STREET WISE SWTD27 Instruction Manual

Charging the SWTD27

1. Plug the charger into a standard wall outlet. Insert the included 18650 batteries into the charger following the polarity diagram.
2. We recommend charging the Triple Defender before it is used. A red light on the base of the charger will illuminate while the unit is charging and then
turn green when fully charged. Remove the batteries from the charger when fully charged. Then unplug the charger. IMPORTANT: do not charge for
more than 8 hours at a time. Overcharging can damage the batteries and void the warranty. If used infrequently the unit will need to be recharged for
8 hours every 60 days. If the flashlight is used frequently or if the electrical current or flashlight becomes noticeably weaker, the unit will need to be
recharged.

Using the Flashlight

Overview: This unit features three (3) light strengths (Maximum, Medium, & Low) and two light patterns (SOS & Strobe). When the situation does not require
maximum light strength, the lower light settings can be used to extend the battery life.
1. Fully press the Push-Button Tail Switch to turn on the unit. You will hear the button click and the green LED or the red and green LED will come on indicating
1
that the power to the unit is on. It will be in the same mode (LIGHT, STUN, or OFF) that it was in when it was turned off. If only the green LED is on and you
see the flashlight, you are in LIGHT mode. If the green and red LED lights are on, you are in STUN mode. If only the green LED is on and you do not see
the flashlight, you are in STANDBY mode. If you press the Push-Button Tail Switch and the flashlight does not turn on see #3 below.
2. Once the flashlight turns on you can change the light mode by Half Pressing either the Push-Button Tail Switch or the Function-Select Switch. If you press
either of these buttons too hard you will hear a click and the flashlight will turn off.
3. If you press the Push-Button Tail Switch and the flashlight does not turn on, then the Function-Select Switch is either set to STUN or OFF mode. If both the
green and red LED lights are on, then it is in STUN mode. Push the Function-Select Switch forward to get to LIGHT mode. If only the green light is on, but
the flashlight is not, it is in the STANDBY mode. Push the Function-Select Switch forward again to get to LIGHT mode. To change the Light mode, see #2
above.
4. To turn off the light, fully press
5. If you turn the light off by fully pressing

Testing the Stun Baton

(WARNING: Do not test fire the stun baton for more than 1 second as this could damage the unit and void the warranty.)
1. Fully press 1 the Push-Button Tail Switch to turn on the unit. If both the red and green LED lights turn on it is in STUN mode and ready to test the stun baton.
Go to #3 below. If only the green LED is on and the flashlight is on, it is in LIGHT mode. Slide the Function-Select Switch down until it is in the lowest position;
the red LED indicates the unit is in STUN mode.
1 Full Press: When fully pressed, you will hear a clicking sound.
Instruction Manual
Push-Button Tail Switch or slide the Function-Select Switch back to the STANDBY setting.
1
1 the Push-Button Tail Switch, you will need to press this same button again to turn it on.
SWTD27
Revised: 06-30-2017
