Magic Chef MCSBRG24W Installation Manual page 10

Gas Pressure Regulator
The gas pressure regulator supplied with this range must be used� For proper operation, the inlet pressure to the
regulator SHOULD BE as follows�
Natural Gas
Minimum Pressure 5" WCP (Water Column Pressure)
Maximum Pressure 10.5" WCP (Water Column Pressure) Maximum Pressure 13" WCP (Water Column Pressure)
NOTE: Contact your local gas supplier if you are not sure about the inlet pressure.
Gas Supply Pressure Testing
NOTE: Gas supply pressure for testing regulator MUST be at least 1" WCP (Water Column Pressure) above the
manifold pressure shown of the model/serial rating plate.
• Line pressure testing above 0�5 psi gauge (14" WCP): The range and its individual shut-off valve must be
disconnected from the gas supply piping system during any pressure testing of that system test pressures in
excess of 0�5 psi (3�5kPa)�
• Line pressures testing at 0�5 psi gauge (14"WCP) or lower: The range must be isolated from the gas supply piping
system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping
system at test pressures equal to or less than 0�5 psi (3�5kPa)�
Minimum Pressure 8" WCP (Water Column Pressure)
10
LP Gas
