NOTES ABOUT THE RDNET SOFTWARE

The RDNet software is protected by international copyright laws and is to be used to
configure the dB Technologies RDNet system only.
It is not allowed to modify or change or try to decompile this software.
n no event shall dB Technologies be liable to end-users for any damage whatsoever,
including but not limited to financial damages for loss of business profits or business
information due to the software use or inability to use this product. The foregoing provision
is effective even if dB Technologies has been advised of the possibility of such damages.
Even if the software has any material, verifiable and reproducible program errors,
dB Technologies shall have no obligation to modify such errors.
DVA Network
Rdnet Control 8
interface.
For this purpose, a proprietary communication protocol has been developed for receiving
and sending data; this connection permits real-time monitoring of the diffuser parameters,
such as output power, amplifier temperature, limiter status, etc...
It is also possible to select various equalizations or create new ones, set the desired
volume levels using the specific plug-in.
It is recommended to download DVA Network free software directly from
dB Technologies (www.dbtechnologies.com) in the special section
«Software & Controller»
DOWNLOAD

SPECIFICATIONS

Network:
- standard EIA RS-485
- up to 8 managed subnet
- max. 32 audio devices connected to each subnet
RDNET connections:
- 8 RJ 45 connectors (EtherCon) for CAT 5 cable
- 8 three-pole XLR plugs (as alternative to RJ 45)
PC connection:
- local: USB (type B)
- remote (alternative to USB): Ethernet (RJ 45)
Power supply:
- operating voltage: 100 ÷ 240 V ac (full range), 50 - 60 Hz (automatic selection)
- consumption: < 15 W
- connector: 'Powercon' type
Mechanical characteristics:
- Dimensions (w, h, d): 482 mm, 44 mm, 182 mm (one 19" rack unit)
- Net weight: 2 kg (4.4 lbs)
- Chassis material: pre-galvanized steel and painted
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in
E3 (or lower E2, E1) Electromagnetic environments.
is equipped with proprietary network interface, called RDNet, for PC
