- Page 1 User Manual OUTLAND ROV 500 Outland Technology, Inc. 38190 Commercial Court, Slidell, LA 70458 985-847-1104 sales@outlandtech.com www.outlandtech.com 28 July 2021 Outland Technology Document Number:46-0010 RevB1...
- Page 2 Your Outland ROV has been rigorously tested. The quality and performance of this system comes with the full confidence and backing of Outland Technology, Inc. As a measure of that confidence, your ROV comes with a Limited one-year warranty that the unit remains free of defects in workmanship and materials.
-
Page 3: Table Of Contents
Contents LIMITED WARRANTY ........................... 4 ROV General Guidelines ........................6 System Overview ........................... 7 Outland ROV 500 ..........................7 Control Console and Power Supply ....................9 Hand Controller ..........................10 ROV Cable ............................11 System Startup ............................ 12 Setup Control Console and Power Supply ..................12 Setup ROV ............................ -
Page 4: Limited Warranty
Advertising claims made by us represent our honest opinion of the qualities and features offered by the product described. We disclaim any warranties expressed or implied, including warranties of merchantability and fitness for a particular purpose, except as provided herein. In no event shall Outland Technology be liable for consequential damages of any kind. Shipping All returns for warranty service must be authorized by Outland. - Page 5 NEVER PLUG OR UNPLUG ELECTRONICS WITH POWER ON! Damage or personal injury may result. Caution Do not operate the thrusters in air at high speeds or for extended durations. Damage to thruster may result. 28 July 2021 Outland Technology Document Number:46-0010 RevB1...
-
Page 6: Rov General Guidelines
IV. ROV storage and shipping. 4.1 Clean and flush with fresh water. 4.2 Dry the cable and ROV before closing storage boxes. This will minimize mold, mildew and corrosion on equipment and interior of boxes. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 7: System Overview
System Overview Outland ROV 500 The Outland ROV 500 system is a robust, powerful Class II vehicle capable of handling harsh conditions. System components have been designed for maximum reliability while incorporating the latest technology. The robust frame allows for addition sensors and equipment to be mounted and integrated into the vehicle. The tether allows for simultaneous stream of up to 3 analog HD cameras. - Page 8 6. Thruster (Port Fwd/Rev) Flooded DC brushless thrusters are used on the ROV 500. The control electronics are mounted in the ROV Control Bottle. Do not operate the thrusters out of water at high speeds or for extended periods of time as damage may result to the bearings.
-
Page 9: Control Console And Power Supply
When supplying power from a generator or inverter the unit must be capable of supplying 2000 watts minimum. Any outlet used should be rated at a minimum of 15 amps at 120VAC or 13 amps at 220VAC. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 10: Hand Controller
8. Auto Heading Enable Button Press button to enable auto heading mode. LED will illuminate when active. 9. Auto Heading Switch Toggle switch up and down to choose between Gyroscope and compass auto heading. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 11: Rov Cable
Controls the open/close and rotation of manipulator. ROV Cable The ROV Cable (C-340x) contains one Cat5E cable (four, 24AWG twisted pair conductors) and twelve 22AWG conductors. Standard lengths listed below: C-3405: 500ft (150m) C-3410,1000ft (300m) 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 12: System Startup
ROV. If indicator does not illuminate refer to Troubleshooting Guide. 4. Verify video and overlay is displayed on the monitor. If the recorder needs setup refer to DVR Manual. 5. If necessary, contact Outland for support with configuring spare lines. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 13: Video Adjustments
Length Low Video Signal, Blinking green Compensation to adjust the level per channel. First set the gain then adjust each channel as needed. No Video Signal, No light 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 14: Perform Preflight Check
Test pan if associated thruster thruster activates. optional pan and tilt activates. camera installed. Press Camera Select to cycle through available cameras. Verify video is displayed on monitor. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 15: Flight
Trim is available in each direction. Stick Gain Stick gain controls the maximum control stick drive signal from 100% to 0% output. 100% means full power will go to the thruster when stick control is at 100%. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 16: Video Overlay Interface
Time and Date Options: The time and date menu allow for the overlay time and date to be updated. Update Device: The update device menu allows for individual device updates to be pushed, send manual commands to devices, update the overlay software, and save/delete the overlay setup. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 17: Edit Mode
Increase Font Size Decrease Font Size Justification: Right (top) Middle (middle) Right (bottom) Contrast Page Selection (x indicates pages Move Rotate Text selected text will be displayed) Keyboard EDIT OPTIONS Displayed Text View 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 18: Diagnostic Display
Red – for negative side fault. Compass: Direction in degrees from north Depth: Current ROV Depth in selected units Depth Rating: Depth transducer maximum rating in PSI. Altimeter: Current ROV altitude in selected units (if equipped) 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 19: Hud Options
6. Click and drag gauge until desired size is achieved. 7. Once desired HUD is setup, press the Exit Layout Button. 8. The setup is automatically saved Resize 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 20: Devices
Direction selection allows for the direction to be revered. The HV Outputs allows for individual thrusters to be disabled. The HV Status is only implemented on the BTL-100 (ROV-1000, 2000, and 2500). 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 21: Data Line Options
Only zero depth with ROV in the water on the surface with depth mode disabled. Zero Cp: CP should be Zeroed at the factory for best result. Connect CP Probe, press Zero CP. Only zero CP when vehicle is out of the water. 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 22: Time And Date Options
Outland Technology. Press Select File Save Settings File: Use this button to save the current overlay setup. Delete Settings File: Use this button to delete the current overaly setup file 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 23: System Maintenance
2. ROV data cable 3. Depth sensor 4. Manipulator 5. Lights 6. Vertical Starboard thruster 7. Vertical Port thruster 8. Starboard thruster 9. Port thruster 10. External camera 11. Spares connections 12. Altimeter/CP 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 24: Rov Power Connection
Twisted Pair 2 - (CP GND) sonar, video or other data COMM + Bi-directional Differential Communication COMM - +15V Power +15 VDC Twisted Pair 3 + Bi-directional Extra twisted pair for differential signal Twisted Pair 3 - 28 July 2021 Outland Technology Document Number:46-0010 RevB1... -
Page 25: Altimeter/Cp Connection
12V camera power (1.5A max) Video 6 Input 75ohm Composite Video Input (SD or HD) Video 7 Input 75ohm Composite Video Input (SD or HD) Video 8 Input 75ohm Composite Video Input (SD or HD) 28 July 2021 Outland Technology Document Number:46-0010 RevB1...
