Page 28 Programming 8. Repeat steps through LEAVE time period, that day's RETURN time period, and SLEEP time period. Tuesday, Wednesday, Thursday, Friday, Saturday, Sunday Repeat steps 4 thru 7 for the remaining days of the week. Programming All of our programmable thermostats are shipped with an energy saving pre-program.
- Page 29 Programming Factory Default Program Setpoint Setpoint Day of Events Time Temperature Temperature the Week (COOL) (HEAT) ° ° ° ° Wake F (21 F (24 ° ° ° ° Leave F (17 F (28 Weekday ° ° ° ° Return F (21 F (24 °...
- Page 30 Programming • A Note About Auto Changeover: If the thermostat is set to Auto, you have the ability to switch between Auto Heat or Auto Cool by pressing the System key. This can be done once the current mode has reached its set- point.
- Page 31 Programming • Reminders Note: Once a Reminder has been turned on and set, the elapsed time can be checked by navigating to it's tech setup step. The elapsed time will then appear in the text field. It can also be reset at that time by a press and hold of the third button from the left for 3 seconds.
