- Page 1 OPERATING INSTRUCTIONS Key-operated multi-point locks AS 2750 AS 2750 with T2 Window systems Door systems Comfort systems...
-
Page 3: Table Of Contents
KFV - operating instructions Multi-point locks key-operated, AS 2750 Contents ABOUT THIS DOCUMENTATION ....4 Target group ..........4 Product description ........4 Producer ............4 Dimensions ........... 4 Applicable documents ........4 Symbols used ..........4 SAFETY ............4 Requirements for the target group ....4 Intended use .......... -
Page 4: About This Documentation
Requirements for the target group KFV Karl Fliether GmbH & Co. KG The following persons may only operate the product if A company of the SIEGENIA GROUP they have understood the dangers involved in handling Siemensstraße 10 the product or if they are supervised during operation: 42551 Velbert •... -
Page 5: Transport
KFV - operating instructions Multi-point locks key-operated, AS 2750 Transport CAUTION • Ensure that the locking elements are in the release The signal word "Caution" designates a potentially position. hazardous situation. If this hazardous situation is not • Multi-point locks are sensitive construction ele- prevented, it could lead to minor or moderate injuries. -
Page 6: Foreseeable Improper Use
KFV - operating instructions Multi-point locks key-operated, AS 2750 Foreseeable improper use NOTICE NOTICE Damage to the lock and the frame parts Damage to the main lock The lock can be damaged if the locking elements are in the locking position when the door is open. The main lock of the multi-point lock could be dam- aged if you drill through the door leaf in the area of •... - Page 7 KFV - operating instructions Multi-point locks key-operated, AS 2750 NOTICE NOTICE Damage to the main lock Impairment of the function The main lock can be damaged if the lever handle The function is impaired if the multi-point lock is and key are operated at the same time. painted.
-
Page 8: Components
KFV - operating instructions Multi-point locks key-operated, AS 2750 Components The multi-point lock is equipped with two auxiliary boxes 1 of which each is equipped with two spring mounted soft lock latches. The multi-point lock is optionally available with a pre-mounted safety lock 2 . AS 2750 AS 2750 with T2 8/16... -
Page 9: Operation
KFV - operating instructions Multi-point locks key-operated, AS 2750 Operation NOTICE Damage to the main lock The main lock of the multi-point lock can be dam- aged if the lever handle and key are operated at the same time. • Do not operated the key and the lever handle at the same time. - Page 10 KFV - operating instructions Multi-point locks key-operated, AS 2750 During the closing process, the latches in the auxiliary box [1] are pushed via their inclined side into the recess of the Q-adjustment. Open door f Activate the lever handle. The main lock latch and the latch- es of the auxiliary box retract and release the door.
-
Page 11: Function Of The Locking Elements
KFV - operating instructions Multi-point locks key-operated, AS 2750 4.1.2 Function of the locking elements f Turn the key in the locking direc- tion with a single turn (2x 360°)*. The main lock bolt [1] and the hook bolt [2] of the auxiliary box are completely extended. -
Page 12: Safety Lock T2 (Optional)
KFV - operating instructions Multi-point locks key-operated, AS 2750 Safety lock T2 (optional) On activation, the T2 safety lock restricts the opening gap of the door. The safety lock T2 is activated from the inside via a rotary knob, the so-called handle [2]. The T2 safety lock can also be released via the main lock using a The T2 safety lock consists of two components: •... -
Page 13: Releasing The T2 Safety Lock Via The Main Lock
KFV - operating instructions Multi-point locks key-operated, AS 2750 4.2.3 Releasing the T2 safety lock via the main lock If the main lock is locked, it must first be released. f Turn the key in the release direc- tion with a single turn (2x 360°)*. -
Page 14: Malfunctions
KFV - operating instructions Multi-point locks key-operated, AS 2750 f Open the door. The blocking clip [1] remains in position and the door can be com- pletely opened. Malfunctions Repair of the multi-point lock is not permissible. In case of damage or malfunction, the mul- ti-point lock must be repaired or replaced by KFV or by a specialist company. -
Page 15: Cleaning And Maintenance
KFV - operating instructions Multi-point locks key-operated, AS 2750 Cleaning and main- tenance All components of the multi-point lock have already been treated with long- term lubrication and are consequently maintenance-free. However, if a subsequent lubrication of the locking elements should be necessary, use only spray-on grease. - Page 16 www.siegenia.com...
