- Page 1 Contactless Pay INSTALLATION & CONFIGURATION INSTRUCTIONS...
-
Page 2: What's In The Box
WHAT’S IN THE BOX? Contactless Puck Contactless Reader Plate with adhesive Stickers for your door or windows to advertise the types of payments you can accept Counter placement pad for your Contactless Puck Tool kit containing a screwdriver, alcohol wipes, and extra adhesives Micro-USB to Micro-USB cable USB-A to Micro-USB cable Note: You will only use one of the... - Page 3 Error Next, if you have an existing card reader, physically remove it before installation. You’ll also need to digitally remove the reader in Toast following these steps: Navigate to the main menu on your terminal, then select Device Setup. Swipe with stripe facing up...
- Page 4 We recommend using this cable if you have an available port If you don’t have an available port, or if you only have a open on your Toast Hub, USB-Hub, or Toast Printer. terminal, use this cable instead. This cable plugs into the USB port on your This cable with the plate attached plugs into the device.
- Page 5 Plug in the remaining Micro-USB side into the bottom of the puck. Toast Hub or USB-Hub. Or plug the USB end of the cable into your Toast Printer. The end of this cable will be marked “to reader.” Nice work! Next, turn to the EMV Configuration...
- Page 6 MICRO - USB TO MICRO - USB INSTALL STEPS Remove the plate covering the port on the If your terminal stand has a neck to hide the cable, side of your terminal. feed it through for a cleaner look. Plug in the remaining end into the bottom of the puck. Plug in the end of the Micro-USB cable paired with the cover and screws.
- Page 7 EMV CONFIGURATION Your contactless reader will auto detect once plugged into your Toast system. You’ll need to enable EMV for the ability to take chip card and contactless payments. Once the puck has been properly plugged into your You’ll see an option for Card Readers below the EMV Toast hardware, restart your terminal.
-
Page 8: Finishing Touches
FINISHING TOUCHES Wrap your cable around the inside of your puck in a To anchor your contactless puck, take the plate with clockwise motion to reduce wire clutter. adhesive and apply it to your counter surface. Keep in mind, the adhesive is strong, so plan your anchoring spot wisely. - Page 9 FINISHING TOUCHES Firmly press the plate down with the adhesive Cards can be: and hold for six seconds. The “insert” side should face toward your guests. • Tapped on the top of the puck. • Dipped into the front slot with the card chip facing up. •...
- Page 10 Questions? know they can pay See the Contactless Reader with contactless. Troubleshooting Guide. Or contact Toast Support online or via phone at 617-682-0225. Find a visible clean spot on the counter to display the card reader and mat. Flip mat over to preferred color treatment.
- Page 12 User shall use the supplied USB cable if an available port open on the product...
