OWNER'S MANUAL
DUAL FUEL RANGE
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
WARNING
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
• Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer, service
agency, or the gas supplier.
WARNING
Never Operate the Top Surface Cooking Section of this Appliance Unattended
• Failure to follow this warning statement could result in fire, explosion, or
burn hazard that could cause property damage, personal injury, or death.
• If a fire should occur, keep away from the appliance and immediately call
your fire department.
• DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH WATER.
LUTD4919SN
MFL68920507
Copyright © 2016 - 2023 LG Electronics Inc. All Rights Reserved.
www.LGSIGNATURE.com

Advertisement

Table of Contents
loading

Related Manuals for LG LUTD4919SN

Summary of Contents for LG LUTD4919SN

  • Page 1 • If a fire should occur, keep away from the appliance and immediately call your fire department. • DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH WATER. LUTD4919SN www.LGSIGNATURE.com Copyright © 2016 - 2023 LG Electronics Inc. All Rights Reserved. MFL68920507...

  • Page 2: Product Features

    PRODUCT FEATURES PRODUCT FEATURES Multiple Gas Burner Sizes Choose a burner to fit the size of your cookware. Cooking multiple items at once is possible by using different burners at the same time. Self Clean & EasyClean ® Useful for easy cleaning. Wok Grate Use the included wok grate to safely support a 12"...

  • Page 3: Table Of Contents

    Recommended Broiling Guide Warm IMPORTANT SAFETY Proof INSTRUCTIONS Meat Probe Remote Start PRODUCT OVERVIEW SMART FUNCTIONS Parts LG ThinQ Application Accessories FCC Notice FCC RF Radiation Exposure Statement INSTALLATION Smart Diagnosis™ Feature Installation Overview MAINTENANCE Product Specifications Before Installing the Range...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Read and follow all instructions when using the range to prevent the risk of fire, electric shock, personal injury, or damage. This guide does not cover all possible conditions that may occur. Always contact your service agent or manufacturer about problems that you do not understand.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS • Do not rest large, heavy items such as whole turkeys on the open oven door. The range could tip forward and cause injury. • Reengage the anti-tip device after pulling the range out for cleaning, service, or any other reason.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS SAFETY PRECAUTIONS Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide, formaldehyde and soot, caused primarily by the imperfect combustion of natural or LP gas. Correctly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize imperfect combustion.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS • To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above the surface units should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a range hood that projects horizontally a minimum of 5 inches beyond the bottom of the cabinets.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS ELECTRICAL SAFETY CAUTION Be certain that all packing materials are removed from the appliance before operating. Keep plastic, clothes, paper, and other flammable materials away from parts of the appliance that may become hot. • Always disconnect power from the appliance before servicing. •...
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS SURFACE BURNERS WARNING • Even if the top burner flame goes out, gas is still flowing to the burner until the knob is turned to the Off position. If you smell gas, immediately open a window and ventilate the area for five minutes prior to using the burner.
  • Page 10 10 IMPORTANT SAFETY INSTRUCTIONS CAUTION • To prevent burns, always be sure that the controls for all burners are in the Off position and all grates are cool before attempting to remove them. • If you smell gas, turn off the gas to the range and call a qualified service technician. Never use an open flame to locate a leak.
  • Page 11 IMPORTANT SAFETY INSTRUCTIONS • When disposing of the range, cut off the power cord and remove the door. • Do not make any attempt to operate the electric ignition oven during an electrical power failure. • Pull the oven rack to the stop-lock position when loading and unloading food from the oven.

  • Page 12: Product Overview

    Choke (1ea) Set screw (1ea) NOTE • Contact the LG SIGNATURE Customer Information Center at 1-800-984-6306 if any accessories are missing. • For your safety and for extended product life, only use authorized components. • The manufacturer is not responsible for product malfunction or accidents caused by the use of separately purchased, unauthorized components or parts.

  • Page 13: Installation

    Engage the anti-tip device Test run Product Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Oven Range Models LUTD4919SN Description Dual Fuel Double Oven Range Electrical requirements 6.9 kW 120/240 VAC or 5.2kW 120/208 VAC "...

  • Page 14: Before Installing The Range

    14 INSTALLATION Before Installing the Range If you did not receive an anti-tip bracket with your purchase, call 1-800-984-6306 to receive one at no charge. WARNING WARNING Tip - Over Hazard • The information in this manual should be A child or adult can tip the range and followed exactly.
  • Page 15 INSTALLATION Preparing for Installation Tools Needed Phillips screwdriver Flat-blade screwdriver " Nut driver Pliers Tape measure Level Open-end or Drill Safety glasses Gloves adjustable wrench Pipe wrench (2) (one for support) Parts Provided Parts not Provided Template (1) Anti-tip bracket kit (1) 4-Wire cord or Strain relief 3-Wire cord...

  • Page 16: Installing The Range

    16 INSTALLATION Installing the Range Choosing the Proper Location CAUTION Unpacking and Moving the Range • Avoid placing cabinets above the range. To CAUTION minimize the hazard caused by reaching over the open flames of operating burners, install a • You should use two or more people to move ventilation hood over the range that projects and install the range.
  • Page 17 INSTALLATION Dimensions and Clearances NOTE Save for the use of the local electrical inspector. 24" 3" (7.6 cm) (60.9 cm) 3" (7.6 cm) 25" Normal counter (63.5 cm) top depth Acceptable gas pipe and electrical Counter 36" outlet area top height (91.4 cm) Cabinet opening...

  • Page 18: Optional Rear Filler

    18 INSTALLATION Installing the Anti-tip Device Leveling the Range Level the range by adjusting the leveling legs with a WARNING wrench. Extending the legs slightly may also make it Tip - Over Hazard easier to insert the rear leg into the anti-tip bracket. A child or adult can tip the range and be killed.

  • Page 19: Providing Adequate Gas Supply

    INSTALLATION Connecting the Range to Gas Installing the Rear Filler Using a screwdriver, remove the upper four This appliance must be installed in accordance with screws that attach the rear bracket and loosen local codes or, in the absence of local codes, with the the lower two screws.

  • Page 20: Connecting Electricity

    20 INSTALLATION Flexible Connector Hookup WARNING • Allow 2 to 3 ft (61.0 cm to 91.4 cm) of slack in the line so that the range can be moved if servicing is ever necessary. • The power supply cord and plug should Pressure not be modified.
  • Page 21 INSTALLATION 3-Wire Connection : Power Cord Use the cord/conduit connection plate to install the power cord or conduit. Leave the connection plate WARNING as installed for power cord installations. Remove the connection plate for conduit installations and use the • The middle (neutral or ground) wire, which smaller 1 in.
  • Page 22 22 INSTALLATION 4-Wire Connection : Power Cord 3-Wire Connection: Conduit Install the conduit as follows: WARNING Remove the conduit connection plate from the rear of • Only a 4-conductor power-supply cord kit the oven and rotate it. The conduit hole (1 ") must rated 120/208 or 120/240 volts, 50 amperes be used.

  • Page 23: Engaging The Anti-Tip Device

    INSTALLATION Engaging the Anti-tip Device 4-Wire Connection: Conduit WARNING • Move the range close enough to the opening to plug into the receptacle. • The white middle (neutral) wire of the power cord or 4-wire conduit has to be connected •...

  • Page 24: Assembling The Surface Burners

    24 INSTALLATION Assembling the Surface Quality of Flames Burners The combustion quality of the burner flames needs to be confirmed visually. A Yellow flames - Call for service. CAUTION Do not operate the burners without all parts in B Yellow tips on outer cones - This place.

  • Page 25: Operation

    OPERATION OPERATION Control Panel Overview 1 Smart Diagnosis 6 - /+ Use during the Smart Diagnosis feature. Press the plus button to increase cooking time or oven temperature. 2 Cook Time / Clock Press the minus button to decrease cooking time or •...

  • Page 26: Changing Oven Settings

    26 OPERATION Changing Oven Settings Minimum & Maximum Default Settings Clock All of the features listed have a minimum and a The clock must be set to the correct time of day in maximum time or temperature setting that may be order for the automatic oven timing functions to work entered into the control.
  • Page 27 OPERATION Timer On/Off Settings The Lower Timer On/Off serves as an extra timer in Press and hold Start Time for three seconds. the kitchen that beeps when the set time has run out. Then press the Start Time key repeatedly to toggle It does not start or stop cooking.
  • Page 28 28 OPERATION Adjusting the Oven Temperature Adjusting the Beeper Volume Your new oven may cook differently from the one Press and hold Start Time for three seconds. it replaced. Use your new oven for a few weeks to Then press Start Time repeatedly until BEEP become more familiar with it before changing the appears in the display.
  • Page 29 OPERATION Start Time (Delayed Timed Cook) Cook Time (Timed Cook) The automatic timer of the Delayed Timed Cook Set the oven to cook for a specific length of time function turns the oven on and off at the time you using the Timed Cook feature.

  • Page 30: Using The Gas Surface Burners

    30 OPERATION Using the Gas Surface CAUTION Burners WHAT TO DO IF YOU SMELL GAS • Open windows. Before Use • Do not try to light any appliance. Read all instructions before using. • Do not touch any electrical switch. Make sure that all burners are properly placed.

  • Page 31: Burner Locations

    OPERATION Burner Locations Using the Gas Surface Burners Your gas range cooktop has four or five sealed gas Be sure that all of the surface burners and grates burners, depending on the model. These can be are placed in the correct positions. assembled and separated.

  • Page 32: In Case Of Power Failure

    32 OPERATION In Case of Power Failure Using a Wok In case of a power failure, you can light the gas 14-inch or smaller flat-bottomed woks can be used surface burners on your range with a match. directly on the grate. Make sure that the wok bottom sits flat on the grate.

  • Page 33: Using Stove-Top Grills

    OPERATION CAUTION CAUTION • Turn off all burners and allow wok grate, burner • Do not remove the center grate when using the grates, and cooktop to cool before installing or griddle. removing wok grate. • Do not remove the griddle plate until the •...

  • Page 34: Using The Oven

    34 OPERATION Using the Oven Replacing Racks Place the end of the rack on the support. Before Using the Oven Make sure rack is level and both sides are in the NOTE same rack position. • Because the oven temperature cycles, an oven Tilt the front end up and push the rack in.

  • Page 35: Convection Mode

    OPERATION Baking Tips Tips for Convection Baking • Baking time and temperature will vary depending • Use Convection Bake for faster and more even on the characteristics, size, and shape of the multiple-rack cooking of pastries, cookies, muffins, baking pan used. biscuits, and breads of all kinds.

  • Page 36: Recommended Baking And Roasting Guide

    36 OPERATION Recommended Baking and Roasting Baking rack guide Guide Rack position Food Baking results will be better if baking pans are Upper Lower centered in the oven as much as possible. If cooking Oven Oven on multiple racks, place the oven racks in the •...

  • Page 37: Broil

    OPERATION Broil Smoking Due to the intense heat associated with broiling, it The Broil function uses intense heat from the upper is normal to experience smoke during the cooking heating element to cook food. Broiling works best for process. This smoke is a natural byproduct of tender cuts of meat, fish, and thinly cut vegetables.

  • Page 38: Recommended Broiling Guide

    38 OPERATION Recommended Broiling Guide The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling times. This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan designed for broiling. Upper oven Lower oven Quantity and/or...

  • Page 39: Warm

    OPERATION Proof Tips for Broiling Beef This feature maintains a warm oven for rising yeast leavened products before baking. • Steaks and chops should always be allowed to rest for five minutes before being cut into and eaten. Setting the Proof Function This allows the heat to distribute evenly through the food and creates a more tender and juicy result.

  • Page 40: Remote Start

    40 OPERATION Setting the Meat Probe Function (example for Recommended Probe Temperature Chart Roast 375 °F with probe temp. 160 °F) Doneness Probe Temp. Select cook mode. Turn the oven mode knob to Beef, Lamb and Veal select Conv. Roast. Rare 130 °F (54 °C) Set the oven temperature: press plus(+) or...

  • Page 41: Smart Functions

    Turn on the Push Alerts to receive appliance status connection. notifications. • The surrounding wireless environment can The notifications are triggered even if the LG ThinQ make the wireless network service run slowly. application is off. • If the appliance is having trouble connecting...

  • Page 42: Fcc Notice

    Search for the LG ThinQ application from the Google off and on, the user is encouraged to try to correct Play Store or Apple App Store on a smartphone.

  • Page 43: Fcc Rf Radiation Exposure Statement

    This equipment complies with FCC radiation exposure diagnosis method. limits set forth for an uncontrolled environment. This • Launch the LG ThinQ application and select the transmitter must not be co-located or operating in Smart Diagnosis feature in the menu. Follow the conjunction with any other antenna or transmitter.

  • Page 44: Maintenance

    44 MAINTENANCE MAINTENANCE Cleaning Burner Heads/Caps For even and unhampered flame, the slits in the CAUTION burner heads must be kept clean at all times.The burner heads and caps (and the oval burner head • Do not clean this appliance with bleach. and cap assembly) can be lifted off.

  • Page 45: Burner Grates

    MAINTENANCE Burner Grates Cleaning the Cooktop Surface The range consists of three separate professional- CAUTION style grates. For maximum stability, these grates should only be used when in their proper position. • To avoid burns, do not clean the cooktop The two side grates can be interchanged from left surface until it has cooled.

  • Page 46: Front Manifold Panel And Knobs

    Compared to the more intense Self Clean process, your LG oven gives you the To replace the knobs, make sure that the knobs option of cleaning with LESS HEAT, LESS TIME, and have the position indicator centered at the top virtually NO SMOKE OR FUMES.
  • Page 47 MAINTENANCE When to Use EasyClean ® Suggested Types of Common Food Items Example of Oven Soiling Soil Pattern Cleaning Method Soils That Can Soil Your Oven Cheese Small drops or or other Pizza spots ingredients Steaks, broiled ® EasyClean Fish, broiled Light splatter Fat/grease Meat roasted at low...
  • Page 48 48 MAINTENANCE Spray or pour the remaining water (8 oz or 240 Once the oven cavity is cleaned, wipe any ml) onto the bottom center of the oven cavity. excess water with a clean dry towel. Replace The indentation on the oven bottom should be racks and any other accessories.

  • Page 49: Self Clean

    MAINTENANCE Self Clean NOTE • Remove oven racks and accessories before The Self Clean cycle uses extremely hot temperatures starting the Self Clean cycle. to clean the oven cavity. While running the Self Clean • If oven racks are left in the oven cavity during cycle, you may notice smoking or an odor.
  • Page 50 50 MAINTENANCE Setting Self Clean with a Delayed After the Self Clean Cycle Start • The oven door remains locked until the oven temperature has cooled. Remove all racks and accessories from the • You may notice some white ash in the oven. Wipe it oven.

  • Page 51: Changing The Oven Light

    MAINTENANCE Changing the Oven Light Cleaning the Exterior Painted and Decorative Trim The oven light is a standard 40-watt appliance bulb. It turns on when the oven door is open. When the oven For general cleaning, use a cloth with hot soapy door is closed, press and hold Start for three seconds water.
  • Page 52 52 MAINTENANCE Oven Door Broiler Pan and Grid • Use soapy water to thoroughly clean the oven door. Rinse well. Do not immerse the door in water. • You may use a glass cleaner on the outside glass of the oven door. Do not spray water or glass cleaner on the door vents.

  • Page 53: Removing And Replacing The Lift-Off Oven Doors

    MAINTENANCE Removing and Replacing the Lift the door up until it is clear of the hinges. Lift-Off Oven Doors about 30° CAUTION • Be careful when removing and lifting the door. • Do not lift the door by the handle. The door is very heavy.

  • Page 54: Door Care Instructions

    54 MAINTENANCE Lower Oven Replacing the Door Firmly grasp both sides of the door at the top. Removing the Door Fully open the door. With the door at the same angle as the removal position, seat the indentation of the hinge arms Unlock the hinge locks, rotating them as far into the bottom edge of the hinge slots.

  • Page 55: Troubleshooting

    Use a sheet pan lined with parchment • Only use flat-bottom woks or 12" to 14" round- paper under fruit pies or other acidic or sugary foods bottom woks when using a LG supplied wok grate. to prevent spillovers from damaging the oven finish. CAUTION...
  • Page 56 56 TROUBLESHOOTING My range is still dirty after running the Is it safe for my convection fan, broil burner or ® ® EasyClean cycle. What else should I do? heater element to get wet during EasyClean ® The EasyClean cycle only helps to loosen light soils Yes.

  • Page 57: Before Calling For Service

    TROUBLESHOOTING Before Calling for Service Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Symptoms Possible Causes / Solutions •...
  • Page 58 58 TROUBLESHOOTING Symptoms Possible Causes / Solutions • Make sure cord is plugged correctly into outlet. Check circuit breakers. Appliance does not • Service wiring is not complete. Contact your electrician for assistance. operate. • Power outage. Check house lights to be sure. Call your local electric company for service.
  • Page 59 TROUBLESHOOTING Symptoms Possible Causes / Solutions • A convection fan may automatically turn on and off. Fan noise - This is normal. • Convection fan stops during a convection bake cycle. Convection Fan stops - This is normal and is done to allow for more even heating during the cycle. This is not a failure of the range and should be considered normal operation.

  • Page 60: Limited Warranty

    PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Dual Fuel Range ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or replace the Product.
  • Page 61 • Increases in utility costs and additional utility expenses. • Any noises associated with normal operation. • Use of accessories, components, or consumable cleaning products that are not authorized by LG. • Replacement of light bulbs, filters, fuses or any other consumable parts.
  • Page 62 62 LIMITED WARRANTY Problem Cause Prevention • Burner cap color 1. Scratching • Do not use steel wool or change and lost shine abrasive cleansers to clean. 2. Use of detergent or abrasive cleansers • To remove burnt-on food, soak the burner heads in hot water for 20–30 minutes.
  • Page 63 LIMITED WARRANTY Problem Cause Prevention • Surface is not level 1. Range not leveled • Check with installer first • Oven is tipping 2. Anti-tip device not installed correctly Anti-tip bracket Wall plate Screw must Level both sides of range enter wood or concrete Approximately...
  • Page 64 If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
  • Page 65 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either: (i) sending an e-mail to...
  • Page 66 66 MEMO MEMO...
  • Page 67 Customer Information Center For inquires or comments, call: 1-800-984-6306 USA Printed in Korea...
