Operation; Power On/Off - Lippert Components OneControl Touch Panel 3.0 OCTP Owner's Manual

Operation

The OneControl Touch Panel (OCTP) uses a touch screen (Fig. 1) as the input device to interface with the
Lippert CAN bus system.
This manual will cover all possible operation and controls of the OCTP, but not all units will have the
same control or systems monitoring. Control and monitoring is dependent on the Lippert control that is
connected to the OCTP and any Lippert OneControl compatible accessories added.

Power On/Off

When the unit's battery disconnect is turned on and power is supplied, the OCTP may start up on its own
depending on how it was previously powered down. If the OCTP was shut down by the user via the power
button (Fig. 1A), then it will not automatically start up at this point.
The device may be powered on or off using the power button (Fig. 1A) located on the bottom of the device.
1. To turn the OCTP on, press and release the power button (Fig. 1A).
NOTE: It will take a few moments to start up and load the system.
2. To turn off the OCTP press and hold the power button (Fig. 1A) .
Rev: 03.30.23
Fig. 1
A
Page 4
CCD-0007179
