Page 1: Table Of Contents
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. Published by WS 0763 BG CD Customer Service...
Page 2: Technical Specifications, Connections, And Chassis Overview
EN 2 BJ3.1E LA Technical Specifications, Connections, and Chassis Overview 1. Technical Specifications, Connections, and Chassis Overview Index of this chapter: 1.1.3 Multimedia 1.1 Technical Specifications 1.2 Connection Overview USB input : USB2.0 (480 Mbps) 1.3 Chassis Overview Supported formats...
Page 3 Technical Specifications, Connections, and Chassis Overview BJ3.1E LA EN 3 Connection Overview 1) ONLY FOR DIGITAL SETS G_16850_002.eps 110107 Figure 1-1 Side and rear I/O connections Note: The following connector colour abbreviations are used HDMI 1 & 2: Digital Video, Digital Audio - In (acc.
Page 4 EN 4 BJ3.1E LA Technical Specifications, Connections, and Chassis Overview EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out EXT2: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out - Audio R 0.5 V / 1 kohm - Audio R 0.5 V...
Page 5 Technical Specifications, Connections, and Chassis Overview BJ3.1E LA EN 5 MAIN SUPPLY PANEL AUDIO PANEL EXTERNAL I/O PANEL CONTROL BOARD SIDE I/O PANEL SMALL SIGNAL BOARD LED PANEL G_16851_001.eps 060307 Figure 1-6 PWB/CBA locations (37-inch models) STANDBY/AUDIO MAIN SUPPLY PANEL...
Page 6: Safety Instructions, Warnings, And Notes
• Be careful during measurements in the high voltage • Use only lead-free soldering tin Philips SAC305 with order section. code 0622 149 00106. If lead-free solder paste is required, • Never replace modules or other components while the unit please contact the manufacturer of your soldering is switched "on".
Page 7: Directions For Use
2006 week 17). The 6 last digits contain the reduce heat. serial number. • Mix of lead-free soldering tin/parts with leaded soldering tin/parts is possible but PHILIPS recommends strongly to MADE IN BELGIUM MODEL 32PF9968/10 avoid mixed regimes. If this cannot be avoided, carefully 220-240V 50/60Hz clear the solder-joint from old tin and re-solder with new tin.
Page 8: Mechanical Instructions
EN 8 BJ3.1E LA Mechanical Instructions 4. Mechanical Instructions Index of this chapter: Notes: 4.1 Cable Dressing • Figures below can deviate slightly from the actual situation, 4.2 Service Positions due to the different set executions. 4.3 Assy/Panel Removal •...
Page 9 Mechanical Instructions BJ3.1E LA EN 9 G_16851_003.eps 060307 Figure 4-2 Cable dressing (37-inch models) G_16851_004.eps 060307 Figure 4-3 Cable dressing (42-inch models)
Page 10 EN 10 BJ3.1E LA Mechanical Instructions Service Positions Assy/Panel Removal For easy servicing of this set, there are a few possibilities 4.3.1 Rear Cover created: • The buffers from the packaging. Warning: Disconnect the mains power cord before you remove •...
Page 11 Mechanical Instructions BJ3.1E LA EN 11 4.3.4 IR & LED Board Speaker box (for 37” and 42” models) 1. Refer to next figure. 2. Unplug connectors [1]. 1. Refer to next figure. 3. Remove screws [2]. 2. Unplug connector [1].
Page 12 EN 12 BJ3.1E LA Mechanical Instructions 4.3.7 Small Signal Board (SSB) and External I/O Panel Caution: it is absolutely mandatory to remount all different 2. Disconnect the mains power supply cable on the Main screws at their original position during re-assembly. Failure to Supply Panel [2].
Page 13 Mechanical Instructions BJ3.1E LA EN 13 4.3.10 LCD Panel This depends on the model/screen size: for the 32” models, quite some panels must be removed to get access to the LCD fixation screws, while for the larger models this is hardly necessary.
Page 14 EN 14 BJ3.1E LA Mechanical Instructions LCD 37” models 1. Unplug the connectors [1] from the LCD Inverters, the loudspeakers, the LED/IR board, the Keyboard Control board, and (carefully) from the LVDS connector on the display. 2. Remove the speaker boxes [2], to get access to the screws that hold the lower side of the metal sub-frame.
Page 15 Mechanical Instructions BJ3.1E LA EN 15 LCD 42” models 1. Unplug the connectors [1] from the LCD Inverters, the loudspeakers, the LED/IR board, the Keyboard Control board, and (carefully) from the LVDS connector on the display. 2. Remove the speaker boxes [2], to get access to the screws that hold the lower side of the metal sub-frame.
Page 16: Service Modes, Error Codes, And Fault Finding
EN 16 BJ3.1E LA Service Modes, Error Codes, and Fault Finding 5. Service Modes, Error Codes, and Fault Finding Index of this chapter: Specifications 5.1 Test Points 5.2 Service Modes Table 5-1 SDM default settings 5.3 Stepwise Start-up 5.4 Service Tools Default 5.5 Error Codes...
Page 17 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 17 be re-written to NVM. ComPair will foresee in a possibility to do this. • Operation Hours. Displays the accumulated total of operation hours (not the stand-by hours). Every time the TV is switched "on/off", 0.5 hours is added to this number.
Page 18 EN 18 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Display Display type Brand SIZE Full Clear LCD Resolution Resolution Type number 12 NC option vertical horizontal 768p 1024 S42AX-YD01(PP42AX-007A) 9322 225 38682 768p 1366 S50HW-XD03 9322 215 26682...
Page 19 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 19 Display Display type Brand SIZE Full Clear LCD Resolution Resolution Type number 12 NC option vertical horizontal reserved reserved 1080p 1920 S63HW-YD02 (W2) under development 768p 1366 T260XW03V1 under development...
Page 20 EN 20 BJ3.1E LA Service Modes, Error Codes, and Fault Finding 5.2.3 Customer Service Mode (CSM) values are “Off”, “Minimum” and “Maximum”. See DFU on how to change this item. • Pixel Plus. Gives the last status of the Pixel Plus setting, Purpose as set by the customer.
Page 21 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 21 are fixed. So for a customer location must be set to “Home”. Can be changed via the installation menu (see also DFU). • HDMI key validity. Indicates if the HDMI keys (or HDCP keys) are valid or not.
Page 22 EN 22 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Stepwise Start-up When the TV is in protection state due to an error detected by main software (Viper protection) and SDM is activated via shortcutting the pins on the SSB, the TV starts up and ignores The stepwise start-up method, as known from FTL/FTP sets the error.
Page 23 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 23 Stand by or Protection Mains is applied action holder: MIPS Standby Supply starts running. +5V2, 1V2Stb, 3V3Stb and +2V5D become present. action holder: St-by In case of PDP 3V3 Vpr to CPU PDP becomes present.
Page 24 EN 24 BJ3.1E LA Service Modes, Error Codes, and Fault Finding From part A From part A From part A From part A action holder: MIPS activate +8V6 supply +8V6 error action holder: St-by detection algorithm Start polling the detect-1V2 every 40ms...
Page 25 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 25 From part A From part B From part B From part B action holder: MIPS action holder: St-by Flash to Ram image transfer succeeded within 30s? autonomous action Code = 5...
Page 26 EN 26 BJ3.1E LA Service Modes, Error Codes, and Fault Finding LCD LPL 26" WX2- SLB2 / 32 "W01- SL06 / 37"WX1- SL04 / 42"WU02-SLB1 / 42" WX3- SLA1 / 42” WX2-SLA1 / 47” WU1-SLC2 Constraints taken into account: - Display may only be started when valid QVCP output clock can be delivered by the Viper.
Page 27 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 27 LCD LPL [26"SLB2 / 32"SL06 / 37"SL04 / 42"SLB1 / 42"SLA1] or LCD AUO [26"/32" XW02 V4/V5] / 47” WU1-SLC2 action holder: MIPS Active action holder: St-by autonomous action Mute all sound outputs.
Page 28 EN 28 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Semi Stand by action holder: MIPS action holder: St-by Delay transition until ramping down of ambient light is finished. *) autonomous action *) If this is not performed and the set is...
Page 29 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 29 Semi Stand by action holder: MIPS action holder: St-by autonomous action Reboot Power-down HDMI and 1394 hardware by keeping POWERDOWN-1394 GPIO 0 line high. Set Viper HW blocks (TM1, TM2, MBS, VMSP1 and VMSP2) to powerdown mode.
Page 30 EN 30 BJ3.1E LA Service Modes, Error Codes, and Fault Finding POD stand by Switch ON all supplies by switching LOW the ON-MODE I/O line. Full SSB power and the display related supplies become available +8V6 detected within +8V6 error...
Page 31 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 31 action holder: MIPS transfer Wake up reasons to the Stand by µP. action holder: St-by autonomous action Images are re-transferred to DDR-RAM from Flash RAM (verification through checksum) MIPS image completes the application reload, stops DDR-RAM access, puts itself in a sleepmode and signals the standby µP when the...
Page 32 EN 32 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Log the appropriate error and action holder: MIPS set stand-by flag in NVM action holder: St-by Redefine wake up reasons for protection autonomous action state and transfer to stand-by µP.
Page 33 Introduction whether the Small Signal Board (SSB) or the display of a Flat ComPair (Computer Aided Repair) is a Service tool for Philips TV is defective. Thus to determine if LVDS, RGB, and sync Consumer Electronics products. and offers the following: signals are okay.
Page 34 EN 34 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Error Codes • On screen via the SAM (only if you have a picture). E.g.: – 00 00 00 00 00: No errors detected – 06 00 00 00 00: Error code 6 is the last and only 5.5.1...
Page 35 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 35 Extra Info is logged in the NVM (that’s why this error is still mentioned • Rebooting. When a TV is constantly rebooting due to here). internal problems, most of the time no errors will be logged •...
Page 36 EN 36 BJ3.1E LA Service Modes, Error Codes, and Fault Finding 5. 1 long blink of 3 s to finish the sequence, 6. The sequence starts again. 5.6.2 How to Activate Use one of the following methods: • Activate the SDM. The blinking front LED will show the entire contents of the error buffer (this works in “normal...
Page 37 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 37 Fault Finding and Repair Tips Read also paragraph “Error Codes” - “Extra Info”. Defective FTV For an explanation of the numbers, refer to the foot notes (on the next page)
Page 38 EN 38 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Foot notes for figure “General fault find tree [1/2]”: PSU (OVP). What about the relay on the PSU? If no 1. Observe set behaviour when connecting to mains, and reaction from PSU, check fuses, Standby Supply …….
Page 39 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 39 32" LCD Power supply start-up behaviour Power Supply Check Mains cord is connected LED is on? Check if vacation switch is closed Red LED is on +5V2 is ok.
Page 40 EN 40 BJ3.1E LA Service Modes, Error Codes, and Fault Finding 37" LCD Power Supply Start-up Behaviour Power Supply Check Mains cord is connected LED is on? Check if vacation switch is closed Red LED is on and +5V2 is ok.
Page 41 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 41 5.8.1 Exit “Factory Mode” used. In normal operation mode the value of this supply voltage will be close to +2V5 (20..30 mV difference). • The supply voltages +5V and +8V6 are available from When an "F"...
Page 42 1. Disconnect the TV from the Mains/AC Power. 4. Check in CSM if the HDMI keys are valid. 2. Press the "OK" button on a Philips DVD RC-6 remote control (it is also possible to use the TV remote in "DVD"...
Page 43 Service Modes, Error Codes, and Fault Finding BJ3.1E LA EN 43 Upgrade via PC and ComPair interface It will be possible to upgrade the Stand-by software via a PC and the ComPair interface. Check paragraph "ComPair" on how to connect the interface. To upgrade the Stand-by software, use the following steps: 1.
Page 44 EN 44 BJ3.1E LA Service Modes, Error Codes, and Fault Finding Personal Notes: E_06532_012.eps 131004...
Page 45: Block Diagrams, Test Point Overviews, And
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA 6. Block Diagrams, Test Point Overviews, and Waveforms Wiring Diagram 32” ME7 WIRING 32” (STYLING ME7) 8305 8306 8735 8364 1M02 8317 1736 1735 MAIN SUPPLY STANDBY / AUDIO INVERTER INVERTER...
Page 46 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Wiring Diagram 37” ME7 WIRING 37” (STYLING ME7) 8320 8319 8302 8146 8103 LCD DISPLAY 1M02 MAIN SUPPLY LVDS 8736 8735 INVERTER INVERTER 1735 1736 AUDIO AMPL 8150 1M52 8152 8201...
Page 47 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Wiring Diagram 42” ME7 WIRING 42” (STYLING ME7) 8319 8309 8420 8303 8302 8304 8307 8406 8306 LCD DISPLAY 8316 1M02 8146 8103 LVDS STANDBY / AUDIO MAIN SUPPLY INVERTER INVERTER...
Page 48: Block Diagram Supply 32
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Supply 32” SUPPLY 32" LCD MAINS FILTER + STANDBY SUPPLY CONNECTIONS HOT GROUND COLD GROUND 7002 TCET1102 3100 1308 5401 7030 1450 5403 1400 BIAS SUPPLY 3000 3031 DC_PROT...
Page 49 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Supply 37” SUPPLY 37" LCD DISPLAY SUPPLY: PART1 DISPLY SUPPLY: PART2 DISPLAY SUPPLY: PART1 VAC-L 7002 TCET1102 VAC-N 3100 BIAS SUPPLY 5401 5403 1308 7030 5405 1450 1400 3810...
Page 50 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Supply 42” SUPPLY 42" MAINS FILTER + STANDBY PART A SUPPLY PART A CONNECTIONS 3028 7002 7030 DC_PROT TCET1102 1316 DC_PROT 5400 5401 1308 5403 1450 1400 BIAS SUPPLY...
Page 51: Block Diagram Video
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Video VIDEO DVB-T: TUNER MPIF MAIN: PNX2015: VIPER: VIPER: MAIN MEMORY 7C00 7J00 7V00 PNX3000HL 7V01 PNX2015E PNX8550 K4H561638F 1T05 1C52 TUNNELBUS TD1316AF VIFINP PNX2015 DDR INTERFACE 9T19 2C84...
Page 52: Block Diagram Audio
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Audio AUDIO DVB-T: TUNER MPIF MAIN: AUDIO LEFT RIGHT PROTECTION / MPIF MAIN: AUDIO SOURCE SELECTION PNX2015 MPIF MAIN: AUDIO AMPLIFIER CONNECTIONS B MUTE CONTROL 7C00 7J00 1M02 PNX3000HL...
Page 53: Block Diagram Control & Clock Signals
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Block Diagram Control & Clock Signals CONTROL & CLOCK SIGNALS VIPER: CONTROL USB 2.0: HOST VIPER: A/V + TUNNELBUS PNX2015: DV I/O INTERFACE PACIFIC3: PART 2 7N00 7V00 7G04 ISP1561BM PNX8550EH...
Page 54: Test Points Ssb Top And Bottom Side
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB (Top Side) I137 A2 IJ20 C1 I156 A2 IJ29 C3 I548 E4 IJ36 C3 I549 E4 IJ36 C3 I550 E4 IJ37 C3 I551 G2 IK95 B3 I552 D2...
Page 55 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB Part 1 (Top Side) Part 1 G_15960_055ta.eps 310306...
Page 56 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB Part 2 (Top Side) Part 2 G_15960_055tb.eps 310306...
Page 57 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB (Bottom Side) F181 E4 F284 G4 FB22 C1 FLB7 C2 FU01 G4 I157 A2 I260 G4 I363 F1 I466 C4 IA28 B3 IH13 E2 IK87 A2 IP29 G1...
Page 58 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB Part 1 (Bottom Side) Part 1 G_15960_056ta.eps 310306...
Page 59 Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Test Point Overview SSB Part 2 (Bottom Side) Part 2 G_15960_056tb.eps 310306...
Page 60: I2C Overview
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA I2C Overview I²C VIPER: CONTROL HDMI HDMI: I/O + CONTROL B10A COMMON INTERFACE: PART1 MPIF MAIN: EXTERNALS B CONNECTIONS B +3V3 3Q11 SDA-MM SDA-MM-BUS1 SDA-MM-BUS1 I2C1-SDA 3Q10 SCL-MM SCL-MM-BUS1 SCL-MM-BUS1 I2C1-SCL...
Page 61: Supply Lines Overview
Block Diagrams, Test Point Overviews, and Waveforms BJ3.1E LA Supply Lines Overview SUPPLY LINE OVERVIEW PNX 2015: SUPPLY MPIF MAIN: IF + SAW FILTER PACIFIC3: PART 2 DC/DC CONNECTIONS B11B FIREWIRE 1394: BUFFERING +1V2 +1V2 1M46 1M46 +8VMPIF-MAIN +8VMPIF-MAIN +3V3...
Page 62: Circuit Diagrams And Pwb Layouts
Circuit Diagrams and PWB Layouts BJ3.1E LA 7. Circuit Diagrams and PWB Layouts Supply 32”: Filter & Stby 1000 E2 F425 G3 1001 E4 F426 G2 MAINS FILTER + STANDBY 1011 E5 F427 F4 1305 F8 F428 F4 1306 G2...
Page 63: Supply 32": Supply (A2)
Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 32”: Supply 1002 H14 3032 B11 7009 G5 I084 F9 1007 G11 3033 A5 7010 F12 I085 F12 1009 I13 3034 G13 7017 F3 I088 E13 SUPPLY 1010 I14 3035 C7 7018 F4...
Page 64 Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 32”: Connections 1310 B6 CONNECTIONS 1314 B1 1315 B2 1316 B3 1317 B4 1319 B3 1321 B2 1M64 C6 3902 C5 3903 C5 3904 E5 3905 E5 9051 B4 9052 B1 9053 B3...
Page 65: Supply 32": Connections (A3)
Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 32” (Top Side) 1000 A1 1305 A3 1319 A11 1M08 C11 2011 B7 2032 A8 2400 C2 2803 B3 3014 B6 3050 A5 3403 A1 3807 B4 5009 B7 5027 C9...
Page 66 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 32” (Overview Bottom Side) 2001 B3 2018 A6 2028 C3 2036 B2 2045 B2 2052 A2 2060 C7 2071 C5 2805 B8 3005 A6 3012 A6 3023 B2 3032 B1 3045 A6...
Page 67 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 32” (Part 1 Bottom Side) Part 1 G_15970_005a.eps 160306...
Page 68 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 32” (Part 2 Bottom Side) Part 2 G_15970_005b.eps 160306...
Page 69: (A1)
Circuit Diagrams and PWB Layouts BJ3.1E LA Display Supply 37”: Part 1 1011 A7 7014 H11 I438 F7 1308 C1 7801 F7 I439 F8 1310 H13 7802 G7 I440 F8 DISPLAY SUPPLY: PART1 1314 F1 7805 E10 I441 B13 1315 F2...
Page 70: (A2)
Circuit Diagrams and PWB Layouts BJ3.1E LA Display Supply 37”: Part 2 1002 H11 3051 B12 F016 B11 I142 H1 1009 G10 3052 C11 F017 D11 I143 H1 1010 G10 3053 E3 F018 B8 I145 E7 2000 E9 3054 B12...
Page 71 Circuit Diagrams and PWB Layouts BJ3.1E LA Platform Supply 37”: Auxiliary Supply 0P01 G10 1P07 B11 2P10 B2 2P22 A14 2P34 C15 2P50 D15 3P02 B12 3P14 F2 3P26 C14 3P38 D3 3P50 C7 3P62 F10 3P74 F6 3P86 E11...
Page 72 Circuit Diagrams and PWB Layouts BJ3.1E LA Platform Supply 37”: Standby Supply 1S01 E8 IS09 D4 2S04 B8 IS10 F10 PLATFORM SUPPLY: STANDBY SUPPLY 2S06 C7 IS11 F7 2S07 F8 IS12 B9 2S13 D8 IS13 B5 2S14 D11 IS14 E9...
Page 73 Circuit Diagrams and PWB Layouts BJ3.1E LA Platform Supply 37”: 25W Supply 1000 D9 9U18 B7 1M07 B9 FU00 B9 25W SUPPLY 1U01 1M09 C9 FU01 C9 HEATSINK 1U00 B2 FU03 B1 1U01 A4 FU05 B3 (7U02) HOT GROUND COLD GROUND...
Page 74: Platform Supply 37": Auxiliary Supply (A3)
Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Top Side) 0P01 A9 1318 C8 1M08 F10 1P30 C11 2013 F7 2403 E1 2P05 A5 2P20 A6 2S14 C8 2U14 C1 3050 D6 3451 D3 3PP3 A7 5005 F7...
Page 75 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Overview Bottom Side) 1P03 A9 2026 C6 2042 D1 2062 F5 2P02 A2 2P33 A6 2P56 B5 2U11 A10 3013 C5 3034 E1 3049 F1 3068 C4 3410 D7...
Page 76 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Part 1 Bottom Side) Part 1 G_15970_012a.eps 160306...
Page 77 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Part 2 Bottom Side) Part 2 G_15970_012b.eps 160306...
Page 78 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Part 3 Bottom Side) Part 3 G_15970_012c.eps 160306...
Page 79 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Display/Platform Supply 37” (Part 4 Bottom Side) Part 4 G_15970_012d.eps 160306...
Page 80: Supply 42": Mains Filter & Stby A (A1)
Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 42”: Mains Filter & Stby A 1000 D2 9812 E11 1001 D4 9813 C12 MAINS FILTER + STANDBY PART A 1011 E5 9814 C12 1305 F7 F410 B1 1306 F2 F411 B2...
Page 81: Supply 42": Part A (A2)
Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 42”: Part A 1009 I9 3070 H4 I036 F6 1010 I9 3071 H5 I037 C8 1304 H12 3075 G5 I038 C8 SUPPLY PART A 1309 I12 3089 H7 I039 D8 COLD 2000 F10...
Page 82: Supply 42": Mains Filter & Stby B (A3)
Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 42”: Mains Filter & Stby B 1C05 E8 ID15 C7 1D00 C2 ID16 C6 1D02 D5 ID24 D8 MAINS FILTER + STANDBY PART B 1D03 D5 ID42 C6 1D50 C8 ID44 C7...
Page 83 Circuit Diagrams and PWB Layouts BJ3.1E LA Supply 42”: Part B 1303 I12 3U70 H4 IA32 I5 1320 I12 3U71 H5 IA33 I4 1M02 H14 3U75 G5 IA34 I3 1U07 G11 3U89 H7 IA35 H3 SUPPLY PART B 1U09 I9...
Page 84: Supply 42": Part B (A4)
Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Top Side) 1000 B1 1304 B11 1320 E11 1B06 A4 1U01 D3 2002 B8 2012 D9 2025 A10 2403 A3 2409 B1 2808 C5 2B92 F10 2D08 E4 2H08 F5...
Page 85 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Overview Bottom Side) 2006 A5 2021 A4 2030 A1 2044 D2 2061 C5 2077 A4 2U06 E5 2U21 D4 2U32 D1 2U48 E4 2U65 G4 3004 A4 3011 A4 3022 A1...
Page 86 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Part 1 Bottom Side) Part 1 G_15950_006a.eps 040406...
Page 87 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Part 2 Bottom Side) Part 2 G_15950_006b.eps 040406...
Page 88 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Part 3 Bottom Side) Part 3 G_15950_006c.eps 040406...
Page 89 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Supply 42” (Part 4 Bottom Side) Part 4 G_15950_006d.eps 040406...
Page 90: Ssb: Dc / Dc (B1-B12)
Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: DC / DC 1U01 A10 2U17 A4 2U27 B7 2U42 B11 2U73 D11 3U07 C5 3U17 E8 3U27 B5 3U37 G1 3U52 A14 3U67 H9 3U86 A2 3UA2 B9 5U00 A8 6U21 E7...
Page 91 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: DC / DC Connections 1M46 D2 6U01 B3 DC/DC CONNECTIONS 1U10 E2 6U25 B6 1U11 E2 7U08 B6 1U12 E3 7U09 C6 1U13 E2 7U24 B2 VTUN GENERATOR 1U14 E2 7U26 B4...
Page 92 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: RS232 Interface 1H07 D1 IU96 D5 1U02 D8 IU97 D7 RS232 INTERFACE 1U03 D8 IU98 D6 2U60 B3 IU99 E5 2U61 B3 IUA2 B2 2U63 C5 2U64 C6 +5V2-STBY 2U65 C6 2U66 D5...
Page 93 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: DVB-T: Tuner 1T04 E2 IT11 A6 1T05 C2 IT13 D3 DVB-T: TUNER 1T06 A2 IT14 B3 2T01 E10 IT15 D9 2T02 F1 IT17 A7 2T03 C8 IT18 F2 2T04 D5 IT19 I3...
Page 94 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: DVB-T: Channel Decoder 1T08 F7 IT70 G3 2T17 C5 IT71 G3 DVB-T: CHANNEL DECODER 2T58 D11 IT72 D4 2T59 D11 IT73 B5 2T60 D11 IT74 F2 2T63 D11 IT75 C4 2T64 D11...
Page 95 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Video Source Selection 0T00 B11 2C02 D4 2C04 D4 2C06 D2 2C08 D2 2C11 E2 2C13 E5 2C15 F2 2C17 F3 2C19 G3 2C22 F6 2C27 G4 5C01 F4 7C00-4 C7...
Page 96 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Supply 1C33 I8 MPIF MAIN: SUPPLY 2AB5 B5 2C31 A7 FC31 5C35 2C32 H2 +5VMPIF-MAIN 2C33 H3 2C34 H5 2C35 C5 IC36 2C36 C5 7C31-1 BC847BS 2C37 H5 FC32 IC83...
Page 97 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: IF & SAW Filter 1C51 A5 2AB4 B9 2C52 A1 2C58 B8 2C67 C6 2C75 B7 2C84 B3 3C51 A6 3C58 D4 3C63 D7 3C70 A9 3C74 C10 3C80 B3...
Page 98 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Audio Source Selection 2K40 C4 MPIF MAIN: AUDIO SOURCE SELECTION 2K41 C3 2K43 C3 2K45 D4 2K46 C3 2K47 C3 2K58 H10 2K60 H10 2K61 I10 2K63 I10 2K64 I3...
Page 99 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Audio 2A20 A8 7A05-2 E5 2A21 C12 7A05-3 F2 MPIF MAIN: AUDIO 2A22 G8 7A05-4 H2 2A23 H9 7A06 F8 2A24 H12 7A07 E7 2A32 B7 7A08-1 A4 2A79 G8...
Page 100 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Connections A 0A00 G10 FA03 C10 0A01 G11 FA04 D10 MPIF MAIN: CONNECTIONS A 0A02 G10 FA05 D10 0A03 G11 FA06 D10 1E40 C10 FA07 C9 1E41 C2 FA08 D10...
Page 101 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: MPIF Main: Connections B 1E62 E2 9A25 E7 MPIF MAIN: CONNECTIONS B 1E63 C2 9A26 E8 1M52 A4 9A69 D4 2A34 2A75 FA33 5A01 100p 100p AUDIO-L 2A01 E8 9A70 D4 1M52...
Page 102 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: Audio / Video 0E02 F1 7J13 D6 5J00 PNX2015: AUDIO / VIDEO 0E03 F1 9J08 A9 +1V2 2J01 A1 9J24 C5 2J03 IJ08 5J13 2LT6 2J03 A6 FJ20 B8 +3V3 5J01...
Page 103 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: DV I/O Interface 2LR1 D8 PNX 2015: DV I/O INTERFACE 3LR0 D4 3LR1 C4 3LR3-1 B4 3LR3-2 B4 3LR3-3 B4 3LR3-4 B4 3LR4-1 B4 3LR4-2 B4 3LR4-3 B4 3LR4-4 B4 3LR5-2 C4...
Page 104 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: Tunnel Bus 2L01 E5 PNX 2015: TUNNELBUS 2L06 F2 2L07 F3 2L08 F3 2L64 E2 3L08 D4 3L09 B4 3L10 B4 7J00-1 2015 3L11 B4 Φ 3L12 B4 TUNNELBUS 3L13 B4...
Page 105 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: DDR Interface 2L50 A8 PNX 2015: DDR INTERFACE 2L51 A8 2L52 A8 2L53 A8 2L54 A8 2L55 C6 2L56 A6 +2V5-DDRPNX +2V5-DDRPNX 2L57 A7 2L58 A7 7J00-3 2L59 C5 2015 Φ...
Page 106 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: Standby & Control 1LA0 D7 3LM2 A4 IL33 I7 2LA0 D7 3LM3 A4 IL34 I6 2LA1 D7 3LM4 B4 IL35 F7 2LA2 D10 3LM5 B4 IL40 C11 PNX 2015: STANDBY & CONTROL...
Page 107 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: Supply 2L80 E1 2L81 E1 PNX 2015: SUPPLY 2L82 E1 2L83 E1 2L84 E1 2L85 E1 2L86 E2 2L87 E2 2L88 E2 7J00-9 7J00-8 2L89 E2 2015 2015 +3V3 Φ Φ...
Page 108 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: PNX2015: Display Interface 1G50 F12 FJ37 H11 2J37 H4 IJ10 B10 PNX 2015: DISPLAY INTERFACE 2J40 F9 IJ12 C11 2J41 F9 IJ13 D11 2J42 F9 IJ14 D4 2J43 G9 IJ15 C2 2J44 G9...
Page 109 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Viper: Control 0H00 B10 1M00 A10 2Q68 E13 3H06 A9 3H14 B9 3H26 F7 3H41 H1 3H79 A7 3H81-3 D8 3H88 E8 3H98 B4 3Q13 B4 3Q20 G11 3Q38-2 F7 3Q48 A4...
Page 110 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Viper: Main Memory 2Q01 B8 VIPER: MAIN MEMORY 2Q03 B9 2Q21 B13 2Q23 B14 2V00 C7 2V01 C14 2V02 C2 2V03 G8 2V04 G9 2V05 G9 2V16 G10 2V17 G11 2V18 G11...
Page 111 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Viper: A/V & Tunnel Bus 2H00 H3 2H01 I6 2H02 H3 2H03 H2 VIPER: A/V + TUNNELBUS 2H11 C12 2H12 D12 2H13 D12 2Q25 C12 7V00-1 2Q29 B12 VIPER REV C 2Q31 C12...
Page 112 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Viper: Supply 2Q00 C10 2Q06 C12 2Q10 C13 2Q14 C14 2Q18 C15 2Q24 E11 2Q30 E12 2Q35 E14 2Q40 D10 2Q45 D12 2Q49 D13 2Q53 D14 2Q57 D15 2Q61 F11 2Q65 C9...
Page 113 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Viper: Display Diversity & Ambi Light 1D40 A3 2Q71 D13 2Q80 G5 2Q86 E2 2Q93 G5 3Q30 C12 3Q54 B5 3Q76 G6 3Q85 A10 3Q96 C6 5Q11 D1 6H09 E7 9Q19 D12...
Page 114 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Pacific 3: Part 1 2G36 D7 3G02 D9 3G09 B4 3G13 B4 3G17 D4 3G23 C8 3G32 D9 3G55-1 C4 3G56-1 C4 3G57-1 D4 3G58-1 D4 3G59-1 E4 3G60-1 E4 7G31-1 C6...
Page 115 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Pacific 3: Part 2 1G01 C12 2G03 A4 2G08 A5 2G13 B3 2G18 B4 2G23 B5 2G28 C3 2G44 B7 2G49 B8 2G54 B14 2G59 A12 3G64 B12 3G71 A12 3G76 E10...
Page 116 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: HDMI 1B00 B3 1B01 A1 HDMI 1B02 C8 1B03 B3 1B04 B3 1B05 B10 1B06 B10 1B07 B10 1B20 I4 1B21 I11 2B00 B4 1B01 FB20 IB63 2B01 B4 3B02 IB17 3B14...
Page 117 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: HDMI: I/O & Control 2B21 B3 5B22 D2 2B22 G3 5B23 D2 2B23 B3 5B24 B2 HDMI: I/O + CONTROL 2B24 B2 5B31 C2 2B25 G3 7B11-1 B5 2B26 C2 7B11-2 C11...
Page 118 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: HDMI: Supply 2B38 F5 HDMI: SUPPLY 2B39 F6 2B40 A3 2B41 A3 HDMI SUPPLY 7B11-3 2B42 A4 TDA9975 2B49 C3 PART HDMI SUPPLY 2B51 C3 2B52 A2 5B17 VDDAPLL FB57 3V3-APLL 1V8-PLL...
Page 119 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: USB 2.0: Host 1N00 G8 1N62 F1 USB 2.0: HOST 2N00 G9 2N01 G9 2N02 B6 +3V3 2N03 A6 2N04 A6 +3V3 2N05 A7 2N06 A7 2N07 A7 +5V2-STBY 2N08 A7 2N09 A7...
Page 120 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Ethernet 1O00 C8 2O02 H4 2O06 D12 2O12 G10 2O16 C8 2O20 G11 2O24 G11 2O28 G10 3O03 C7 3O07 D1 3O11 D8 3O21 A8 3O25 C9 5O00 G9 7O00-1 B3 FO01 A10...
Page 121 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: UART 1M15 B6 1O02 C5 2O51 C5 3O16 C2 6O02-2 D4 FO11 C4 Personal Notes: 1O01 B5 2O50 B5 3O15 B3 6O02-1 A4 FO10 B4 UART 6O02-1 +3V3-STANDBY BAV99S 1M15 FO10 3O15...
Page 122 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Common Interface: Part 1 1P01-A B1 0 2P07 A6 2P19 C2 2P26 C2 3P08 A4 3P14 B4 3P20 A8 3P26 E10 3P32 C4 3P74 E3 6P11 D3 9P02 D3 9P09 B7 9P34 B1...
Page 123 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Common Interface: Part 2 Personal Notes: 2P44 B3 COMMON INTERFACE: PART 2 2P50 C1 B10B 2P51 E1 3P02 C3 3P03 A3 +3V3 3P04 B3 3P05 A3 3P07 3P07 A4 CI or no POD-RDC...
Page 124 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Common Interface: Part 3 2P31 A3 2P32 C3 COMMON INTERFACE: PART 3 B10C B10C 2P33 E7 2P76 A7 2P77 C7 +3V3 3P60-1 B4 3P60-2 C3 +3V3 3P60-3 C4 3P76 3P60-4 C3 +3V3...
Page 125 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: NVM / NAND / UART Switch 1P02 B6 2P34 B4 NVM / NAND / UART SWITCH B10D B10D 2P35 C4 2P80 C8 2P81 C8 +3V3-STANDBY 2P82 C6 9P41 9P42 3P36 A3 3P37 A4...
Page 126 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Firewire 1394: Main 1Z05 F12 IZ12 F8 FIREWIRE 1394: MAIN B11A B11A 1Z10 B14 IZ13 F8 1Z11 E14 IZ14 F8 +3V3-VCCD 1Z55 I7 IZ15 F8 5Z02 IZ00 2Z04 B9 IZ16 F8 +3V3-VCCA...
Page 127 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Firewire 1394: Buffering 2Z50 A3 FIREWIRE 1394: BUFFERING B11B B11B 2Z51 B3 2Z52 D3 +3V3BUFF 3Z53 F3 +3V3 +3V3BUFF 5Z50 2Z50 3Z54 F3 7Z10 IZ50 100n 74LVC245A 5Z50 A2 PCI-CBE1 3EN1 7Z10 A3...
Page 128 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: Firewire 1394: Miscellaneous 1TG1 E4 IM08 F2 2M90 B2 IM11 A3 MISCELLANEOUS 2M91 C2 IM12 A2 2M92 D3 IM13 C5 2M93 C4 IM14 C2 +3V3-STANDBY +3V3-STANDBY +3V3-STANDBY 2M94 D5 IM15 C2 3M00 E1...
Page 129 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: SRP List Part 1 schematic netname B03e (3x) +5V-AUD B03a (1x) AV1_CVBS B10b (1x) CTX_POD-A(4) B05c (1x) DV2A-DATA9_7 B06b (1x) DV-GOUT-6 B05c (1x) I2S-MAIN-ND B10a (2x) MDIA(4) B04b (1x) MP-BOUT-5 B03c (4x)
Page 130 Circuit Diagrams and PWB Layouts BJ3.1E LA SSB: SRP List Part 2 Schematic Net Name B07a (2x) P50-HDMI B05a (1x) PCI-AD29 B11a (2x) PHY-D(4) B10a (1x) POD-DATA4 B05e (1x) SDA-AMBI B05c (1x) TUN-VIPER-RX-DATA1 B08 (2x) USB20-OC2 B11a (1x) XIO-D15 B04e (3x)
Page 131 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Top Side Overview) 1B01 C4 2BA4 B4 2J75 B1 2O18 D4 2Q94 F2 3A01 B1 3C31 A2 3H71 D2 3LA0 B3 3LL9 C3 3Q61 D3 5B24 B4 6J04 B1 9A56 A1...
Page 132 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Top Side Part 1) Part 1 G_15960_055a.eps 010306...
Page 133 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Top Side Part 2) Part 2 G_15960_055b.eps 010306...
Page 134 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Overview Bottom Side) 1C51 A3 2C16 B3 2P23 G1 2U60 F2 3B93 B1 3LN5 C2 3P38 F1 3U22 G3 3V36 E3 7B30 B1 9C51 A3 1C52 A3 2C17 B3 2P24 F2...
Page 135 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Bottom Side Part 1) Part 1 G_15960_056a.eps 060306...
Page 136 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout SSB (Bottom Side Part 2) Part 2 G_15960_056b.eps 060306...
Page 137: Externals: A (Be1)
Circuit Diagrams and PWB Layouts BJ3.1E LA Externals: A 1000 A7 3055 F7 F023 F13 1003 B12 3056 F12 F024 F13 EXTERNALS A 1004 C7 3057 G11 F025 F13 1005 C12 3058 F7 F026 A3 1006 C7 3059 F5 F027 A4...
Page 138: Externals: B (Be2)
Circuit Diagrams and PWB Layouts BJ3.1E LA Externals: B 1010 H13 9110 I4 1080-1 B14 9111 C3 1080-2 C14 9112 C3 EXTERNALS B 1080-3 A14 9113 C3 1090 D14 9114 C3 1100 H12 9115 D3 1101 H12 9116 C3 REGIMBEAU...
Page 139: Externals: C (Be3)
Circuit Diagrams and PWB Layouts BJ3.1E LA Externals: C 1040 H11 I203 B3 1050 A11 I204 F5 1060 B11 I205 B3 EXTERNALS C 1070-1 D11 I206 B9 1070-2 G11 I207 B3 1070-3 E11 I208 C3 1225 A9 I209 C3 1230 B9...
Page 140 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Externals (Top Side) Layout Externals (Bottom Side) 1010 D2 2208 B2 7005 C1 2019 C2 6002 D2 1020 C1 2209 B2 7006 C2 2025 A2 6003 D1 1030 C2 2210 B2 7007 C1...
Page 141: Audio Panel (37"): Left / Right
Circuit Diagrams and PWB Layouts BJ3.1E LA Audio Panel (37”): Left / Right 1735 B14 2D04 D3 2D10 C6 2D17 E8 2D26 C9 2D32 B13 2D39 D15 2D46 D3 3D06 A4 3D12 D4 3D18 C5 3D30 B10 3D36 D10 3D42 C13...
Page 142 Circuit Diagrams and PWB Layouts BJ3.1E LA Audio Panel (37”): Protection & Mute Ctrl 0002 G11 IDE1 D10 PROTECTION / MUTE CONTROL 1M02 C11 IDE2 D11 1M52 A11 IDE3 A5 2DD1 F3 IDF1 A3 2DD2 D6 IDF2 B4 2DD4 F6...
Page 143: Audio Panel (37"): Protection & Mute Ctrl (C2) 142
Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Audio Panel (37”) (Top Side) Layout Audio Panel (37”) (Bottom Side) 2D00 B2 2D17 A2 2D35 A1 2DE0 B1 3D09 B2 3D31 B1 3D69 A2 3DF5 B3 3DG9 B3 7D06 A2 7DF0 A3...
Page 144: Side I/O Panel (D)
Circuit Diagrams and PWB Layouts BJ3.1E LA Side I/O Panel 1301 A1 S307 F2 1302-1 C1 S308 F2 SIDE FACING SIDE AV 1302-2 D1 S310 E8 1302-3 E1 S311 E8 1303 E1 S312 E8 1304 B9 1308 D9 1309 D7...
Page 145 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Side I/O Panel (Top Side) 1301 1302 1303 1304 1308 1309 1310 G_16850_026.eps 3139 123 6229.1 120107 Layout Side I/O Panel (Bottom Side) 2301 A4 2307 A2 2313 A3 3305 A3 3311 A3...
Page 146: Keyboard Control Panel (E)
Circuit Diagrams and PWB Layouts BJ3.1E LA Keyboard Control Panel Personal Notes: 1001 C1 1002 C1 KEYBOARD CONTROL 1003 C1 1004 C2 1005 C2 1011 C1 1012 C1 1013 C2 1014 C2 1015 C2 1016 C3 1M01 A4 2001 B3...
Page 147 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Keyboard Control Panel (Top Side) 1011 A5 1012 A6 1013 A3 1014 A2 1015 A1 1016 A7 1M01 A8 G_16850_028.eps 3139 123 6219.1 120107 Layout Keyboard Control Panel (Bottom Side) 2001 A1...
Page 148 Circuit Diagrams and PWB Layouts BJ3.1E LA Front IR / LED Panel Personal Notes: 1M01 E1 1M20 E1 IR/LED/LIGHT-SENSOR 1M21 E1 2001 A2 2002 D2 3010 A2 3011 A2 +5V_STANDBY 3012 B4 +5V_STANDBY +5V_STANDBY 3013 B4 3014 B2 3015 C2...
Page 149: Front Ir / Led Panel
Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Front IR / LED Panel (Top Side) Layout Front IR / LED Panel (Bottom Side) 2001 C2 3014 B2 3020 C3 4005 C2 4015 C4 6014 D4 2002 B1 3015 B1 3021 C3...
Page 150: Standby & Audio Panel (32"): Connections(Sa1)
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (32”): Connections 0001 A8 CONNECTIONS 1318 B2 1J02 E7 1M03 B5 1M46 D5 1M63 B7 1M64 C2 9002 C2 9003 C2 9008 B2 +5V_SW +5V_SW 9009 B2 9030 E4...
Page 151: Standby & Audio Panel (32"): Standby
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (32”): Standby 1301 B1 3541 G12 I131 E3 1305 E13 3542 H13 I132 B13 1306 B3 3543 D13 I133 D5 1310 A12 3544 G12 I134 E3 STANDBY 1311 A12...
Page 152: Standby & Audio Panel (32"): Supply
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (32”): Supply 1M08 B9 7U02 B4 1M10 C9 7U03 E5 1U01 F5 7U04 E6 SUPPLY 1U11 D9 7U05 D7 2U02 B3 7U07 F6 COLD-GROUND HOT-GROUND 2U05 B7 7U08 E7...
Page 153: Standby & Audio Panel (32"): Audio
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (32”): Audio 1735 D14 2D04 F3 2D10 D6 2D16 F10 2D27 D10 2D33 D12 2D40 B2 2D91 F9 3D06 C4 3D12 E4 3D18 D5 3D30 C10 3D36 E10 3D42 D13...
Page 154: Standby & Audio Panel (32"): Prot. / Mute (Sa5)
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (32”): Prot. / Mute 0002 G12 c004 F11 1M02 C12 c006 F11 PROTECTION / MUTE CONTROL 1M52 B12 2DD1 G3 2DD4 G6 2DE0 E12 2DF0 C4 2DF2 B5 2DF3 C5...
Page 155 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (32”) (Top Side) Layout Standby & Audio Panel (32”) (Overview Bottom Side) 2103 B4 2513 C1 2541 C1 2D09 E1 2D25 E1 2D37 G1 2DD1 D1 2DG2 D2...
Page 156 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (32”) (Part 1 Bottom Side) Part 1 G_15970_023a.eps 160306...
Page 157 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (32”) (Part 2 Bottom Side) Part 2 G_15970_023b.eps 160306...
Page 158: Standby & Audio Panel (42"): Connections(Sa1)
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (42”): Connections 0001 F4 F120 D6 0002 F4 F121 C4 CONNECTIONS 0003 F5 F122 C5 1303 B7 F131 E3 1304 C8 F132 E3 1309 E7 F135 E3 1314 E1...
Page 159: Standby & Audio Panel (42"): Standby
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (42”): Standby 1301 B1 3506 G11 7511 A8 I186 G6 1305 D13 3507 F13 7512 A10 I187 D11 6511 I509 I510 3516 34V (34V) VTUN 1306 B3 3508 G13...
Page 160: Standby & Audio Panel (42"): Audio
Circuit Diagrams and PWB Layouts BJ3.1E LA Standby & Audio Panel (42”): Audio 0044 D14 2705 A7 2715 F4 2726 E2 2758 G9 2780 E5 2790 E2 3701 E6 3711 E4 3722 C1 3744 G11 3755 B10 3765 C12 3796 E11...
Page 161 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (42”) (Top Side) Layout Standby & Audio Panel (42”) (Overview Bottom Side) 3128 B3 3145 B3 3156 A3 3175 C2 3510 A2 6118 C4 2103 B4 2131 A1...
Page 162 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (42”) (Part 1 Bottom Side) G_15950_033a.eps Part 1 050406...
Page 163 Circuit Diagrams and PWB Layouts BJ3.1E LA Layout Standby & Audio Panel (42”) (Part 2 Bottom Side) Part 2 G_15950_033b.eps 050406...
Page 164 Circuit Diagrams and PWB Layouts BJ3.1E LA Personal Notes: E_06532_013.eps 131004...
Page 165: Alignments
Alignments BJ3.1E LA EN 165 8. Alignments Index of this chapter: Notes: 8.1 General Alignment Conditions • All changes must be stored manually. 8.2 Hardware Alignments • If an empty NVM (permanent memory) is detected, all 8.3 Software Alignments settings are set to pre-programmed default values.
Page 166 EN 166 BJ3.1E LA Alignments 8.3.3 White Point • Set “Active control” to “Off” as earlier described. • Choose “TV menu”, “TV Settings” and then “Picture” and put: – “Dynamic contrast” to “Off”. – “Colour enhancement” to “Off”. – “Light sensor” to “Off”.
Page 167 Alignments BJ3.1E LA EN 167 Option Settings 8.4.1 Introduction The microprocessor communicates with a large number of I ICs in the set. To ensure good communication and to make digital diagnosis possible, the microprocessor has to know which ICs to address. The presence / absence of these specific ICs (or functions) is made known by the option codes.
Page 168 EN 168 BJ3.1E LA Alignments Menu-item Subjects Options Description Audio Repro Acoustic System (Cabinet None design, used for setting Entry ME5 5W dynamic audio parameters). Entry ME5 15W (Soft) Wrap Entry+ (ME7) etc..Centre mode support Feature present / not present...
Page 169 3 (8) China IF 0= Off, 8= On 4 (16) Interconnect Alternative Tuner 0= Philips, 16= Alps Tuner make. 5 (32) Tuner Type 0= TD1336s (B-Chassis US), 32= TD1331(J-Chassis US), 64= UV1318 Tuner type (B-chassis US is e.g (analogue EU), 96= TD1316 (Hybrid EU) "BP2.3U").
Page 170 EN 170 BJ3.1E LA Alignments Bit (dec. Byte value) Subject Options Settings (in decimal values) Remarks 0 (1) Display Screen see Table “Display code overview” in Chapter “Service Modes” for the values Screen size, type, and resolution. 1 (2) 2 (4)
Page 171: Circuit Descriptions, Abbreviation List, And Ic Data Sheets
Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 171 9. Circuit Descriptions, Abbreviation List, and IC Data Sheets Index of this chapter: 9.1.2 Chassis Block Diagram 9.1 Introduction 9.2 Power Supply Description below refers to the block diagrams in chapter 6 9.3 Front-End...
Page 172 EN 172 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets SSB Cell Layout LVDS DISPLAY INTERFACE DC / DC & CONV SOURCE SELECTION SIGNAL PROCESSING MPIF RS232 COMMON INTERFACE TUNER UART HDMI 1 HDMI 2 G_15960_112.eps 070306 Figure 9-1 SSB top view...
Page 173 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 173 Power Supply Common Interface (CI) 9.2.1 DC/DC converters 9.4.1 Introduction For a (more) detailed description of the on-board DC/DC The digital sets of this chassis are provided with a special slot converters of the SSB see the BP2.xU Service Manual.
Page 174 EN 174 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets Conditional Access Working Principle 9.4.3 Communication Channels The Conditional Access Module (CAM), also called POD (Point Of Deployment), is a removable CAM, implementing the In Band (IB) Conditional Access (CA) system for a Host (i.e. the TV set).
Page 175: Abbreviation List
Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 175 Abbreviation List Colour Transient Improvement: manipulates steepness of chroma transients 0/6/12 SCART switch control signal on A/V CVBS Composite Video Blanking and board. 0 = loop through (AUX to TV), 6...
Page 176 EN 176 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets enabled for HDCP "software key" Non-Volatile Memory: IC containing decoding. TV related data such as alignments HDMI High Definition Multimedia Interface Open Circuit Head Phone Out Of Band channel Monochrome TV system.
Page 177 4.406250 MHz and 4.250000 MHz Sound Intermediate Frequency SMPS Switched Mode Power Supply Sync On Green SOPS Self Oscillating Power Supply S/PDIF Sony Philips Digital InterFace SRAM Static RAM Small Signal Board STBY STandBY Sync On Green SVGA 800x600 (4:3)
Page 178: Ic Data Sheets
EN 178 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10 IC Data Sheets This section shows the internal block diagrams and pin configurations of ICs that are drawn as "black boxes" in the electrical diagrams (with the exception of "memory" and "logic"...
Page 179 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 179 9.10.2 Diagram B2A, TD1316AF (IC 1T05) Block Diagram G_15960_139.eps 100306 Figure 9-9 Internal block diagram 9.10.3 Diagram B2B, TDA10046AHT (IC 7T17) Block Diagram G_15960_140.eps 100306 Figure 9-10 Internal block diagram...
Page 180 EN 180 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10.4 Diagram B3x, PNX3000HL (IC 7C00) Block Diagram 1 × CVBSOUTA CVBSOUTB 2NDSIFEXT (FMRAD) SIFAGC CVBSOUTIF MIXER SIFIN 2nd SIF internal & AM SND DEMOD DTV 1st IF...
Page 181 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 181 9.10.5 Diagram B4x, PNX2015E (IC 7J00) Block Diagram 16-BIT 225 MHz DDR PNX2015 MEMORY CONTROLLER video NORTH TUNNEL SOUTH TUNNEL PNX8550 coprocessor HD input (TDA9975) MEMORY VO-1 BASED SCALER...
Page 182 EN 182 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10.6 Diagram B4A, CY2305SC-1 (IC 7J08) Block Diagram Pin Configuration CY2305SC-1 CLKOUT CLKA1 SOIC Top View CLKA2 CLKOUT CLK4 CLK2 CLKA3 CLK1 CLK3 CLKA4 CLKB1 Select Input CLKB2...
Page 183 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 183 9.10.8 Diagram B5x, PNX8550EH (IC 7V00) Block Diagram Streaming Interface Optional External 32-Bit 225 MHz DDR from Tunnel Video Improvement Processing PNX8550 Memory 30 (dig) DVD-CSS 5-Layer Controller...
Page 184 EN 184 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10.9 Diagram B5A, LM3526MX (IC 7Q01) Block Diagram Pin Configuration LM3526-L F_15400_134.eps 230905 Figure 9-16 Internal block diagram and pin configuration...
Page 185 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 185 9.10.10 Diagram B7B & B7C, TDA9975EL (IC 7B11) Block Diagram τ ORR/V τ I²C ORB/U τ ORG/Y G/Pb B/Pb1 B/Pb2 B/Pb3 I²C 10/12 I²C I²C CLAMP BIAS I²C I²C...
Page 186 EN 186 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10.11 Diagram B8, ISP1561BM (IC 7N00) Block Diagram SMI# SEL48M PME# ISP1561BM GLOBAL CONTROL IRQ1 IRQ12 legacy keyboard and mouse support AD[31:0] PCI CORE KBIRQ1 C/BE#[3:0] REQ# MUIRQ12...
Page 187 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 187 9.10.12 Diagram B10A, TPS2211AIDB (IC 7P00) Block Diagram TPS2211A Card B V CC1 3.3 V V CC2 3.3 V V pp1 12 V V pp2 See Note A...
Page 188 EN 188 BJ3.1E LA Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.10.13 Diagram B10A, STV0701 (IC 7P03) Block Diagram Pin Configuration F_15400_138.eps 240505 Figure 9-20 Internal block diagram and pin configuration...
Page 189 Circuit Descriptions, Abbreviation List, and IC Data Sheets BJ3.1E LA EN 189 9.10.14 Diagram C, TDA8925ST (IC 7701) Block Diagram V DD2 V DD1 TDA8925ST/J TDA8926J BOOT1 DRIVER HIGH CONTROL OUT1 HANDSHAKE DRIVER REL1 STAB temp V SS1 TEMPERATURE SENSOR...
Page 190: Spare Parts List
EN 190 BJ3.1E LA Spare Parts List 10. Spare Parts List Set Level per Model Number (CTN) 8136 3104 311 08031 Cable 11p/480/11p 8146 3104 311 06991 Cable 11p/280/11p 42PFL7332/10 (ME7) 8150 3139 131 08631 Cable 31p/340/30p 32PFL7332/10 (ME7) 8152...
Page 191 Spare Parts List BJ3.1E LA EN 191 1116 3139 268 09031 Side I/O Assy [D] 2046 3198 017 34730 47nF 16V 0603 3101 4822 051 30153 15kΩ 5% 0.062W 1150 3139 268 50011 Service SSB 8-bit [B] 2047 5322 126 11583 10nF 10% 50V 0603 3102 2322 704 62203 22kΩ...
Page 192 EN 192 BJ3.1E LA Spare Parts List 7006 9322 192 18687 STP15NK50ZFP 2410 2022 554 04163 100pF 10% 250V 3021 4822 117 12971 15Ω 5% 0603 0.62W 7007 3198 010 42320 BC857BW 2411 2022 554 04163 100pF 10% 250V 3022 4822 051 30681 680Ω...
Page 193 Spare Parts List BJ3.1E LA EN 193 3P42 4822 051 30222 2.2kΩ 5% 0.062W 9014 3198 036 90010 Wire 0.58mm 9P53 3198 036 90010 Wire 0.58mm 3P43 4822 051 30222 2.2kΩ 5% 0.062W 9016 3198 036 90010 Wire 0.58mm 9P54 3198 036 90010 Wire 0.58mm...
Page 194 EN 194 BJ3.1E LA Spare Parts List 6020 4822 130 11397 BAS316 7P09 3198 010 42310 BC847BW 2046 3198 017 34730 47nF 16V 0603 6021 9322 206 26687 STPS20H100CT 7P10 3198 010 42310 BC847BW 2047 5322 126 11583 10nF 10% 50V 0603 6022 4822 130 11148 UDZ4.7B...
Page 195 Spare Parts List BJ3.1E LA EN 195 3018 4822 052 10479 47Ω 5% 0.33W 3U47 4822 051 30479 47Ω 5% 0.062W 5009 4822 157 11411 Bead 80Ω at 100MHz 3019 4822 051 30222 2.2kΩ 5% 0.062W 3U48 4822 051 30272 2.7kΩ 5% 0.062W 5010 4822 157 11411 Bead 80Ω...
Page 196 EN 196 BJ3.1E LA Spare Parts List 6U06 4822 130 11397 BAS316 2A32 2020 012 93822 47μF 20% 16V 2C07 2238 787 15641 22nF 5% 16V 0402 6U07 4822 130 11397 BAS316 2A34 2238 869 15101 100pF 5% 50V 0402...
Page 197 Spare Parts List BJ3.1E LA EN 197 2G42 4822 124 81058 47μF 20% 4V 2L06 2238 586 59812 100nF 20% 50V 0603 2N12 2238 586 59812 100nF 20% 50V 0603 2G43 2022 552 05679 1μF 10% 16V 0805 2L08 2020 552 96618 1nF 10% 50V 0402...
Page 198 EN 198 BJ3.1E LA Spare Parts List 2Q57 2020 552 96628 10nF 10% 16V 0402 2U25 2022 552 05635 22μF 10% 16V 3A09 4822 117 13605 Jumper 0402 2Q58 2020 552 96628 10nF 10% 16V 0402 2U25 2222 784 13681 22μF 10% 16V X5R 1812 3A10 3198 031 05610 560Ω...
Page 199 Spare Parts List BJ3.1E LA EN 199 3B24 4822 117 13548 1kΩ 5% 0402 3G35 3198 031 01230 12kΩ 5% 0402 3J66 3198 031 04720 4.7kΩ 5% 0402 3B27 3198 031 03390 33Ω 1% 0402 3G51 3198 031 04730 47Ω 5% 0402 3J75 3198 031 04720 4.7kΩ...
Page 200 EN 200 BJ3.1E LA Spare Parts List 3LB8 4822 117 13606 10kΩ 5% 0.01W 0402 3LN3 4822 117 11373 100Ω 1% 0805 3O16 4822 117 13545 100Ω 1% 0402 3LB9 4822 117 13606 10kΩ 5% 0.01W 0402 3LN4 4822 117 11373 100Ω 1% 0805 3P01 3198 031 04720 4.7kΩ...
Page 201 Spare Parts List BJ3.1E LA EN 201 3Q43 4822 117 13546 47Ω 5% 0402 3U41 2322 706 73303 33kΩ 5% 0402 9B14 4822 117 13605 Jumper 0402 3Q44 2350 033 11689 4x 68Ω 5% Netw. 3U42 3198 031 01090 10Ω 5% 0.01W 0402...
Page 202 EN 202 BJ3.1E LA Spare Parts List 5A05 2422 549 43062 Bead 600Ω at 100MHz 5Q04 2422 549 43769 Bead 30Ω at 100MHz 7C54 3198 010 42310 BC847BW 5A06 2422 549 42896 Bead 120Ω 100MHz 5Q04 2422 549 45843 Bead 30Ω at 100MHz...
Page 203 Spare Parts List BJ3.1E LA EN 203 2213 2238 586 59812 100nF 20% 50V 0603 3104 3198 031 01510 150Ω 5% 0.01W 0402 Externals [BE] 2214 4822 124 12095 100μF 20% 16V 3105 4822 051 30102 1kΩ 5% 0.062W 2215...
Page 204 EN 204 BJ3.1E LA Spare Parts List 6013 4822 130 11416 PDZ6.8B 2D08 4822 126 14247 1.5nF 50V 0603 3DG1 4822 051 30103 10kΩ 5% 0.062W 6014 4822 130 11416 PDZ6.8B 2D09 4822 126 14247 1.5nF 50V 0603 3DG2 4822 117 12925 47kΩ 1% 0.063W 0603 6015 4822 130 11416 PDZ6.8B...
Page 205 Spare Parts List BJ3.1E LA EN 205 2313 3198 016 36810 680pF 25V 0603 2160 4822 124 21913 1μF 20% 63V 2314 3198 016 36810 680pF 25V 0603 2163 4822 124 40207 100μF 20% 25V 2163 4822 124 81151 22μF 50V...
Page 206 EN 206 BJ3.1E LA Spare Parts List 2D38 4822 124 80061 1000μF 20% 25V 3515 4822 117 13632 100kΩ 1% 0603 0.62W 3D30 4822 051 30223 22kΩ 5% 0.062W 2D39 2222 580 15649 100nF 10% 50V 0805 3516 4822 051 30472 4.7Ω 5% 0.062W 3D31 4822 117 11817 1.2kΩ...
Page 207 Spare Parts List BJ3.1E LA EN 207 6103 5322 130 31938 BYV27-200 7DF3 3198 010 42310 BC847BW 6104 9340 548 69115 PDZ27B 7DF4 3198 010 42310 BC847BW 6105 4822 130 11522 UDZ15B 7DF5 3198 010 42310 BC847BW 6106 9340 548 67115 PDZ22B...
Page 208: Revision List
EN 208 BJ3.1E LA Revision List 11. Revision List Manual xxxx xxx xxxx.0 • First release. Manual xxxx xxx xxxx.1 • Manual updated with several new models (mainly 37” and 42”). All relevant chapters are adapted.

Philips BJ3.1E LA Service Manual

Quick Links

Related Manuals for Philips BJ3.1E LA

Summary of Contents for Philips BJ3.1E LA

Table of Contents
