BDL6520EL Safety Instructions Warnings and Precautions KNOW THESE SAFETY SYMBOLS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any inside part of this product.
BDL6520EL Regulatory Information CE Declaration of Conformity We declare under our responsibility that the product is in conformity with the following standards: • EN60950-1:2006+A11:2009+A1:2010+A12:2011 (Safety requirement of Information Technology Equipment). • EN55022:2010 (Radio Disturbance requirement of Information Technology Equipment). •...
Page 4
BDL6520EL Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.
Page 5
BDL6520EL Information for U.K. only WARNING – THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: 1. Remove fuse cover and fuse.
Page 7
Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old display from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.
BDL6520EL Table Of Contents Unpacking and Installation ........1 3.6. Fixing your external PC ........13 1.1. Unpacking ..............1 OSD Menu ..............14 1.2. Package Contents .............1 4.1. Navigating the OSD Menu ......14 1.3. Installation Notes ............1 4.1.1. Navigating the OSD menu using 1.4.
BDL6520EL Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Due to the size and weight of this display it is recommended for two people to move it.
BDL6520EL 1.4. Mounting on a Wall To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface that complies with UL1678 standard in North America. Protective Sheet Table 1.
BDL6520EL 1.5. Mounting in Portrait Position This display can be installed in portrait position. 1. Remove the table stand, if attached. 2. Rotate 90 degrees clockwise. The “ ” logo should be on the LEFT side when facing the display.
BDL6520EL Parts and Functions 2.1. Control Panel MUTE INPUT MENU NOTE: “Keyboard Control Lock Mode” This function completely POWER] button disables the access to all Keyboard Control functions. To Press to turn the display on or put the display to standby.
BDL6520EL 2.2. Input/Output Terminals VIDEO OUT AUDIO OUT AUDIO IN 1 AUDIO IN 3 S-VIDEO IN AUDIO IN 2 VIDEO IN (OUT) (IN) AC IN VIDEO IN / VIDEO OUT • S-VIDEO IN (Mini DIN 4 pin): S-VIDEO (Y/C separate signal) AC power input.
BDL6520EL 2.3. Remote Control [DISPLAY] button Press to turn on/off the information OSD displayed on the upper right corner of the screen. 2.3.1. General functions [ ] button • Press to move the selection left in OSD menu. POWER •...
BDL6520EL 2.3.2. [FREEZE] operation 2.3.5. Operating range of the remote control Press this button to freeze the screen image. Point the top of the remote control toward the display’s remote control sensor when pressing a button. To freeze the screen image: Use the remote control within a distance of less than 10m/33ft from 1.
BDL6520EL Connecting External Equipment 3.1. Using the Switch Cover A cover for the power switch is provided to prevent the display from being turned on or off accidentally. To lock the cover into position: 1. Align and insert the cover to the indentation located beside the power switch.
BDL6520EL 3.2. Connecting External Equipment (DVD/VCR/VCD) 3.2.1. Using COMPONENT video input Component Out Audio Out (YPbPr) DVD / VCR / VCD [AUDIO IN 2], [AUDIO IN 3] [COMPONENT IN] (YPbPr) 3.2.2. Using HDMI video input DVD / VCR / VCD...
BDL6520EL 3.3. Connecting a PC 3.3.1. Using VGA input VGA Out Audio Out [AUDIO IN 1] [AUDIO IN 2], [AUDIO IN 3] [VGA IN] 3.3.2. Using DVI input DVI Out Audio Out [AUDIO IN 1] [AUDIO IN 2], [AUDIO IN 3] [DVI IN] 3.3.3.
BDL6520EL 3.4. Connecting Audio Equipment 3.4.1. Connecting external speakers External Speakers Speaker Switch NOTE: Press the [Speaker Switch] to select either the internal or external speakers according to your connection. 3.4.2. Connecting an external audio device Audio In Stereo Amplifier...
BDL6520EL 3.5. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. NOTE: Up to maximum 25 displays (5x5) can be used in a daisy-chain configuration.
BDL6520EL 3.6. Fixing your external PC Thi sidsplay reserved 6 pcs of M4 screw holes with 100 mm pitch for mounting your Smart Insert Module. (by using M4x10 screw) 100 mm...
BDL6520EL OSD Menu 4.2. OSD Menu Overview An overall view of the On-Screen Display (OSD) structure is shown 4.2.1. Picture menu below. You can use it as a reference for further adjusting your display. 4.1. Navigating the OSD Menu Brightness...
BDL6520EL This item is functional only when {Color temperature} is set Clock phase NOTE: to {User}. Adjust to improve the focus, clarity and stability of the image. Smart contrast This item is functional for VGA input only. NOTE: When turned on, this function helps enhance image contrast when Zoom mode displaying dark scenes.
BDL6520EL Audio reset H position Moves the horizontal position of the image left Reset all settings in the Audio menu to factory preset values. or right. Card OPS audio Select the analog or digital audio mode for card OPS. V position Moves the vertical position of the image up or 4.2.4.
BDL6520EL By pressing the [PIP ON/OFF] button on the remote control, you can Panel saving change the mode in the order shown below: Choose to enable the panel saving functions and thus reduce the risk of “image persistence” or “ghost-imaging”.
BDL6520EL OSD H-position to enter the following values manually. When finished, press [SET] button to store and save the chosen values. Adjust the horizontal position of the OSD menu. • IP address OSD V-position • Subnet mask Adjust the vertical position of the OSD menu.
Page 27
BDL6520EL Example: 2 × 2 screen matrix (4 displays) • {Overscan} – Display about 95% of the original size of the image. The rest of the areas surrounding the image will be cut off. H monitors = 2 displays V monitors = 2 displays •...
Page 28
BDL6520EL Frame comp. – {No} • Which input source the display will use for each scheduled activation period. NOTE: We recommend you to set up current date and time in the {Date and time} menu before using this function. 1. Press [SET] or [ ] button to enter the submenu.
Page 29
BDL6520EL • If there are two schedule items programmed for the same time, the on when the display power is set to on. When set to other video highest numbered schedule takes priority. For example, if schedule source inputs, the OPS will always be set to on.
BDL6520EL Input Mode PC Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz WVGA 70 Hz 33.75 MHz...
This notice explains the different types of pixel defects and defines the acceptable defect level for the BDL6520EL LCD screen. In order to qualify for repair under warranty, the number of pixel defects must exceed a certain level as shown in the reference table. If the LCD screen is within specification a warranty exchange / claim back will be refused.
Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or sub- pixel defects exceeding the tolerances listed in the following table.
BDL6520EL Cleaning and Troubleshooting 7.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.
BDL6520EL 7.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of the 2. Make sure the power switch is switched on.
