- Page 1 CFD461GW CFD462GB CFD463WBG CFD463S USER MANUAL FROST FREE BOTTOM MOUNTED REFRIGERATOR Keep this manual in a safe location and use it for reference. Read this manual carefully before commencing operation of this appliance, and comply with the Terms and Conditions.
-
Page 2: Part Names And Locations
PART NAMES AND LOCATIONS Description Light Egg Tray Bottle Rack Refrigerator Glass Shelf Salad Crisper Upper Freezer Drawer Freezer Room Glass Shelf Bottom Freezer Drawer Adjustable Foot As the manufacturer holds the authority to redesign or modify its products without notice: Any modifications or upgrades of our products will result in this refrigerator varying slightly from this manual but the functionality will remain the same to that as set out within this manual. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Follow these basic precautions to reduce the risk of fire, electrical shock hazards or injury when operating the WARNING refrigerator: It is critical use this appliance safely. Read all instructions before operating the refrigerator and do not attempt to repair or modify this unit in any way as it can cause harm or void the warranty. - Page 4 R600a WARNINGS NOTE: This model uses 0.078Kg of R600a flammable refrigerant in its sealed system. The following must be observed for your safety: R600a Refrigerant Warning • This appliance contains a small quantity of R600a refrigerant which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using the Refrigerator Remove the exterior and interior packing. Before connecting the refrigerator to a power source, let the unit stand upright for approximately 4 hours to mitigate the possibility of a malfunction in the cooling system from improper handling during transportation. - Page 6 OPERATING INSTRUCTIONS Display panel is located at the door of the cold storage room, interface display as follows: Function Settings Power up The first connection of the refrigerator power supply, display the full light display 2 seconds after the resumption of normal display, the refrigerator by the smart run by default. Note:The electric control refrigerator has the function of self check function, and the function can be ignored when the refrigerator door is opened for the first time.
- Page 7 2)Press the "Function" key, function selection order according to the following cycle are: "LECO"→"Fast-freezer"→"Vacation"→"Smart"→"LECO". 3)Press the "Temp." key, digital icon flashing display, then press this button to adjust the size of the digital, and finally,press the "OK" key to finish setting. 4)Temperature setting range: Cold room temperature setting range is: 2.0℃~ 8.0℃;...
- Page 8 temperature display. Press any key to stop flashing, at the same time had reached the highest temperature of the freezer will be shown. Sensor fault alarm When refrigerators operating screen "E0", "E1", "E2", "EH" and so on, explain fridge sensor fails, the refrigerator can refrigeration, but please as soon as possible to the fridge for maintenance.
-
Page 9: General Care And Maintenance
GENERAL CARE AND MAINTENANCE Cleaning the Refrigerator Upon installation of your new appliance, it is recommended that it be cleaned thoroughly and properly maintained thereafter. Turn off the refrigerator and then unplug the unit from the wall outlet. Remove all food content before washing the inside with a damp cloth soaked in lukewarm ... -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE Many common refrigerator problems can be easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling for service. PROBLEM POSSIBLE CAUSES Power cord isn’t plugged in properly. ... - Page 11 The gasket/s may be dirty or not properly maintained. Clean properly. the seals and make sure they are dry before closing the door/s. The storage basket and/or shelves are out of position. For any enquiries, please call the CHiQ Cusotmer care on: 1300 796 688.
