INSTALLATION INSTRUCTIONS

IMPORTANT: This appliance shall be installed only by a qualified technician in accordance with the manufacturer's
installation instructions, local gas fitting regulations, municipal building codes, electrical wiring regulations, and
local water supply regulations.

REMOVING PACKAGING MATERIALS

WARNING: Excessive Weight Hazard
• Use two or more people to move and install range�
• Failure to do so can result in back or other injury�
1� Remove all packaging materials, tape, and film from the range� Keep cardboard bottom under range� DO
NOT dispose of anything until the range installation is complete�
2� Remove all oven racks and parts packaged from the range�
3� To remove the cardboard bottom�
a� Take 4 cardboard corners from the carton�
b� Stack one cardboard corner on top of another� Repeat with the other 2 corners�
c� Place the stacked corners lengthwise on the floor behind the range to support the range when is laid
on its back�
4� Using two or more people, firmly grasp the range and gently lay it on its back on the cardboard corners�
5� Remove cardboard bottom�
NOTE: It is recommended to adjust leveling legs while the range is on its back�
NOTE: To place range back up into standing position
• Place a sheet of cardboard or hardboard on the floor in front of range to protect the flooring�
• Using two or more people, stand the range back up onto the cardboard or hardboard�

HOW TO INSTALL ANTI-TIP BRACKET

NOTE: An anti-tip bracket kit is provided with the range�
WARNING: Tip Over Hazard
• A child or adult can tip the range and be killed�
• Connect anti-tip bracket to rear range foot�
• Reconnect the anti-tip bracket, if the range is moved�
• Failure to follow these instructions can result in death or serious burns to children and adults�
IMPORTANT: DO NOT completely remove the rear leveling leg� The anti-tip bracket uses either the right-hand
or left hand, rear leveling leg to secure the range to the floor�
1. Remove the anti-tip bracket from where it is taped inside the range.
2. Place the bracket so that the back of the bracket is against the rear wall and the side edge of the bracket is
3/8" to 1/2" from the adjacent cabinet.
NOTE: If there is no adjacent cabinet, place the bracket so that the edge of the bracket is 3/8" to 1/2" in from
the range side panel. If the countertop overhangs the cabinet, offset the bracket from the cabinet by the
