This unit ships from our factory without oil. It must be
properly serviced with fuel and oil before operation.
If you have any questions regarding the assembly of
your generator, call our help line . Please have your
serial number and model number available.

Unboxing

1. Set the shipping carton on a solid, at surface.
2. Remove everything from the carton except the
generator.
3. Using the frame of the unit, carefully remove
the generator from the box. (two people lifting is
recommended)

Connect Battery

1. The Red (+) Connector should be attached to the
battery first.
2.
Remove the screw from the battery terminal.
3.
Place screw through the eyelet and tighten screw.
4. Install the Red protection boot.
Repeat these steps for the Black (-) Terminal.
5.

Add Engine Oil

CAUTION
DO NOT attempt to crank or start the engine before
it has been properly lled with the recommended
type and amount of oil. Damage to the generator as
a result of failure to follow these instructions will
void your warranty.
NOTE
The generator rotor has a sealed, pre-lubricated ball
bearing that requires no additional lubrication for
the life of the bearing.
NOTE
The recommended oil type is 10W-30 automotive oil.
1. Place the generator on a at, level surface.
ASSEMBLY
2. Remove oil ll cap/dipstick to add oil.
3. Add up to 0.6 qt. (0.6 L) of oil (not included) and
replace oil ll cap/dipstick. DO NOT OVERFILL.
4. Check engine oil level daily and add as needed.
NOTE
Once oil has been added, a visual check should show
oil about 1-2 threads from running out of the ll hole.
If using the dipstick to check oil level, DO NOT screw
in the dipstick while checking.
CAUTION
The engine is equipped with a low oil shut-off and
will stop when the oil level in the crankcase falls
below the threshold level.
NOTE
We consider the rst 5 hours of run time to be
the break-in period for the unit. During the break
in period stay at or below 50% of the running
watt rating and vary the load occasionally to allow
stator windings to heat and cool. Adjusting the
load will also cause engine speed to vary and help
seat piston rings. After the 5 hour break-in period,
change the oil.
12
Degrees Celsiusº(Outside)
Full Synthetic 5W-30
Degrees Fahrenheitº(Outside)
