Amana Technical Information— Room Air Conditioner
TE09095W2B
• Due to a possibility of personal injury or property damage, always contact an authorized technician for servicing
or repair of this air conditioner.
• Refer to Service Manual RS4110008 for installation, operation, disassembly, testing, and troubleshooting
information.
• Refer to Parts Manual RAC-RP-133 for part number information.
All safety information must be followed as provided in Service Manual RS4110008.
To avoid risk of electrical shock that can cause death or severe injury, disconnect unit from power and discharge
capacitor through a 10,000-ohm resistor before servicing, unless tests require power. Wires removed during
disassembly must be replaced on correct terminals to ensure proper grounding and polarization.
Model
Electrical requirements
Refrigerant/amount
Compressor
Voltage low/high (nominal)
BTUH
Watts
Current
Lock rotor
Full load
Overload protector
Close temperature
Open temperature
Short time trip:
Time
Current
Fan motor
Electrical requirements
RPM
Low speed
High speed
Watts at high speed
Current at high speed
Capacitor
Capacitance
Voltage rating (nominal)
Heater
Volts
Resistance
Watts
November 2001
TE09095W2B
!
CAUTION
!
WARNING
TE09095W2B
230/208V VAC 60Hz
HCFC22/30.885 ounces
187/253 VAC (230/208 VAC)
9,200 BTUH
851/769.6 watts
22.2 amps
3.70 amps
141.8°F ±48.2°F (61°C ±9°C)
275°F ±41°F (135°C ±5°C)
6.5-16 seconds
15 amps
230 VAC 60Hz
1050 RPM
1300 RPM
232 watts
1 amps
15/5 Mfd ±10%
370 VAC
230 VAC
14.3 ohms ±3%
3400 watts
1
RT4110048 Rev. 0
