Fitting the whisk into the whisk gearbox
- Grasp the holder in one hand.
- With the other hand, take the first whisk and
insert the shaft A into the bore B of the whisk
gearbox drive shaft. Make sure the drive lugs D
are properly aligned with the notches.
- As you push the whisk into the holder drive shaft
C, rotate it slightly in order to slide the drive lugs
into the notches D of the drive shaft C, thereby
locking the whisk into place inside the shaft.
- To check that the whisk is properly fixed inside the
shaft C, gently pull the metal wires.
- Repeat this procedure with the second whisk. If
you cannot push it in properly, remove it, rotate it
90° and start again.
10
03/11/2022
Removing the whisk from the whisk gearbox
While griping the ejector
A in one hand and the
holder B in the other,
pull the ejector in the
direction of the arrow.
Removing the ejector
Hold the whisk by the
wires B Bin one hand.
With the other hand,
pull the ejector A in the
direction of the arrow
(see figure).

• MIXING TOOL FUNCTION

(MP 450 Turbo FW XL)
Attaching the mixing tool to the mixing tool
housing:
Line the flat side of the mixing tool B up with the flat
side of the housing A.
Once the mixing tool has been attached to the
housing, simply insert the latter into the motor unit,
turning it in an anticlockwise direction.
Detaching the mixing tool from its housing:
To release the mixing tool from its housing,
simply press the button C. All that then remains
to be done is to remove the housing from the
motor unit.
W A R N I N G
• Always unplug the Immersion Blender
before cleaning it!
• Always dilute bleach according to the
M
IXING TOOL
HOUSING
instructions on the label
M
IXING TOOL
• Never run the motor assembly through a
dish machine.
• The type and concentration of the sanitation
agent must comply with 21 CFR 178 1010
regulations.
• Clean according to local health department
regulations.
M
IXING TOOL
HOUSING
M
IXING TOOL

CLEANING
