Mains Powered
Ei3030 Multi-Sensor Fire
Alarm & Carbon Monoxide
Instruction Manual
Read and retain carefully for as long as the product is being used. It contains vital
information on the operation and installation of your Alarm. The manual should be
regarded as part of the product.
If you are just installing the unit, the manual MUST be given to the householder. The
manual is to be given to any subsequent user.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ei3030 and is the answer not in the manual?

Questions and answers

Related Manuals for Aico Ei3030

Summary of Contents for Aico Ei3030

  • Page 1 Mains Powered Ei3030 Multi-Sensor Fire Alarm & Carbon Monoxide Instruction Manual Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your Alarm. The manual should be regarded as part of the product.
  • Page 2 Symbol Glossary The symbols on this page are used in accordance with EN 62368-1, IEC 60417, ISO 7000 and other applicable standards. They are used to convey information on the safe and effective use of our devices. These symbols may be used on the device itself, on its packaging or in associated documentation. Symbol Description Symbol...

  • Page 3: Table Of Contents

    Contents Installer Guide 1. Introduction 1.1 Overview 1.2 Technical Specifications 2. Installation 2.1 Important Safety Instructions 2.2 Where to locate the Alarm? 2.3 Where in the room? 2.4 Unsuitable locations 2.5 Mounting and wiring 2.6 Interconnecting Alarms 2.7 Removing the Alarm...
  • Page 4 User Guide 3. What is Carbon Monoxide? 3.1 Symptoms of CO poisoning 3.2 How to protect your family against CO 3.3 How does your Alarm work 4. Testing 4.1 Testing and maintaining your Alarm 4.2 Cleaning your Alarm 5. What to do in case of Fire alarm 6.

  • Page 5: Installer Guide

    Installer Guide Introduction...
  • Page 6 The Ei3030 is a Multi-Sensor Fire & Carbon Monoxide Alarm, detecting smoke, heat and carbon monoxide. It contains a proven optical sensor, with automatic dust compensation, for smouldering fires, as well as an independent fast acting Class A1 Thermistor sensor to detect dangerous levels of heat and an electrochemical CO sensor to detect the presence of abnormal levels of Carbon Monoxide.

  • Page 7: Overview

    1.1 Overview Red LED Alarm Indicator Yellow LED Fault Indicator Smoke Entry Vents Green LED Power Indicator Test / Hush Button Alarm Sounder Alarm Removal Latch Heat Sensor ‘FIRE’ & ‘CO’ (Thermistor) LED Display (normally hidden) RF Module House Code Carbon Monoxide Sensor Entry Holes LED Indicator Button...

  • Page 8: Technical Specifications

    1.2 Technical Specifications Optical Photoelectric Optical Sensor Heat Sensor Thermistor Class A1 detection – Alarm is triggered at 58°C Electrochemical Carbon Monoxide Sensor 100-250V AC, 50Hz, 0.25W Power Supply Built-in 10-year rechargeable Vanadium Pentoxide Lithium cells. Fully charged, the battery will provide up to 6 months (without module fitted) Battery Backup or 3 months (with module fitted) back-up without mains power Piezoelectric Alarm...
  • Page 9 Green LED – Power supply, Test Yellow LED – Fault, EOL Visual indicators Red LED – memory, pre-alarm or alarm (if coincides with alarm sounding) Display Indicates FIRE or CO Up to 12 units can be interconnected via a hardwired or wireless system Interconnection (using optional Ei3000MRF SmartLINK module) Supplied with Easi-fit anti-tamper mounting plate with integral terminal...

  • Page 10: Installation

    Installation...

  • Page 11: Important Safety Instructions

    2.1 Important Safety Instructions WARNING: Mains operated Alarms must be installed and interconnected by a qualified electrician in accordance with the local appropriate Regulations for Electrical Installations. Failure to install this Alarm correctly may expose the user to shock or fire hazards and damage the product. The Alarm is designed to be permanently mounted, using its own built-in terminal block to connect it to the mains power supply.

  • Page 12: Where To Locate The Alarm

    2.2 Where to locate the Alarm Fire Alarms The Ei3030 contains 3 sensors for smoke, heat and CO detection. It is a versatile Alarm that can be placed in most rooms of the house, with the exception of a Shower/Bathroom. Care must also be taken if installing in a kitchen/garage to avoid false alarms due to cooking fumes and contaminants.
  • Page 13 the alarm should be heard throughout the house – particularly in the bedrooms. It is also important that nuisance/false alarms are minimised to ensure the Alarms are not disabled or ignored. A single Alarm will give some protection if it is properly installed, but most homes will require two or more to ensure that a reliable early warning is given.
  • Page 14 Aico/Ei Electronics recommends that an LD1 system be installed for optimum protection. Please see following pages for detailed information. CO Alarms For CO detection, the Ei3030 should be installed in every room containing a fuel burning appliance.
  • Page 15 UK Requirements (BS 5839-6:2019) OPTIMUM PROTECTION for dwellings where occupants may be at high risk (e.g. elderly) for dwel Optimum Protection LD1: As LD2, but in addition Smoke or Heat Alarms should be located in all rooms attic and other areas of the dwelling. (apart from toilets or bathroom) Inte Interconnect all Alarms...

  • Page 16: Where In The Room

    2.3 Where in the room? The locations must comply with applicable building regulations APEX SMOKE / MULTI-SENSOR ALARMS <600mm HEAT ALARMS <150mm Fig.1 Fig.2 - Ceiling Mounting Hot smoke and gases rise and spread out, so a central ceiling position is the preferred location. The air is “dead”...
  • Page 17 - The Alarm should be at a horizontal distance of between 1m and 3m from the potential CO source. - If there is a partition in the room, the Alarm should be located on the same side of the partition as the potential source. The Ei3030 is not suited for wall mounting.

  • Page 18: Unsuitable Locations

    2.4 Unsuitable locations Do not place the Alarm in any of the following areas: • In a bathroom or other areas where the Alarm may be exposed to water splashes, dripping or condensation (e.g. above an electric kettle). • In very high or awkward areas where it may be difficult to reach the Alarm (for testing, hushing etc.) or fit the screwdriver to release the Alarm from its mounting plate.

  • Page 19: Mounting And Wiring

    2.5 Mounting and wiring WARNING: to prevent injury, this apparatus must be securely attached to the ceiling or wall in accordance with the installation instructions. 1. Select a location complying with the advice in previous sections. 2. Disconnect the AC mains supply from the circuit that is going to be used.
  • Page 20 WARNING: Mixing (or poorly terminating) the Live and Neutral connections when interconnecting Alarms may damage all the Alarms - ensure that the same colours are used throughout the premises for Live, Neutral and Interconnect wires. We strongly recommend that you check for the following before connecting the Alarm: •...
  • Page 21 To interconnect Alarms connect all the IC terminals together as shown in Figure 8 (see “Interconnecting Alarms” section). 4. If the mains wires are recessed, bring the wires through the rear hole in the mounting plate as shown in Figure 4. If the mains wires are being brought along the surface: (a) position the mounting plate so the cable trunking is as shown in Figure 4.
  • Page 22 Alarms can then be heard in the distance as they will continue to sound for a further 3 seconds. Note: On initial press the Ei3030 will emit the fire sound pattern. On second press the Ei3030 will emit the CO sound pattern.

  • Page 23: Interconnecting Alarms

    The following is suggested: • In an RF system an Aico Alarm Controller (Ei450) should be incorporated and be readily accessible to all occupants so that the source of an alarm can be quickly identified. This is especially important when both Fire and CO Alarms are used in the same system as the occupant will need to open all windows and doors if it is a CO incident but do the opposite to slow down a fire.
  • Page 24 Make electrical connections as shown in Figure 8. Wiring must be installed in compliance with local regulations. Fig.8 In the UK it is recommended that the following coloured cores are used (for example with triple flat 6243YH cable). 230V supply : Brown Neutral: Grey sleeved blue at terminations Interconnect : Black The interconnect wire (minimum 0.75mm...
  • Page 25 Front Wall Front Wall Fig.9 Orientate all Mounting Plate Mounting Plate mounting plates in the same direction Mounting Plate Mounting Plate Please note in a hybrid system containing Smoke/Heat/CO Alarms we recommend using an Ei3000 Series Alarm as the hybrid link to the RF section of the system. Ensure the Alarms operate correctly - see TESTING YOUR ALARM in the user section.

  • Page 26: Removing The Alarm

    2.7 Removing the Alarm * Disconnect mains before removal * Locate removal slot Insert screwdriver Locate the arrow on the front face of the Alarm Insert a flat-bladed screwdriver horizontally The slot is located directly above the arrow about 10mm into the centre of the removal slot Slide Alarm off mounting plate Remove Alarm With the screwdriver still inserted, push the lower...

  • Page 27: User Guide

    User Guide What is Carbon Monoxide?
  • Page 28 Many people are killed each year, and many more suffer ill health from Carbon Monoxide (CO) poisoning. CO is an invisible, odourless, tasteless and extremely toxic gas. It is produced by appliances and vehicles burning fuels, such as coal, oil, natural/bottled gas, paraffin, wood, petrol, diesel, charcoal etc.

  • Page 29: Symptoms Of Co Poisoning

    3.1 Symptoms of CO poisoning Table A Concentration Inhalation Time (approx) and Symptoms Developed of CO in Air ppm The maximum allowable concentration for continuous exposure in any 8 hour period according to OSHA *. Slight headache after 1.5 hours. Slight headache, fatigue, dizziness, nausea after 2-3 hours.

  • Page 30: How To Protect Your Family Against Co

    3.2 How to protect your family against CO Follow these guidelines to reduce the risk of Carbon Monoxide poisoning. (1) Know and look out for tell-tale signs that Carbon Monoxide may be present. These include: - The Alarm warning of abnormal levels of CO. - Staining, sooting or discolouration on or around appliances.

  • Page 31: How Does Your Alarm Work

    Carbon Monoxide alarm pattern is a repeating cycle of 3 slower sound pulses followed by a pause. On the Ei3030, the LED display will indicate if Fire or CO is detected. The flash rate of the red LED indicator is dependent on the alarm event type, and in the case of CO, on the level detected. Table B shows how...
  • Page 32 Table B - Alarm indicators LED icon Event type Red LED Alarm Fire or CO (Ei3028 only) every sec Flashing FIRE CO Gas Level within every 4 sec Flashing ≥ 50ppm 60-90 mins within CO Gas Level every 4 sec Flashing 10-40 mins ≥...
  • Page 33 Note: In an interconnected system, an Alarm triggered by another Alarm will sound but will not flash its red LED alarm indicator. This means that while the Alarm is sounding, it is not the unit actually sensing the alarm event. If you have an Ei1529RC or Ei450 Alarm Controller installed, press the locate switch to leave just the Alarm that has triggered the system sounding and identify the source and type of the alarm.
  • Page 34 The memory feature has two operation modes: - memory indication for 24 hour period after alarm. - memory recall on demand 24-hour memory indicators: For 24 hours after alarming, the red LED alarm indicator will flash at different rates every 48 seconds (approx) depending on the alarm event type (Fire or CO) and in the case of CO, on the level detected - See Memory Mode table in section 7.
  • Page 35 Alternatively, in an interconnected system fitted with a Control switch, you can identify the source Alarm by pressing the LOCATE switch. When all Alarms are sounding, it will silence all Alarms apart from the Alarm that is sensing Fire/Smoke/Heat/CO. If the source of the alarm is due to carbon monoxide, only use the control switch in line of sight of the CO Alarm to silence it.

  • Page 36: Testing

    Testing...

  • Page 37: Testing And Maintaining Your Alarm

    4.1 Testing and maintaining your Alarm Frequent testing of all your Alarms is a requirement to ensure they are functioning correctly. Guidelines and best practices for testing are as follows: 1. After the system is installed. 2. Once monthly thereafter. 3.
  • Page 38 (iii) Press the test/hush button for up to 10 seconds and ensure that the Alarm sounds. (Note: On initial press the Ei3030 will alarm the fire sound pattern. On second press the Ei3030 will alarm the CO sound pattern). This tests the sensor, electronics and sounder are working. The Alarm will stop when the button is released.

  • Page 39: Cleaning Your Alarm

    The Ei3000MRF modules (if required) must be re-fitted to the Alarms and the Alarms must be re-attached to the mounting plates when the premises are re-occupied. Ensure to match the original RF module back to the same Alarm head. (Long term storage (over 1 year) can damage the batteries such that they will not recharge when the units are re-connected to the mains supply).
  • Page 40 with a clean damp cloth then dry thoroughly with a lint free cloth. Do not use any cleaning agents, bleaches, detergents or polishes, including those in aerosol cans. DO NOT PAINT YOUR ALARM. Other than the cleaning described above, no other customer servicing of this product is required. Servicing or repairs, when needed, must be performed by the manufacturer.

  • Page 41: What To Do In Case Of Fire Alarm

    What to do in case of FIRE?
  • Page 42 WARNING: If your Alarm sounds and you are unsure of the cause, it should be assumed that the alarm is due to an actual fire and the dwelling should be evacuated immediately. (i). Check room doors for heat or smoke. Do not open a hot door. Use an alternate escape route.

  • Page 43: What To Do In Case Of Co Alarm

    What to do in case your Alarm detects Carbon Monoxide?
  • Page 44 Open the doors and windows to ventilate the area (if it is safe to do so). (ii) Turn off all fuel appliances where possible. (iii) Evacuate the property leaving the doors and windows open. (iv) Get medical help immediately for anyone suffering the effects of Carbon Monoxide poisoning (headache, nausea), and advise that Carbon Monoxide poisoning is suspected.

  • Page 45: Indicator Summary Tables & Troubleshooting

    Indicator Summary Tables & Troubleshooting...
  • Page 46 Normal Operation Mode / Action Green LED Yellow LED Red LED Alarm Icon Display Notes (Power) (Fault) (Alarm) FIRE/CO (Ei3028 only) 1 Flash & Power up Standby Testing (pressing Flashing and holding test/hush button) In Alarm Fire sound Detecting Fire Flashing pattern as per...
  • Page 47 Memory mode What you hear / see >24h 0-24h What type of on button test alarm event has occurred Icon Display Red LED Sound Red LED Sound FIRE/CO Flashing every every Fire 48 secs 8 secs Flashing every every CO Gas Level 48 secs 8 secs 50ppm...
  • Page 48 Fault modes and Memory indicator What you hear / see What it What to do Green LED Yellow LED Red LED Chirps means (power) (fault) (alarm) every Reconnect AC AC mains off mains power 48 sec AC mains off every Reconnect AC Low battery mains power...
  • Page 49 The Alarm can communicate its status and history through various Led flashes and chirps/beeps. However, a more comprehensive report of all such events is available through the AudioLINK download via the smart phone App. Low Battery Backup Fault If the battery backup supply is depleted, the sounder will give one short chirp with one yellow LED fault indicator flash every 48 seconds.
  • Page 50 Maximum Dust Compensation The Alarm monitors the dust contamination build-up in the optical smoke chamber and then compensates for it, reducing the possibility of false alarms. If however, the Alarm gives 4 short chirps with 4 yellow LED flashes when the test/hush button is pressed, it indicates that the Alarm has reached the maximum dust compensation.
  • Page 51 Your Alarm does not • Check the Alarm is secured correctly on the mounting plate. sound when you press the • Wait 15 seconds after connecting the power before button testing. test/hush button • Hold button down firmly for at least 10 seconds. •...
  • Page 52 • For CO: - Ensure there are no fuel burning appliances in the vicinity which could be leaking CO gas (e.g. even from next door). - Ensure there are no fumes or aerosols in the area (e.g. paint, thinners, hair spray, chemical cleaners, aerosol sprays, damp proofing done with and aqueous emulsion such as Aminofunctional siloxane and Alkylalkoxysilane) which can cause false CO alarms.
  • Page 53 Interconnected Alarms • Hold test/hush button for 10 seconds after the first alarm has sounded do not all sound to ensure signal is transmitted to all units. • If this is not the case and you have a hardwired interconnection, we recommend you consult a qualified electrician.

  • Page 54: Limitations Of Fire And Co Alarms

    Limitations of Fire and CO Alarms...
  • Page 55 Multi-Sensor Fire and Carbon Monoxide Alarms can significantly help to reduce the risk of fire and CO fatalities. However independent authorities have stated that these systems may be ineffective in some situations. There are a number of reasons for this: •...
  • Page 56 • This Alarm does not detect the presence of natural gas (methane), bottled gas (propane, butane) or other combustible gases. Fit combustion gas alarms to detect these. Note: This Alarm contains an electrochemical sensor which has a cross sensitivity to hydrogen. This means that they can alarm due to sensing hydrogen WARNING: THIS ALARM IS DESIGNED TO PROTECT INDIVIDUALS FROM THE ACUTE EFFECTS OF CARBON MONOXIDE EXPOSURE.

  • Page 57: Important Safeguards

    Important Safeguards...
  • Page 58 When an Alarm system is installed, basic safety precautions should always be followed, including those listed below: • Please read all instructions. • Use the testing of the Alarm as a means to familiarise your family with the alarm sound. Rehearse emergency escape plans so everyone at home knows what to do in case the Alarm sounds.

  • Page 59: Service And Guarantee

    Service and Guarantee...

  • Page 60: Getting Your Alarm Serviced

    10.2 Guarantee Aico guarantees this Alarm for five years from the date of purchase against any defects that are due to faulty materials or workmanship. If this Alarm should become defective within the guarantee period, we shall at our discretion repair or replace the faulty unit.
  • Page 61 Block E1 The crossed out wheelie bin symbol that is on your product indicates that this product should not be disposed of via the normal household waste stream. Proper disposal will prevent possible harm to the environment or to human health. When disposing of this product please separate it from other waste streams to ensure that it can be recycled in an environmentally sound manner.
  • Page 62 KM522831 KM83678 KM86596 EN14604: 2005 + AC 2008 BS 5446-2: 2003 EN50291-1: 2018...
  • Page 63 Ei Electronics, Shannon, Co. Clare, Ireland Ei Electronics, Shannon, Co. Clare, Ireland DoP No. 23-0001 DoP No. 23-0001 EN14604:2005 + AC:2008 Smoke Alarm Devices: Ei3030 Fire Safety Nominal activation conditions/ sensitivity, Vibration resistance Pass Pass response delay (response time) and...
  • Page 64 An Ei Company Aico Oswestry, Shropshire SY10 8NR, U.K. Tel: 01691 664100 www.aico.co.uk P/N B20665 Rev1 © Ei Electronics 2023...
