Summary of Contents for Toast Flex 14
- Page 1 Installation Guide TOAST HAR DWAR E...
-
Page 2: Before Getting Started
If you are pre-live, reach out to Toast Onboarding. If you are post-live, reach out to Toast Support. Wipe down the countertop with the alcohol wipe provided in your box. -
Page 3: Cabling Diagram
Use the cabling diagram as a guide for how your system will be wired when it’s all set up. Toast Flex MSR Card Reader Only if you have a Toast Flex for Guest (Wedge) Direct Attach Toast Flex for Guest... - Page 4 “Internet IN” on the Toast Printer. Take the red end of the USB-C cable and plug it into the red “To Stand” port on the Toast Printer. Take the other end and connect it to the orange port on the base of the Printer Toast Flex.
- Page 5 See the image shown above on the page. After configuring your Toast Printer, the LED will be amber if the printer For more information regarding printer setup, check is in Sleep mode. This happens if the printer is turned off. To power it out this article on Toast Central.
- Page 6 Toast Flex + Toast Printer CONTINUED How to Add Peripherals Step 8 If you have a cash drawer, plug in the cash drawer cable to your Toast Printer. If you have a Toast Flex for Guest (Wedge), gently flip and place Step 9 your Flex Terminal so that the display faces down and unscrew the two thumb screws and lift up to remove the back plate.
- Page 7 Set up payment using one of the options below: Toast Tap If you are attaching your Toast Tap to your Toast Flex and Toast (On-Counter) Printer set-up, plug the USB-A end on your cable into your Toast Printer. If you have Toast Tap (Direct Attach to Toast Flex), this will already be adhered to your Toast Flex terminal.
- Page 8 Turn on EMV. EMV must be turned on to accept payment on your new Toast system. See page 10 for EMV set up instructions. If you have any additional printers to set up, this is done via the Printer Setup feature in the Toast app.
-
Page 9: Card Readers
Card Readers Unpack your Toast Card Reader. Toast Tap(On Counter) Toast Tap (Direct Attach) Toast MSR (Magnetic Stripe Reader) - Page 10 Configuring EMV for your Toast System in the Toast App Your Toast system is EMV capable. EMV is a credit card payment process that checks cards embedded with a computer chip for their legitimacy. Enabling EMV will allow for dipping and tapping of credit cards on the Toast Tap.
- Page 11 When setting up your Toast Tap (On-Counter), you may have a second screen For more information regarding card reader setup, check attached to your terminal - also known as a Toast Flex for Guest or Guest- out this article on Toast Central Facing Display.
- Page 12 To Meraki / Toast Network ft. Choose the cord length that best suits your restaurant and connect it from the Toast Network to the yellow port labeled “Internet IN” on the base of the Toast Flex terminal stand. Step 3 Step 2 Remove the power box labeled “Power.”...
- Page 13 Step 5 CONTINUED Power on your Toast Flex Power on the Toast Flex and follow the Toast setup instructions that appear on the screen. Log into your restaurant in the Toast App and complete basic setup. Note: You may need to update the Toast App when you open it for the first time.
- Page 14 Kitchen to be located. Make sure there is a power outlet and ethernet connection going to the Toast Network in reach. Set up prep stations on Toast Web before doing any initial setup on the To Meraki / Toast Flex for Kitchen.
- Page 15 Kitchen to be located. Make sure there is a power outlet and ethernet connection going to the Toast Network in reach. Set up prep stations on Toast Web before doing any initial setup on the Toast Flex for Kitchen.
- Page 16 Toast Flex for Guest Statement 8-inch, 1280 x 800 resolution The device may not be modified in any way without Toast, Inc. (“Toast”)’s permission, and use of the Camera 5M FF USB Camera device must be in accordance with this user manual. Toast is not responsible for the following scenar-...
- Page 17 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. Toast hereby declares that this radio equipment is in compliance • Connect the equipment into an outlet or a circuit different from that to which the receiver is connected.
- Page 18 Visit toasttab.com/classroom Visit pos.toasttab.com/blog Need to talk to someone right away? Toast Customer Care is available 24/7 to help or route you to the correct team at Toast. Login to your account at central.toasttab.com for chat support, to submit a new...
