PCB Piezotronics ICP 102B18 Installation And Operating Manual page 9

Model Number
102B18
Performance
Measurement Range(for ±5V output)
Useful Overrange(for ± 10V output)
Sensitivity(± 15 %)
Maximum Pressure(static)
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(-5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Electrical Isolation
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector
Weight
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® PRESSURE SENSOR
ENGLISH SI
50 psi 344.7 kPa
100 psi 689.4 kPa
100 mV/psi 14.5 mV/kPa
1000 psi 6895 kPa
1.0 mpsi 0.007 kPa
≥ 500 kHz ≥ 500 kHz
≤ 1.0 µ sec ≤ 1.0 µ sec
0.5 Hz 0.5 Hz
≤ 1.0 % FS ≤ 1.0 % FS
≤ 0.002 psi/g ≤ 0.0014 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
3000 °F 1650 °C
2000 g pk 19,600 m/s² pk
20,000 g pk 196,000 m/s² pk
≥ 1.0 sec ≥ 1.0 sec
22 to 30 VDC 22 to 30 VDC
2 to 20 mA 2 to 20 mA
<100 Ohm <100 Ohm
8 to 15 VDC 8 to 15 VDC
8 8
10 Ohm 10 Ohm
Compression Compression
Quartz Quartz
Stainless Steel Stainless Steel
Invar Invar
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
0.50 oz 14.3 gm
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
[2]
except where noted below. More than one option may be used.
CA
- Ablative Coating
[1]
H
- Hermetic Seal
Sealing Welded Hermetic
[3]
M
- Metric Mount
Supplied Accessory : Model 065A40 Seal ring 0.435" OD x 0.397" ID x 0.030" thk brass (3)
replaces Model 065A03
[1]
N
- Negative Output Polarity
S
- Stainless Steel Diaphragm
Diaphragm 316L Stainless Steel
W
- Water Resistant Cable
NOTES:
[1]Typical.
[2]For +10 volt output, minimum 26 VDC supply voltage required. Negative 10 volt output may be
limited by output bias.
[3]Zero-based, least-squares, straight line method.
[4]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 065A03 Seal ring 0.435" OD x 0.377" ID x 0.030" thk brass (3)
Entered: AP Engineer: RPF
Date: 4/9/2015 Date: 4/9/2015
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 44078
Welded Hermetic
316L Stainless Steel
Sales: RWM Approved: RPF Spec Number:
Date: 4/9/2015 Date: 4/9/2015
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
40749
