AirMetER-DX
PARTICULATE SENSOR
MODULE REMOVAL &
REPLACEMENT GUIDE
Revision | May 2023
Air-Met Scientific

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirMetER-DX and is the answer not in the manual?

Questions and answers

Related Manuals for airmet AirMetER-DX

Summary of Contents for airmet AirMetER-DX

  • Page 1 AirMetER-DX PARTICULATE SENSOR MODULE REMOVAL & REPLACEMENT GUIDE Revision | May 2023 Air-Met Scientific...
  • Page 2 Do not use a power drill on the particulate sensor module • screws as this may cause damage to the instrument. Ensure that the AirMetER-DX is switched off and • disconnected from any power source while removing and replacing the particulate sensor module.
  • Page 3 PARTICULATE SENSOR MODULE REMOVAL & REPLACEMENT Remove the outlet tubing from the particulate sensor module by twisting the luer fitting anticlockwise. Using a 2mm allen key, loosen the grub screw to ensure that the heated inlet can slide to assist with step 3.
  • Page 4 PARTICULATE SENSOR MODULE REMOVAL & REPLACEMENT Unplug the tube adapter from the heated inlet by compressing the orange section inwards. This will release the tube adapter. Slide the heated inlet upward until there is a gap between the heated inlet and tube adaptor. Remove the four screws from the top and bottom of the particulate sensor module.
  • Page 5 PARTICULATE SENSOR MODULE REMOVAL & REPLACEMENT Unplug the ethernet and power supply cables from the particulate sensor module PCB. When replacing the particulate sensor module, complete these steps in reverse. To confirm that the instrument is not leaking after the particulate sensor module replacement, check that the flow rate is still within the required range before covering the inlet with a finger.
  • Page 6 If you have any questions or require troubleshooting while using this guide, our team are here to assist you. Please feel free to contact us at any of the following means: 1800 000 744 engineeredsolutions@airmet.com.au www.airmet.com.au CONTACT US Alternatively, scan the QR code to locate your nearest Air-Met Scientific office.
