Summary of Contents for bluefin THBF715 Master Series

  • Page 2: Table Of Contents

    INSTALLATION MANUAL This manual covers the following models: •THBF715 Thermostat Applications Guide Des cription Power Type Gas or Oil Heat Electric Furnace Battery Power Heat Pump (No Aux. or Emergency Heat) Hardwire (Common Wire) Heat Pump (with Aux. or Emergency Heat) Multi-stage Systems Hardwire (Common Wire) with Battery Backup Heat Only Systems...

  • Page 3: Installation Tips

    INSTALLATION TIPS Wall locations The thermostat should be installed approximately 4 to 5 feet above the floor. Select an area with average temperature and good air circulation. Do not install thermostat: • Near hot or cold air ducts • In direct sunlight •...

  • Page 5: Subbase Installation

    SUBBASE INSTALLATION Mercury Notice: Caution: All of our products are mercury Electrical Hazard free. However, if the product you Failure to disconnect the are replacing contains mercury, power before beginning to dispose of it properly. Your local install this product can cause waste management authority electrical shock or equipment can give you instructions on...

  • Page 6: Wiring

    WIRING 1 Turn off Power to Heating/Cooling System c::::::J CJ c::::::J CJ c::::::JCJ c::::::J CJ c::::::J CJ c::::::J CJ Circuit breaker Heating/cooling system power swich 2 Remove Old Thermostat Remove the old thermostat but leave the wallplate with wires attached. Do not remove the wallplate yet - -- �...
  • Page 7 WIRING Label Wires with Tags Label the wires using the supplied wire labels as you disconnect them. Wire Labels Wiring Labels Etiquettes de fils R6tulos para los cables Apply these wiring labels to Lorsque vous retirez les fils Coloque estos r6tulos, con la each wire with the appropriate des bornes du thermostat designaci6n de las termina...
  • Page 8 WIRING Mount new wallplate Mount the new wallplate using the included screws and anchors. Drill 3/16-in. holes for drywall • Drill 3/16-in. holes for plaster...
  • Page 9 WIRING 6 Connect Wires Match the wire labels. If the labels do not match the letters on the thermostat, refer to "Alternate Wiring (Conventional Systems)" on page 9 and connect the terminal accordingly (see notes below). Remove metal jumper if you have both R and Re wires •...
  • Page 10 WIRING Alternate Wiring (Conventional Systems} If the labels do not match letters on the thermostat, refer to the chart below and connect the terminal accordingly (see notes below). GE)GE)I C 0 B WW2 Y2 Y RC RH/R If the wires will be connected to both RC and RH/R terminals, remove the meta l jumper If a C or X wire is available, connect with the C terminal.

  • Page 14: Technician Setup Menu

    TECHNICIAN SETUP MENU Technician Setup Menu T his thermostat has a technician setup menu for easy installer configuration. To setup the thermostat for your particular application: Press MENU button Press and hold TECH SET button for 3 seconds. T his 3 second delay is designed so that homeowners do not accidentally access the installer settings.
  • Page 15 Done TECHNICIAN SETUP MENU Feature Filter Room Minimum Compressor Cooling Heating Change Temperature Compressor Short Cycle Swing Swing Reminder Calibration On T ime Delay Feature The swing setting, This feature will flash This feature allows This feature allows The compressor short The swing setting, Description often called "cycle...

  • Page 16: Mounting And Battery Installation

    & MOUNT THERMOSTAT BATTERY INSTALL ATION Mount Thermostat Align the 4 tabs on the subbase with corresponding slots on the back of the thermostat, then push gently until the thermostat snaps in place. ::Jn.nn.M LLJ•LJLJ Room 1. f F Set At l'-I n_"...

  • Page 17: Programming The Thermostat

    PROGRAMMING THE THERMOSTAT Set Time Follow the steps below to set the day of the week and current time: Press MENU Press SET TIME & Day of the week will be flashing. Use the key to select the current day of the week. Press NEXT STEP The current hour will be flashing, When using 12-hour time, make sure tne correct a.m.
  • Page 20 PROGRAMMING THE THERMOSTAT Set Program Schedule To customize your program schedule, follow these steps Weekday: Saturday: Select HEAT COOL from the system switch. Repeat steps 4 through 7 for Note: You have to program heat and cool each separately Saturday WAKE time period, LEAVE...
