AFLOWT LV Series Installation Manual

Ultrasonic level gauge
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ULTRASONIC LEVEL GAUGE
AFLOWT LV
VERSION
LV-2xx
INSTALLATION MANUAL
9001:2008
Saint-Petersburg, Russia

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LV Series and is the answer not in the manual?

Questions and answers

Related Manuals for AFLOWT LV Series

Summary of Contents for AFLOWT LV Series

  • Page 1 ULTRASONIC LEVEL GAUGE AFLOWT LV VERSION LV-2xx INSTALLATION MANUAL 9001:2008 Saint-Petersburg, Russia...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page INTRODUCTION ..................... 3 1. SAFETY INSTRUCTIONS ................... 4 2. PREPARATION FOR MOUNTING ..............5 3. MOUNTING CONSIDERATIONS ................ 6 4. MOUNTING THE LEVEL GAUGE ............... 7 4.1. Types of acoustic systems ..............7 4.2. Mounting acoustic systems ..............7 4.3.

  • Page 3: Introduction

    The present manual covers the procedures for on-site mounting and dismounting of "AFLOWT LV" ultrasonic Level gauges of LV-2xx versions. In the course of work, also refer to "ULTRASONIC LEVEL GAUGE AFLOWT LV. LV-2xx version. Operation manual, Part I and Part II"...

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. The Level gauge should be mounted (dismounted) by the qualified technical staff: - Certified for performing work of this type on the site where the Level gauge is installed and authorized by the manufacturer - Authorized to work with electrical installations up to 1000 V - Familiar with all the instructions outlined for the Level gauge and auxiliary equipment used for mounting and dismounting.

  • Page 5: Preparation For Mounting

    2. PREPARATION FOR MOUNTING 2.1. To mount the Level gauge on site, the following areas should be available: - Free channel (tank, pipeline) section for mounting an acoustic system (AS) - Free space used to place structures providing protection of AS from precipitation, wind, and solar/heat radiation - Free area suitable for positioning BMD, SPS and CB (Communication Block).

  • Page 6: Mounting Considerations

    3. MOUNTING CONSIDERATIONS 3.1. Site requirements for mounting AS should be as follows: - Tank (channel, pipeline) operation conditions exclude foreign items on the surface of media interface within the area of measurements - Liquid turbulence and pulsations are absent or minimal - Foams on the surface of media interface are minimal - There are no structural components on the way of acoustic beam from PEP to the media interface...

  • Page 7: Mounting The Level Gauge

    4. MOUNTING THE LEVEL GAUGE 4.1. Types of acoustic systems 4.1.1. Simplistically designed AS-1xx-xx3 systems come without reference reflectors and sound guides. AS-11x-xx3 systems is equipped with disc mount ones (Fig.A.1). Mount disc both have holes for fixing an acoustic system to the object under control.

  • Page 8: Mounting Modules

    4.2.4. AS-40x-xx0 and AS-6xx-xx0 systems are mounted as shown in figures B.2-B.4. Several mounting methods are available: - Mounting AS on a frame installed on the object under control (Fig.B.2). AS mount flange is fixed to the frame by bolts. Deflection of the base plane of the mount flange from the horizontal plane is checked with a builder's level in two mutually perpendicular directions.
  • Page 9 a minimum from other cables. It is recommended not to coil the excessive cables. CAUTION! YOU MUST NOT change the length of BMD-CB and CB-PEP cables. To avoid mechanical damages, it is recommended to place all cables in metal or plastic tubes, corrugated sleeves, and cable trays, trunks, or conduits.

  • Page 10: Start-Up Procedures

    5. START-UP PROCEDURES 5.1. Initial configuration 5.1.1. Prior to work, it is necessary to check that the Level gauge's operation settings specified in the Equipment Certificate or Check Form correspond to the ones in the Device's internal memory as well as to check its configuration settings.

  • Page 11: Configuring The Level Gauge Installed On The Object Under Control

    5.2.1. Configuration procedure is performed after determining all initial settings and completing all mount procedures. The Level gauge is configured from the keyboard, which is operated as described in "ULTRASONIC LEVEL GAUGE AFLOWT LV. LV-2xx version. The operation manual,...
  • Page 12 Part II" document. Also, the Level gauge can be configured from a PC with use of "Monitor AFLOWT LV-2xx" software. 5.2.2. The Level gauge is switched to SERVICE mode, and then powered on. Setting/ Configuration menu is opened and the following parameters are set for each channel: - Calc.

  • Page 13: Special-Purpose Configuration

    is necessary to check that the signals reflected from the media interface and reference reflector (for AS with reference reflector) are displayed. If the Device is configured correctly, the measured distance is equal to the actual distance, and positions of the selection marker and the desired echo-signal match on the display.
  • Page 14 5.3.3. Prior to configuration, measurement base B (section 5.1.2) is determined along with an actual value of liquid level in the tank Н The measurements are performed with other measuring tools (e.g., measuring needle, measuring rod etc). At the same time, the actual level value is measured by the Level gauge, and the following readings are taken from the Device's display: distance D′, ultrasound velocity C′, and gas medium temperature t′.

  • Page 15: Dismounting

    6. DISMOUNTING To dismount the Level gauge before dispatching for regular calibration or repair, it is necessary to: - Turn power off the Device - Unscrew 6 screws fixing the Measurement Subblock to the Mount Module from the front panel side - Disconnect signal cables connecting BMD with external devices from the terminal blocks - Screw 6 screws fixing the Measurement Subblock to the Mount Module...

  • Page 16: Appendix A. Acoustic Systems

    APPENDIX A. Acoustic systems Base plane of readout 170 * 170* * - reference dimension 1 – Mount rail; 2 – PEP; 3 – sensitive element RTD Fig. A.1. AS-11x-xx3 acoustic system...
  • Page 17 * - reference dimension 1 – AS mount flange; 2 – PEP; 3 – sound guide; 4 – holder of reference reflector; 5 – reference reflector Fig. A.2. AS-40x-xx0 Acoustic system...
  • Page 18 * - reference dimension 1 – ring bolt; 2 – PEP; 3 – sound guide; 4 – holder of reference reflector; 5 – reference reflector Fig. A.3. AS-50x-xx0 Acoustic system...
  • Page 19 * - reference dimension 1 – RTD; 2 – mount flange; 3 – PEP Fig. A.4. 61x-xx0 Acoustic system...
  • Page 20 * - reference dimension 1 – ring bolt; 2 – RTD; 3 – PEP; 4 – sound guide; 5 – counterbalance Fig. A.5. AS-71x-xx0 Acoustic system...
  • Page 21 Fig. A.6. Mount Adaptor...
  • Page 22 Fig. A.7. Flange with the ring bolt installed...
  • Page 23 Fig. A.8. Pipe mount adaptor...
  • Page 24 Fig. A.9. Perforated adaptor pipe...

  • Page 25: Appendix B. Methods For Mounting Acoustic Systems

    APPENDIX B. Methods for mounting acoustic systems Fig. B.1. Mounting AS-11x-xx3...
  • Page 26 1 – AS mount flange; 2 – sound guide; 3 – reference reflector holder; 4 – reference reflector; 5 – frame Fig. B.2. Mounting AS-40x-xx0 on a frame...
  • Page 27 a) AS-62x-xx0 b) AS-40x-xx0 * - reference dimension 1 – AS mount flange; 2 – mount adaptor; 3 – sound guide; 4 – RTD1; 5 – RTD2; 6 – reference reflector holder; 7 – reference reflector Fig. B.3. Rigid mounting of AS using Mount Adaptor...
  • Page 28 a) AS-61x-xx0, 62-x-xx0 b) AS-40x-xx0 1 – RTD1; 2 – RTD2; 3 – AS mount flange; 4 – adaptor pipe; 5 - mount adaptor; 6 – sound guide; 7 – reference reflector holder; 8 – reference reflector Fig. B.4. Rigid mounting of AS using Mount Adaptor and adaptor pipes...
  • Page 29 a) AS-72x-xx0 b) AS-50x-xx0 * - reference dimension 1 – RTD1; 2 – RTD2; 3 – structural component; 4 – ring bolt; 5 – sound guide; 6 – reference reflector holder; 7 – reference reflector Fig. B.5. "Flexible mount", AS suspended from a structural component of the object under control...
  • Page 30 * - reference dimension 1 – RTD1; 2 – RTD2; 3 – flange with ring bolt; 4 – mount adaptor; 5 – sound guide; 6 – reference reflector holder; 7 – reference reflector Fig. B.6. "Flexible mount", AS suspended from a flange on a ring bolt...

  • Page 31: Appendix C. Wiring Diagrams

    APPENDIX C. Wiring diagrams Fig. C.1. Diagram for connection of AS-62X-XX0, -72X-XX0 acoustic systems (fore 2 RTD) to the one-channel BMD...
  • Page 32 NOTE. If RTD2 is not installed, LEAD2A and LEAD2B contacts must be closed by a jumper. Fig. C.2. Diagram for connection of AS-61X-XX0, -71X-XX0 acoustic systems (fore 1 RTD) to the one-channel BMD...
  • Page 33 Fig. C.3. Diagram for connection of AS-61X-XX0, -71X-XX0 acoustic systems and AS-62X-XX0, -72X-XX0 acoustic systems to the two-channel...
  • Page 34 =24V Secondary Power DIGITAL MEASURING BLOCK (BMD) Source AFLOWT LV ULTRASONIC LEVEL GAUGE ~ 220V 50 Hz S/N 000001 24DC COMMUNICATION COMMUNICATION BLOCK BLOCK TCR (at use of AS with the resistance thermo converter) Acoustic system Fig. C.4. Diagram for connection of two-channel Level gauge...

  • Page 35: Appendix D. Report On Mounting And Start-Up Procedures

    APPENDIX D. Report on mounting and start-up procedures (Recommended) REPORT on mounting and start-up procedures for "AFLOWT LV" Level gauge Serial No_______ (page___ of____) UL-2 version_____Channel No______ BMD____ Serial No ____________ AS type________ Serial No_______, PEP type_____ Serial No ________, RTD1 type _______________Serial No __________, Add.
  • Page 36 5. HV-function of the tank Table D.1 No of the point Level, m Volume,m No of the point Level, m Volume,m No of the point Level, m Volume,m No of the point Level, m Volume,m 6. Notes _____________________________________________ __________________________________________________________ Representative of start-up organization ____________________ / ______________________ / Signature name and initials...

  • Page 37: Appendix E. Adjustment Profiles

    APPENDIX E. Adjustment profiles Tables E.1-E.4 contain standard values of the parameters included in the factory-installed adjustment profiles. Table E.1. Profile1 (for AS-40X-XX0, AS-50X-XX0) Type of Number of ultrasound Dead Correlation cycles in a Search Parameter velocity zone, m threshold sounding criterion correction*...

  • Page 38: Appendix F. Velocity Of Ultrasound For Pure Gases

    APPENDIX F. Velocity of ultrasound for pure gases Velocity of ultrasound in pure gases at 0 °C Table F1 Name of the gas Ultrasound velocity C , m/s Nitrogen Nitrogen monoxide (laughing gas) Nitrogen dioxide 324 * Ammonia Argon Dry air Hydrogen 1284 Hydrogen bromide...
