  • Page 1 ASSEMBLY INSTRUCTIONS Multi-point locks Key-operated BS 2100 BS 2800 Extension pieces A 2100 A 2800 Window systems Door systems Comfort systems...
  • Page 2 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 2/44 02.2019 H39.MFVRS006EN-00...
  • Page 3: Table Of Contents

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Content INTRODUCTION .........4 Mounting the handle set ......27 Milling the frame ......... 29 Manufacturer and Service ......4 4.9.1 Frame milling for BS 2100 BS 2800 ..... 29 Target group of this documentation ..... 4 4.10 Requirements for SKG certification .....
  • Page 4: Introduction

    Manufacturer and Service (e.g. deadbolt, latch) must not be painted over. KFV Karl Fliether GmbH & Co. KG Installation conditions and requirements A company of the SIEGENIA GROUP Siemensstraße 10 Local building laws and regulations must be observed 42551 Velbert...
  • Page 5: Transport

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Transport Symbols used • Block set the door leaf in the frame with door gap The following icons are used in this document: restrictors. General warning symbol • The transit support provided must remain in the main lock during the transport of a pre-assembled Useful information or advice door without cylinder lock.
  • Page 6: Other Types Of Indicators

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Other types of indicators 1.11 Applicable documents Below is a list of symbols used in these instructions and For the installation of the multi-point lock, it is essential their meanings: to observe all assembly and operating instructions that are enclosed with other (optional) components.
  • Page 7 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 The door leaf must not be carried using the lever handle as a grip. None of the locking elements may be excluded when the door is open. Force must be exerted on the lever handle only in the normal direction of rotation.
  • Page 8: Safety

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Safety Before starting the assembly work, read the following safety instructions carefully. They are designed to keep you safe and prevent hazards, injuries and material damage. Observe all warning notes. Information This symbol indicates special features and designates facts that require increased attention.
  • Page 9: Variants And Components

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Variants and components Two variants of the multi-point lock are available, with comfort mushroom cam [1] or with roller bolt [2]. An extension piece [3] or [4] with an additional locking element can be mounted to extend the multi-point locks. BS 2100 BS 2800 A 2100...
  • Page 10: Size Variants

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Size variants 3.1.1 PZ dimensions: 72 mm, 74 mm, 92 mm, 94 mm The dimensions apply to the multi-point lock in the locking position Size variants R001 2170 1020 R002 2170 1050 R003...
  • Page 11: Distance 85 Mm

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 3.1.2 Distance 85 mm The dimensions apply to the multi-point lock in the locking position Size variants R001 2170 1013 R002 2170 1043 R003 2170 1013 R004 2400 1043 R005 2170 1042 R014...
  • Page 12: Distance 88 Mm

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 3.1.3 Distance 88 mm The dimensions apply to the multi-point lock in the locking position Size variants R001 2170 1016 R002 2170 1046 R003 2170 1016 R004 2400 1046 R005 2170 1045 R014...
  • Page 13: Main Lock Types, Key-Operated

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 3.1.4 Main lock types, key-operated Variable dimensions in mm Deadbolt Cylinder lock dimension Backset Rear backset projection Main lock type PZ/RZ 55, 65, 70, 80 17.5 57.5 12.5 51.5 55, 65, 70, 80 17.5 57.5 12.5...
  • Page 14: Additional Locking Elements

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 3.1.5 Additional locking elements BS 2100 11,5 BS 2300 14/44 02.2019 H39.MFVRS006EN-00...
  • Page 15: Installation

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Installation Change DIN orientation of the soft lock latch 1 x 5.5 mm There is a slot [1] on the gear box side. The locking spring [2] of the latch shank can be opened through this slot using a slotted screwdriver.
  • Page 16: Swing Door Roller Latchreplace Soft Lock Latch With Swing Door Roller Latch

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Swing door roller latch 4.2.1 Replace soft lock latch with swing door roller latch 1 x 5.5 mm There is a slot [1] on the gear box side. The locking spring [2] of the latch shank can be opened through this slot using a slotted screwdriver.
  • Page 17: Adjustment Of Swing Door Roller Latch

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.2.2 Adjustment of swing door roller latch f Align the centre part in such a way that the hole [1] is facing forwards. 2 mm f Insert a 2 mm hexagon wrench into the latch shaft through the hole in the centre part.
  • Page 18: Milling The Door Leaf

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Milling the door leaf Determination of position, see chapter Wear safety goggles 3.1 “Size variants” from page 10. Routed pocket for the main lock [1] 16.0 mm [2] 234.0 mm [3] 137.0 mm [4] 17.5 mm + 1 mm [5] Backset...
  • Page 19: Installing The Multi-Point Lock

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Installing the multi-point lock f Insert the multi-point lock in the milled door leaf. f Adjust the multi-point lock to the handle nut [1]. f Screw the multi-point lock to the door leaf.
  • Page 20: Extension Pieces A 2100, A 2800

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Extension pieces A 2100, A 2800 For tall doors, the multi-point lock can be supplemented at the top with an extension piece with a further locking element. A 2100 A 2800 20/44 02.2019 H39.MFVRS006EN-00...
  • Page 21: Cropping The Multi-Point Lock

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.5.1 Cropping the multi-point lock f On the faceplate on the multi- point lock [1], measure 25 mm upwards from the middle of the fastening hole [2] above the locking cam. f Crop the projection and deburr the sawn edges.
  • Page 22: Inserting The Multi-Point Lock

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.5.2 Inserting the multi-point lock f Insert the multi-point lock in the milled door leaf. f Adjust the multi-point lock to the handle nut [1]. 22/44 02.2019 H39.MFVRS006EN-00...
  • Page 23 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 f Leave the top four screwing points free. f Screw the multi-point lock to the door leaf at the remaining screwing points. H39.MFVRS006EN-00 02.2019 23/44...
  • Page 24: Measure And Crop The Extension Piece

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Measure and crop the extension piece The faceplate and drive rod must not be bent. f Carefully draw the faceplate forwards. f Guide the cam [1] of the drive rod of the extension piece into the hole of the drive rod of the multi-point lock.
  • Page 25 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 The extension piece can be cropped up to max. 10 mm over the middle of the fastening hole [1]. f Insert the multi-point lock together with the extension piece into the door leaf. f Mark the cropping position on the extension piece.
  • Page 26: Installing The Multi-Point Lock And Extension Piece

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Installing the multi-point lock and extension piece f Connect the extension piece to the multi-point lock once again. f Insert the multi-point lock together with the extension piece into the door leaf and insert all remaining screws.
  • Page 27: Mounting The Handle Set

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Mounting the handle set Prior to the assembly of the hardware, observe the enclosed assembly instructions of the manufacturer. Compare the drilling template for the hardware with the positions of the fixing holes for the gear box before drilling, see chapter 3.1.4 “Main lock types, key-operated”...
  • Page 28 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 f Fix the cylinder lock with the cylinder lock screw [1]. f Install the handle set according to the enclosed assembly instructions of the manufacturer. 28/44 02.2019 H39.MFVRS006EN-00...
  • Page 29: Milling The Frame

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Milling the frame 4.9.1 Frame milling for BS 2100 BS 2800 Determination of position, see chapter Always use safety goggles for milling The frame parts are horizontally 3.1 “Size variants” from page 10. work.
  • Page 30: Requirements For Skg Certification

    4.10.1 Frame parts and screws PVC frames Security frame part for comfort Frame part with SKR stamp mushroom cam SB S-RS 3SL ... (SIEGENIA) Ø ≥ 4.2 mm 4.10.2 Positioning of the frame parts Maximum interval ≤ 5 mm Maximum interval ≤ 5 mm Minimum interval ≥...
  • Page 31: Assembling The Frame Parts

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.11 Assembling the frame parts 4.11.1 Main lock f Insert the frame part for main lock into the routed pocket of the frame. Use the prescribed screws for SKG certified frame parts (see chapter 4.10 “Requirements for SKG certification”...
  • Page 32: Assembling The Frame Parts For Bs 2100

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.11.2 Assembling the frame parts for BS 2100 Determination of position for A 2100, Determination of position, see chapter see chapter 4.5 “Extension pieces 3.1 “Size variants” from page 10. A 2100, A 2800”...
  • Page 33: Assembling The Frame Parts For Bs 2800

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.12 Assembling the frame parts for BS 2800 Determination of position for A 2800 Determination of position, see chapter see chapter 4.5 “Extension pieces 3.1 “Size variants” from page 10. A 2100, A 2800”...
  • Page 34: Adjustment Of Airgap

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.13 Adjustment of airgap Observe the assembly and operating instructions for the door hinges. f In accordance with the enclosed assembly instructions of the door hinge manufacturer, adjust the airgap [1] between the faceplate and frame part.
  • Page 35: Adjustment Of At Piece

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.13.1 Adjustment of AT piece When the door is closed, the latch must engage in the AT piece with as little play as possible. The AT piece is horizontally adjustable for this purpose. f Shut the door.
  • Page 36 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 2.5 Nm f Tighten the two adjustment screws. f Close the door and check whether the latch engages properly. Repeat the adjustments if necessary. Day latch T 10 The day latch differs from the AT piece by means of a sliding handle [1], releasable fitting part.
  • Page 37: Pressure Control

    • Adjustment in the direction of the frame reduces the compression. *Spanner+allen key (optionally available) Material number (SIEGENIA) 157756 Material description ADJUSTMENT KEY SW4/SW11 Adjustment in the direction of the door leaf f Turn the comfort mushroom cams in the direction of the door leaf.
  • Page 38: Roller Bolt

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.14.2 Roller bolt The roller bolts can be moved up to a millimetre to the right or left to regulate the contact pressure of the door leaf on the frame seal. There is a marking [1] on the roller bolt.
  • Page 39: Functional Test

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.15 Functional test A functional disorder after locking may result in it being impossible to open the door. There is a risk that the door cannot be opened again without damage. Never start the functionality check until the door is open.
  • Page 40 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Locking the locking elements f Turn the key in the locking direction with a double turn. The main lock bolt and the cams must extend into the locking position completely and with ease. Checking the counter-pressure retention f Press back the locking elements...
  • Page 41: Check When The Door Is Closed

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 4.15.2 Check when the door is closed Checking the engaging of the latch f Shut the door. The door must close easily. The latch must engage properly in the AT piece. If the latch does not engage: f Adjust the AT piece in the direction of the door leaf.
  • Page 42 Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Check the engaging of the locking elements f Turn the key in the locking direction with a double turn. The main lock bolt must extend completely and the cams must retract into the frame parts.
  • Page 43: Troubleshooting

    Assembly instructions Multi-point locks, key operated BS 2100, BS 2800 Troubleshooting Functional disorder of the lever handle The lever handle does not return to its original position by itself. f Check that the lever handle is correctly seated. • The lever handle must not have any contact with the rose or the plate or the gear box. f Check the tightening torque of the screwing of the handle set.
