- Page 1 User Manual OUTLAND ROV 1000, 2000 & 2500 Outland Technology, Inc. 38190 Commercial Court, Slidell, LA 70458 985-847-1104 sales@outlandtech.com www.outlandtech.com Document Number: 46-0002 Rev B1 April 2021...
- Page 2 Your Outland ROV has been rigorously tested. The quality and performance of this system comes with the full confidence and backing of Outland Technology, Inc. As a measure of that confidence, your ROV comes with a Limited one-year warranty that the unit remains free of defects in workmanship and materials.
- Page 3 BLANK PAGE...
-
Page 4: Table Of Contents
Contents LIMITED WARRANTY ........................6 ROV General Guidelines ......................8 System Overview ......................... 9 Outland ROV 1000, 2000, and 2500..................9 Control Console and Power Supply ..................11 Power Supply: PS-4000 ......................12 Hand Controller ........................12 ROV Cable ..........................14 System Startup .......................... 15 Setup Control Console and Power Supply ................15... - Page 5 38190 Commercial Court, Slidell, Louisiana U.S.A. 70458 Voice: 985-847-1104 | Fax: 985-847-1106, sales@outlandtech.com www.outlandtech.com Model 1000 Model 2000 Model 2500...
-
Page 6: Limited Warranty
Advertising claims made by us represent our honest opinion of the qualities and features offered by the product described. We disclaim any warranties expressed or implied, including warranties of merchantability and fitness for a particular purpose, except as provided herein. In no event shall Outland Technology be liable for consequential damages of any kind. - Page 7 NEVER PLUG OR UNPLUG ELECTRONICS WITH POWER ON! Damage or personal injury may result. Caution Do not operate the thrusters in air at high speeds or for extended durations. Damage to thruster may result. Outland Technology Inc. 46-0002 Rev B1 - April 2021...
-
Page 8: Rov General Guidelines
Port side lateral and port side forward/reverse thrusters are reverse pitch (left hand). 4.3 Dry the cable and ROV before closing storage boxes. This will minimize mold, mildew and corrosion on equipment and interior of boxes. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 9: System Overview
System Overview Outland ROV 1000, 2000, and 2500 The Outland ROV systems are robust, powerful Class II vehicles capable of handling harsh conditions. System components have been designed for maximum reliability while incorporating the latest technology. The robust frame allows for additional sensors and equipment to be mounted and integrated into the vehicle. - Page 10 508 pixels. 18. Thruster (Starboard Lateral) Refer to item 9 above. 19. Cable grip attachment point Attached cable grip to this location. 20. Thruster (Starboard Fwd/Rev) Refer to item 99 above. Outland Technology Inc. 46-0002 Rev B1 - April 2021...
-
Page 11: Control Console And Power Supply
300VDC. When supplying power from a generator or inverter the unit must be capable of supplying 4000 watts minimum. Any outlet used should be rated at 30 amps (120 VAC) to 15 amps (240 VAC). Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 12: Power Supply: Ps-4000
PS-1080 power supplies. PS-4000 Outlands newest power supply, the PS-4000, is available for all ROV 1000, 2000 and 2500 units. Supplying up to 4000W at 300VDC, the power supply incorporates the same LIM/GFI and add the capability of monitoring the output without using the overlay system by means of a small display. -
Page 13: Hand Controller
Rotate knob counterclockwise to add port lateral trim. Rotate knob clockwise to add starboard lateral trim. 12. Forward/Reverse Trim Knob Rotate knob counterclockwise to add reverse trim. Rotate knob clockwise to add forward trim. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 14: Rov Cable
The ROV Cable (C-340x) contains one Cat5E cable (four, 24AWG twisted pair conductors) and twelve 22AWG conductors. Standard lengths listed below: C-3405: 500ft (150m) C-3410,1000ft (300m) Assembly Drawing on page 31. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 15: System Startup
12. Power connections for DVR and monitor (11). 13. Video Output Connection, typically connected to DVR (12). 14. Make sure the Main power switch on the power supply is off. 15. Connect input power to power source (13). Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 16: Setup Rov
Use gain to adjust the signal of all channels Low Video Signal, Blinking green and the Length Compensation to adjust the level per channel. First set the gain then adjust each channel as needed. No Video Signal, No light Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 17: Perform Preflight Check
Right to turn on and hold Left to turn off. Test pan if optional pan and tilt camera is installed using Right/Left. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 18: Flight
Stick Gain Stick gain controls the maximum control stick drive signal from 100% to 25% output. 100% means full power will go to the thruster when stick control is at 100%. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 19: Video Overlay Interface
These indicate the last eight power cycles. A dot indicates normal power cycle. A + indicates a GFCI trip on the high side and a – indicates a GFCI trip on the low side. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 20: Menu Page
3. Displays connected devices firmware number and revision. 4. Choose the data to display on the text page views (same for all views) and the position. 4.2. Choose Data to Display 4.1. Choose Display Position Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 21: Advanced Menu
These options are setup at the factory for the specific vehicle setup. Contact Outland for additional details. WARNING: Call for more information about advanced options. Changing advanced options without permission will void the warranty. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 22: Devices Menu
4. Reconnect each cable to the associated port and secure cables to frame if previously removed. Plug and secure any loose cables ends. Route the cables so they do not interfere with water flow from the thrusters. Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 23: Electrical Interface
3. Rear ROV Bottle Lights 4. Rear Camera ROV Power Connection Connector: Subconn/Seacon MC-BH-3-M Signal Function Description HV + Power +150 VDC HV - Power - 150 VDC Chassis Power Chassis Ground Outland Technology Inc. 46-0002 Rev B1 - April 2021... - Page 24 +12V Power 12V camera power (1.5A max) Video 2 Input Video Input (SD or HD) Video 3 Input Video Input (SD or HD) Video 4 Input Video Input (SD or HD) Outland Technology Inc. 46-0002 Rev B1 - April 2021...
-
Page 25: Thruster
COMM + Bi-directional Differential Communication COMM - +12V Power 12 V camera power Video 2 Output HD Video Output Address 0 Input Camera Address LSB Address 1 Input Camera Address MSB Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 26: Uwl-505 Light, Mp-100 Manipulator
RS232 data input from Altimeter COMM + Bi-directional Differential Communication COMM - +24V Power 24 VDC Input Input CP Voltage 1 Output Input CP Voltage 2 Output CP Common Input CP Ground Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 27: Btl-050 Vdsl Bottle (Optional)
Line 3 - Video 2 output, Spare 1 (DB9) or USB Line4 + Bi-directional Spare twisted pair. Can be connected to Line4 - Video 3 output, Spare 1 (DB9) or USB Outland Technology Inc. 46-0002 Rev B1 - April 2021... - Page 28 No Connection Aux Controller Connection Connector: 211398-1 Signal Function Description 12VDC Power 12V power supply for hand controller Power Primary ground return for 12V power COMM + Bi-directional Differential Communication COMM - Outland Technology Inc. 46-0002 Rev B1 - April 2021...
-
Page 29: Rov Power Supply
Power Chassis ground connection. Safety ground wire connection. +12V Power 12V DC from Control Console COMM + Bi-directional Differential Communication COMM - Line Power AC Input wired to accept 100-240V Neutral Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 30: Connector Diagrams
Connector Diagrams Wet-mate Bulkhead/In-Line Connectors Male Bulkhead and In-line Connector pinouts Female Bulkhead and In-line Connector pinouts Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 31: System Drawings
System Drawings ROV Block Diagram Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 32: Rov Spare Line Routing
ROV Spare Line Routing Outland Technology Inc. 46-0002 Rev B1 - April 2021... -
Page 33: Rov Cable Wiring Diagrams
ROV Cable Wiring Diagrams Outland Technology Inc. 46-0002 Rev B1 - April 2021... - Page 34 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 35 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 36 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 37 Use wiring diagram 25-0029 Rev B1 for ROV Serial Numbers less than or equal to that listed below and use 25-0029 Rev C1 for serial numbers greater then listed. ROV-1000: 254, ROV-2000: 526, ROV-2500: 771. Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 38 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 39 Use wiring diagram 25-0030 Rev B1 for ROV Serial Numbers less than or equal to that listed below and use 25-0029 Rev C1 for serial numbers greater then listed. ROV-1000: 254, ROV-2000: 526, ROV-2500: 771. Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 40 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 41 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 42 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 43 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
- Page 44 Outland Technology Inc. 46-0002 Rev B1 - April 2021...
