- Page 1 ATH-M50xSTS-USB Streaming Headset User Manual English...
-
Page 2: Safety Precautions
Safety precautions Follow applicable laws regarding mobile phone and headphone use if using headphones while driving. Do not use the product in places where the inability to hear ambient sound presents a serious risk (such as at railroad crossings, train stations, and construction sites). To prevent damage to your hearing, do not raise the volume too high. -
Page 3: Notes On Use
Notes on use Be sure to read the connected device’s user manual before use. Audio-Technica will not be liable in any way for any loss of data in the unlikely event that such losses should occur while using the product. On public transportation or in other public places, keep the volume low so as not to disturb other people. -
Page 4: Part Names And Functions
Part names and functions Headset L/R (left/right) indicator Earpad Headband Slider Joint Housing Monitor dial Microphone USB plug (USB Type-A) - Page 5 Part names and functions Accessories ™ USB conversion adapter (USB Type-A to USB Type-C Earpads At the time of purchase, the earpads that are made of mesh material with excellent air permeability for increased comfort are attached to the headset. Earpads There are two types of earpads for this product.
-
Page 6: Wearing The Product
Wearing the product Put the side of the product marked “L” (LEFT) onto the left ear and the side marked “R” (RIGHT) onto the right ear, slide the slider up and down so that the earpads cover the ears, and then adjust the headband. Swivel mechanism You can fold the housing so that it lies flat. - Page 7 Wearing the product Joint...
-
Page 8: Using The Product
Using the product Lower the volume on the computer you intend to use, then connect the cable to the USB port on the computer. When connecting to a USB Type-C port, use the included USB conversion adapter (USB Type-A to USB Type- The computer will automatically recognize the product and install the driver. -
Page 9: Computer Settings
Click “System”. Click “Sound”. In “Output” and “Input”, confirm that “ATH-M50xSTS-USB” is selected. If the product is not selected, select the product. Depending on the app or software being used, it may be necessary to switch the output and input for that app or software to this product. - Page 10 Using the product Monitoring your voice You can check the sound of your voice during use by pressing the monitor dial. Each time the monitor dial is pressed, it switches between ON and OFF. Tilt the monitor dial to the left or right to adjust the volume of your voice.
- Page 11 Cleaning Get into the habit of regularly cleaning the product to ensure that it will last for a long time. Do not use alcohol, paint thinners, or other solvents for cleaning purposes. Use a dry cloth to clean the headphones and the in-line controller. Wipe away any perspiration or dirt from the cable with a dry cloth immediately after use.
-
Page 12: Communication Specifications
Specifications Headphones Type Closed-back dynamic Driver 45 mm Sensitivity 99 dB/mW Frequency response 15 to 28,000 Hz 1,600 mW Maximum input power Impedance 38 ohms Microphone Type Back electret condenser Unidirectional Polar pattern Frequency response 50 to 20,000 Hz (at 3 cm) Communication specifications System operation USB 2.0 compliant... - Page 13 Trademarks ™ USB Type-C is a trademark of USB Implementers Forum. ® ® Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft Windows operating system is indicated in its abbreviated form as Windows. Mac and macOS are trademarks of Apple Inc., registered in the U.S.
- Page 14 株式会社オーディオテクニカ 〒194-8666 東京都町田市西成瀬2-46-1 www.audio-technica.co.jp Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2023 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 382908160-02-01 ver.1 2023.02.15...
