- Page 1 1107 DX Soil Compactor SERVICE MANUAL Part number 47714442 edition English October 2014...
- Page 2 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.106] Valve drive and gears .
- Page 3 [33.110] Parking brake or parking lock ............33.1 Hydraulic systems...............
- Page 4 INTRODUCTION 47714442 06/10/2014...
- Page 5 Contents INTRODUCTION Safety rules ..................3 Safety rules .
-
Page 6: Safety Rules
INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions. - Page 7 NOTICE: Extreme working and environmental conditions require shortened service intervals. Use Case fluids, lubricants, and filters for the best protection and performance of your machine. All fluids, lubricants, and filters must be disposed of in compliance with environmental standards and regulations. Contact your Dealer with any questions regarding the service and maintenance of this machine.
- Page 8 INTRODUCTION Safety rules - Ecology and the environment Soil, air, and water are vital factors of agriculture and life in general. When legislation does not yet rule the treatment of some of the substances required by advanced technology, sound judgment should govern the use and disposal of products of a chemical and petrochemical nature.
- Page 9 SERVICE MANUAL Engine 1107DX 47714442 06/10/2014...
- Page 10 Engine - Engine and crankcase Engine and crankcase - Disassemble - Top Engine 1. Disconnect the battery and store it in a dry place 2. Remove the radiator fan 3. Disconnect wiring from the alternator 4. Remove fan belt. Discard if it is damaged 5.
- Page 11 Engine - Engine and crankcase 2. Disconnect the air delivery pipe with the heat shield from the turbocharger air outlet and air inlet mani- fold 3. Disconnect the exhaust pipe (1) from the tur- bocharger expansion bellow flange and discard the joint 4.
- Page 12 Engine - Engine and crankcase 7. Check turbocharger axial and radial play If play ex- ceeds the recommended limits, recondition the tur- bocharger PTIL14COM1278AA 12. Disconnect and remove the high pressure pipe (1) be- tween fuel pump and injectors. PTIL14COM1280AB PTIL14COM1296AA 13.
