STREET WISE SWAAB30 Instructions

2
1
1.
LED Flashlight
2.
Stun Probes
3.
Indicator Lights- Flashlight or Off: Green
Light Only. Stun Mode: Red and Green
4.
Stun Activation Button
IMPORTANT: Before using we recommend that you take time to familiarize yourself with this unit. The key to
understanding how it operates is the "Function-Select Button (5)." Each time this button is pressed, the function changes
in the following order: Light, Stun, Off. To help you remember the order, the corresponding symbol is shown below the
Function-Select Button:

ADJUSTING THE STUN BATON

Note: The baton can be adjusted up to 19 inches long
1. With the handle in your right hand and the top half of the baton in your left, twist the handle slightly until you feel it loosen.
2. Twist the part of the stun baton labeled "Twist Lock". Twisting all the way will lock it back into place. Move the top up or down until you
reach your desired length; it will stop when it reaches the maximum length.
3. Twist the handle and the top half of the baton in the opposite direction to lock in place.

RECHARGING

1. The batteries charge while inside the unit and they are already installed so there is no need to remove them unless you want to replace the
rechargeable batteries. To access the batteries, turn the bottom of the handle counter clock wise.
2. We recommend charging the stun baton before it is used. To charge, fully press the Push-Button Tail Switch to turn on the unit. The
standby indicator light on the baton will turn green. Plug the charging cord into the Charging Port (6) in the middle of the baton and plug the
other end into a standard outlet. A red light on the base of the charger will illuminate while the unit is charging and then turn green when
fully charged. Charge for 8 hours. Then unplug the unit from the charging cord. IMPORTANT: do not charge for more than 8 hours at a
time. Overcharging can damage the unit and void the warranty. When used infrequently the unit will need to be recharged for 8 hours every
60 days. If the flashlight is used frequently or if the electrical current or flashlight becomes noticeably weaker, the unit will need to be
recharged.

USING THE FLASHLIGHT

Overview: This unit features three light strengths (Maximum, Medium, & Low) and two light patterns (SOS & Strobe). When the situation does
not require maximum light strength, the lower light settings can be used to extend the battery life.
1. Fully press
the Push-Button Tail Switch to turn on the unit. You will hear the button click and the green LED or the red and green LED will
1
come on indicating that the power to the unit is on. It will be in the same mode (LIGHT, STUN, or OFF) that it was in when it was turned off.
If only the green LED is on and you see the flashlight, you are in LIGHT mode. If only the green LED is on and you do not see the
flashlight, you are in OFF mode. If the green and red LED lights are on, you are in STUN mode. If you press the Push-Button Tail Switch
and the flashlight does not turn on see #3 below.
2. Once the flashlight turns on you can change the light mode by Half Pressing either the Push-Button Tail Switch or the Function-Select
Button. If you press either of these buttons too hard you will hear a click and the flashlight will turn off.
3. If you press the Push-Button Tail Switch and the flashlight does not turn on, then the Function-Select Button is either set to Stun or OFF
mode. If both the green and red LED lights are on, then it is in Stun mode. Fully press
mode. If only the green light is on, but the flashlight is not, it is in the OFF mode. Fully press
Light mode. To change the Light mode, see #2 above.
4. To turn off the light, fully press
5. If you turn the light off by fully pressing
off by fully pressing the Function-Select Button, be careful to note that you are now in stun mode (red light will be ON) and pressing the
1
Full Press: When fully pressed, you will hear a clicking sound.
1
SWAAB30 Instructions
8
for LIGHT, for STUN, and
either the Function-Select Button or the Push-Button Tail Switch.
1
the Push-Button Tail Switch, you will need to press this same button again to turn it on. If you turn it
1
3 4
6 5
5. Function- Select Button (Light, Stun, OFF)
6. Charging Port (Backside-Not Shown)
7. Push-Button Tail Switch (Not Shown):
1
a. Full Press turns unit ON/OFF.
b. Half Press changes light model
8. Twist Lock
for OFF.
the Function-Select Button two times to get to Light
1
the Function-Select Button one time to get to
1
7
Rev 04/2023
