- Page 1 User Manual 6200 Video Overlay Outland Technology, Inc. 38190 Commercial Court, Slidell, LA 70458 985-847-1104 sales@outlandtech.com www.outlandtech.com Document Number: 46-0029 Rev A2 July 2022...
-
Page 2: Table Of Contents
Text Overlay ..........................7 Smart Camera Setup Guide ....................... 7 DVR Setup ..........................8 6200: Video Overlay System The Outland Technology 6200 video overlay adds overlay and camera control (requires pan and tilt or zoom/focus camera) to the CON-3500/3700 HD Video Systems. -
Page 3: Hardware Set Up
The typical OTI Smart Camera overlay setup is shown below. Please note that for this guide video is not being display for additional clarity. Using a USB keyboard connected to the 6200 Overlay press the H key to display the help menu. This displays the available key options accessible from the main view (image above). -
Page 4: Setup Menu: S
Setup Menu The above Setup menu is displayed when the S key is pressed. Below is a description of each option. If a camera is connected and communicating to the overlay it’s firmware version will be displayed at the bottom (requires an OTI Smart Camera, PTZF or MPT Camera). 1. - Page 5 a. Select Desired position by pressing key associated with position. b. Example: Pressing J will display the data selection options. Select the desired data by pressing the associated key. Example press 8 to display the water temperature. Below are descriptions of the data options. 0: clear data 1: Display current time 2: Display current date...
- Page 6 8. Compass Setup: The compass menu is used to remove compass offset and display a compass rose. a. The compass setup is used to zero the compass offset from North. i. Hold camera facing north. ii. Press 1. Zero North to set the North Position. b.
-
Page 7: Dive Timers
Dive Timers The 6200 video overlay system features two dive timers. 1. Setup dive timers to be displayed in desired location a. Enter setup menu Dive Timers b. Enter data positions menu c. Select desired location then select dive time (repeat for dive timer 2 if desired) d. -
Page 8: Dvr Setup
In order to display the overlay on the video the DVR first needs setup. Follow the below guide for details. If addition details are required, please refer to the DVR manual. Additional setup can also be found on the Outland Technology website (outlandtech.com). 1. Turn on camera 1 power 2. - Page 9 5. Select the Camera button 6. Change Overlay Type on Camera 1 to Camera 4 7. Exit Camera Menu: Press ESC or Right mouse click...
- Page 10 8. Select the Display Button 9. Under HDMI Overlay Press the Eyedropper button and select a color (Black) in the displayed video region Select Eyedropper color in this region. Should be black for the Overlay. 10. Exit DVR menu (ESC or right click) 11.
