- Page 1 ELECTROMAGNETIC FLOW METER AFLOWT MF Pro-×××M× Version “ ” INSTALLATION MANUAL ISO 9001:2015...
- Page 2 * * * Manufacturer quality management system is certified to ISO 9001:2015 * * * URL: http://www.aflowt.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................... 3 1. SAFETY INSTRUCTIONS .................. 5 2. MOUNTING PREPARATION ................5 3. MOUNTING ......................6 3.1. General Requirements ................6 3.2. Mounting the Flow Meter into the Pipeline ..........6 3.3. Wiring the Flow Meter ................12 4. - Page 4 AFLOWT MF electromagnetic flow meters, Pro-×××М× version, Pro-112MI, -122MI, -212MI, -222MI, -111MA,-121MA, -211MA, -221MA, -112MC, -122MC, -212MC, -222MC models. In the course of work, also refer to the "AFLOWT MF electromagnetic flow meter. Version Pro-×××М×. Operation manual" document. LIST OF ABBREVIATIONS...
-
Page 5: Safety Instructions
1. SAFETY INSTRUCTIONS 1.1. The flow meter should be mounted (dismounted) by technicians: - Certified for performing work of this type - Having the right to work with electrical installations up to 1000 V - Familiar with all the instructions outlined for the flow meter and auxiliary equipment used for mounting and dismounting. -
Page 6: Mounting
3. MOUNTING 3.1. General Requirements When mounting the MF on site, a free pipeline section should be provided. It is used to mount the flow meter and straight pipe runs of appropriate length upstream and downstream the flow pipe. Overall dimensions and weight of the MF are given in Appendix A of the Operation Manual. - Page 7 - Straight pipe runs with nominal diameter (DN) equal to nominal diameter of the MF should be provided upstream and downstream the MF. Length of the runs should not be less than specified in Table 1. The runs must not include devices or components that may disturb flow structure - When the MF is operated, the flow pipe inner channel should be fully filled with liquid...
- Page 8 Delivery package is agreed with the customer. Set of design documentation for the fitting assembly is available at customer's option. 3.2.3.2. Welding of assembly-welded structure components and connection of the components to the pipeline at flow meter location must be performed in compliance with applicable regulatory documents.
- Page 9 The other (free) end of the adaptor is threaded with straight pipe outer thread - Flow pipe dimension simulator of appropriate size and design (wafer type) - Gaskets - Fasteners. 3.2.4.2. The simulator overall mounting dimensions and DN correspond to the dimensions of the flow meter flow pipe to be mounted with this fitting assembly.
- Page 10 3.2.6. Mounting fitting assembly into the plastic (metal-plastic) pipeline. 3.2.6.1. Before mounting drain liquid from the pipeline and cut the pipeline where the flow meter will be installed. Fix the assembly to stationary supports by clamps where pipeline is cut considering the following condition: threaded holes M5 on cylindrical surface of the flanges used to connect wires to the MF case should be in position allowing easy connection of the wires.
- Page 11 CAUTION! Please make sure that gaskets are aligned relative to the flow pipe inner channel, i.e. a gasket must not even partly cover the inner channel. To provide gasket alignment, it is recommended to fix the gaskets by adhesive. The flow meter shall be mounted into the pipeline when all construction, welding and other works are finished.
-
Page 12: Wiring The Flow Meter
3.3. Wiring the Flow Meter 3.3.1. Power and communication cables are connected to the MF after it is installed into the pipeline. Cables are passed via corresponding MB through connections and connected to boards of processor and communication modules. Schematics of the input and outputs are given in Appendix B of the Operation Manual. - Page 13 To prevent measuring block from moisture ingress via through connections when using flat section cables it is necessary to connect cables so that falling U-loop is formed in the vertical plane (see Fig.5). a) horizontal b) sloping c) vertical Fig.5. Position of cables at the inlet of through connections when mounting MF into the pipeline 3.3.3.
-
Page 14: Dismounting
4. DISMOUNTING 4.1. The order of dismounting the flow meter before dispatching for regular calibration or repair is as follows: - Turn off power, then disconnect network and signal cables from the flow meter - Disconnect wires from the pipeline flanges - Cut off liquid at the FS location, make sure that pressure is released and drain the liquid - Dismount the flow meter and install the simulator... -
Page 15: Putting Into Operation
5. PUTTING INTO OPERATION 5.1. When putting the flow meter into operation check the following: - The flow is in the direction of the arrow on the flow meter case - Lengths of the inlet and outlet straight pipe runs of the MF are relevant to the flow reversibility - The flow meter and related equipment are connected in accordance with the selected wiring diagram... -
Page 16: Appendix А. Carbon Steel Structures For Mounting Flow Meters Into The Pipeline
APPENDIX А. Carbon steel structures for mounting flow meters into the pipeline Flow direction 1 — taper adaptor; 2 — straight pipe run; 3 — mating flange; 4 — MF (flow pipe dimension simulator); 5 — wires connecting MF case and pipeline. - Page 17 Table А.1 (continued) , DN Notes 1048 1088 1148 1078 1328 1328 1588 1288 1348 1278 1092 1368 1368 1788 1788 1797 1877 1797 1524 1957 1957 2557 * - reference dimensions without processing tolerances ** - adaptor is made of two concentric adaptors Note.
- Page 18 Flat weld flanges (for 2.5 MPa pressure) are used to mount the MF into the pipeline: - For DN10-DN20 — flanges of design type B (with a fixing ridge) - For DN25–DN150 — flanges of design type F (with a notch) Modification of flanges is needed before welding which means drilling a threaded hole M5 on the flange cylindrical surface to fix wires (Fig.A.2).
- Page 19 а) DN10, DN15 b) DN20 DN, mm d1, mm d2, mm d3, mm c, mm L, mm L1, mm 11,6 +0,5 10,5 Fig.А.3. View and dimensions of adaptor DN10-DN20...
- Page 20 Flange Wetted seam 3 ± 0.2 Transitive a branch pipe Fig.А.4. Flange DN10-DN20 and pipe adaptor welded together...
- Page 21 Flow direction 1 — taper adaptor; 2 — straight pipe run; 3 — gaskets; 4 — mating flange; 5 — flanged MF (flow pipe dimension simulator), 6 — wires connecting MF case and pipeline. Fig.А.5. Assembly-welded structure for mounting flow meters of Pro-×22М× versions (lined with fluoroplastic) with protection rings (flanged) into the pipeline Table А.2.
- Page 22 Table А.2 (continued) , DN Notes 1006 1096 1136 1196 1126 1376 1376 1636 1318 1378 1308 1121 1398 1398 1818 1818 1890 1970 1890 1614 2050 2050 2650 2426 2426 1050 2062 2506 2506 3106 3488 1565 3044 3488 4088 * —...
- Page 23 Flow direction 1 — adaptor with a flange; 2 — MF (flow pipe dimension simulator); 3 — wires connecting MF case and pipeline. Fig.А.6. Assembly structure for mounting flow meters of Pro-×12М× versions (wafer type) with protection rings into plastic (metal-plastic) pipe- line Table А.3.
- Page 24 rings does not provide electrical contact of the MFР case with the fluid being measured. In this case manufacturer doesn't guarantee stable operation of the flow meter. NOTE. When flow meters of Pro-×22М× versions with protection rings are mounted into the plastic (metal-plastic) pipeline, a grounding element ensures electrical contact with the fluid being measured.
-
Page 25: Appendix B. Holder To Fix Metal Sleeves For Power And Communication Cables
APPENDIX B. Holder to Fix Metal Sleeves for Power and Communication Cables * — reference dimension 1 — measuring block; 2 — holder; 3 — screws to fix holder on the flow meter measuring block; 4 — metal sleeve clamps; 5 — holes for metal sleeves.
