STREET WISE SWPFTB9R Instruction Manual

Triple Stun
Contact Probes
STOP.
Before Proceeding, Please Read: This stun baton flashlight performs many functions and has built in safety
features that can be confusing if you do not take time to read these directions and familiarize yourself with it. The key to
understanding how this unit operates is the "Function-Select Button." Each time this button is pressed, the function
changes in the following order: Light, Stun, Off. To help you remember the order, the corresponding symbol is shown
below the Function-Select Button:

Recharging

1. The rechargeable batteries are already installed. The unit cannot be opened, as this will void the warranty.
2. We recommend charging the stun baton before it is used. Simply plug the charging cord into the bottom of the unit and into a
standard outlet. A green light will come on while the unit is charging. IMPORTANT: do not charge for more than 8 hours at a
time. Overcharging can damage the unit and void the warranty. Under normal use the unit will need to be recharged for 8
hours every 60 days. If the LED flashlight is used frequently or if the electrical current becomes noticeably weaker, the unit will
need to be recharged.

Using the Flashlight

Overview: This unit features three light strengths (Maximum, Medium, & Low) and two light patterns (Strobe & SOS). When the
situation does not require maximum light strength, the lower light settings can be used to conserve battery strength. Note that the
ON/OFF Safety Switch on the bottom of unit only affects the stun mode so the light will work when this switch is set to either on or
off.
1. Press the Function-Select Button until you see the flashlight turn on (remember there are three functions in the following
order: Light, Stun, & Off).
2. Once the light is on you can change the light mode by half pressing the Function-Select Button. The light mode will change in
the following order: Maximum, Medium, Low, Strobe, SOS. Warning: if you fully press the Function-Select Button the light
will turn off and you will be in the Stun Mode. In this mode pressing the Stun Activation Button will discharge the stun gun (if
the ON/OFF switch is set to ON).
3. To turn off the light, fully press
Function, pressing once moves the function to Stun, pressing twice moves it to Off and pressing a third time moves it back to
Light.
Testing the Stun Baton (WARNING: Do not test fire the stun baton for more than 1 second as this will damage the unit and void
the warranty.)
1. Slide the on/off switch on the bottom of the unit to the "ON" position.
2. Press the Function-Select Button until you are in the Stun Function (Remember there are three functions- Light, Stun, & Off)
3. The easiest way to locate the Stun Function is to fully press
Full Press: When fully pressed, you will hear a clicking sound.
1
SWPFTB9R
Instruction Manual
Stun Activation Button
for Light, for stun, and
the Function-Select Button. Remember the order of the functions: When in light Light
1
Function-Select Button
(Light, Stun, Off)
Attached Belt Clip
(Not Shown)
for off.
the Function-Select Button until you see the flashlight turn on.
1
Charging Port
(Not Shown)
ON/ OFF Safety Switch
(Not Shown):
Revised 03/21/2014
