Audio-Technica ATH-M50xSTS-USB - Streaming Headset Manual

Part names and functions

Headset

1. L/R (left/right) indicator
2. Earpad
3. Headband
4. Slider
5. Joint
6. Arm
7. Housing
8. Monitor dial
9. Microphone
10. USB plug (USB Type-A)

Accessories

1. USB conversion adapter (USB Type-A to USB Type-C^™)
2. Earpads

At the time of purchase, the earpads that are made of mesh material with excellent air permeability for increased comfort are attached to the headset.

Earpads
There are two types of earpads for this product. Use the product for whichever of these purposes suits your needs.

Wearing the product

Put the side of the product marked "L" (LEFT) onto the left ear and the side marked "R" (RIGHT) onto the right ear, slide the slider up and down so that the earpads cover the ears, and then adjust the headband.

Swivel mechanism

You can fold the housing so that it lies flat.

• The swivel mechanism cannot rotate more than 90 degrees. Do not apply excessive force.

  Joint

Compact folding

You can fold the housing into the inner side of the headband using the joints at the fulcrum.

• Be careful so as not to get your fingers caught in the joints.
• When using the product, make sure to return the housings to their original positions.

  Joint

Using the product

1. Lower the volume on the computer you intend to use, then connect the cable to the USB port on the computer.
   • When connecting to a USB Type-C port, use the included USB conversion adapter (USB Type-A to USB Type-C).
   • The computer will automatically recognize the product and install the driver.


2. Place the product with the side marked "L" on your left ear and the side marked "R" on your right ear, and adjust the headband length by sliding the slider.
3. Adjust the microphone near the corner of your mouth.
4. Operate the computer to adjust volume as necessary.
   • Read the user manual for the computer.

Computer settings

Windows 11 / Windows 10

1. Open the Start Menu and click "Settings".
2. Click "System".
3. Click "Sound".
4. In "Output" and "Input", confirm that "ATH-M50xSTS-USB" is selected.
   • If the product is not selected, select the product.

Depending on the app or software being used, it may be necessary to switch the output and input for that app or software to this product.

macOS

1. Click the Apple icon and select "System Preferences".
2. Click "Sound".
3. In "Output" and "Input", confirm that "ATH-M50xSTS-USB" is selected.
   • If the product is not selected, select the product.

Depending on the app or software being used, it may be necessary to switch the output and input for that app or software to this product.

Muting the microphone

1. Moving the microphone up mutes the microphone.
   • To unmute, move the microphone down.


Monitoring your voice

1. You can check the sound of your voice during use by pressing the monitor dial.
   • Each time the monitor dial is pressed, it switches between ON and OFF.
   • Tilt the monitor dial to the left or right to adjust the volume of your voice.


Cleaning

Get into the habit of regularly cleaning the product to ensure that it will last for a long time. Do not use alcohol, paint thinners, or other solvents for cleaning purposes.

• Use a dry cloth to clean the headphones and the in-line controller.
• Wipe away any perspiration or dirt from the cable with a dry cloth immediately after use. Failure to clean the cable may cause it to deteriorate and harden over time, resulting in malfunction.
• Wipe the cable plug with a dry cloth if dirty. Failure to clean the plug may cause sound skipping or noise.
• To clean the earpads and headband, wipe with a dry cloth. Earpads and headband may fade if sweat or water dries on them. If the earpads and headband get wet, we recommend wiping them with a dry cloth and allowing them to dry in the shade.

• If the product will not be used for an extended period of time, store it in a well-ventilated place free from high temperatures and humidity.
• Earpads are consumable parts. The earpads deteriorate over time due to use or storage. Contact your local Audio-Technica dealer for earpad replacement or other repairs.

Specifications

Headphones

Microphone

Communication specifications

Other

• For product improvement, the product is subject to modification without notice.
