  • Page 1 TECHNOLOGICAL MAGNETIC FLOW METER AFLOWT MFT INSTALLATION MANUAL ISO 9001:2015...

  • Page 2: Table Of Contents

    CONTENTS Page INTRODUCTION ..................... 3 1. SAFETY INSTRUCTIONS ................... 4 2. PREPARATION FOR MOUNTING ..............4 3. MOUNTING……....................5 3.1. General Requirements ................5 3.2. Mounting the flowmeter in the pipeline ........... 5 3.3. Mounting the secondary converter of the flowmeter remote version ..9 3.4.

  • Page 3: Introduction

    4. When welding is performed, DO NOT use the flowmeter with PFC installed. Install the PFC dimension simulator provided in the delivery package. 5. MFT mounted in the pipeline SHOULD NOT be rotated around the pipeline axis. 6. When mounting and using MFT, DO NOT remove protection rings from PFC.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. The flowmeter should be mounted (dismounted) by the qualified technical staff: - Certified for performing work of this type on the site where the flowmeter is installed and authorized by the manufacturer - Authorized to work with electrical installations up to 1000 V - Familiar with the instructions for the flowmeter and the auxiliary equipment used for mounting and dismounting.

  • Page 5: Mounting

    - The flowmeter should be mounted in the part of a pipeline where liquid turbulence and pulsations are minimal. Fig.1. Recommended MFT locations - Straight pipe runs with nominal diameter (DN) equal to nominal diameter of the flowmeter and length of no less than specified in table 1 should be provided upstream and downstream the flowmeter.
  • Page 6 Maximum deflection is ± 30 ° - Intensity of external magnetic field (commercial frequency) should not exceed 400 A/m. Table 1. Lengths of straight runs for various MFT design versions Unidirectional flow Bidirectional flow upstream MFT...
  • Page 7 Fig.2 Fig.3 CAUTION! Overlaps and undercuts inside the channel are unacceptable. After completing the work, remove burrs and scales from the inside. c) Assemble the whole structure using bolts (studs) to fix components. Please make sure that the simulator is installed instead of PFC to provide alignment between two welded units, flatness/parallel alignment of the flanges, and to avoid damages to the flowmeter in the course of welding the structure to the pipeline.
  • Page 8 When mounting the flowmeter, put new gaskets provided in the delivery package into the companion flanges.  When mounting flanged type flowmeters into the pipeline, bolt PFC/pipeline mating flanges from the side of the pipeline flanges. Length of the bolts must provide the minimal distance of 3 mm from a bolt end to the flowmeter’s assembly.

  • Page 9: Mounting The Secondary Converter Of The Flowmeter Remote Version

    The flowmeter mounted in the pipeline SHOULD NOT be rotated around the pipeline axis. 3.2.7. Mounting the flowmeter with threaded coupling 3.2.7.1. Select the flowmeter’s pipeline mounting location observing the rules specified in Table 1. Cut the pipeline drained of liquid following the instructions given in section 3.2.6.

  • Page 10: Wiring The Flowmeter

    protrusion as shown in Fig.C.4, after which the top plate is secured with screws. 3.4. Wiring the Flowmeter 3.4.1. Power and communication cables are connected to the flowmeter after it is installed into the pipeline. Prior to connection, cut isolation from cable ends by 5 mm and after that, connect them to the terminals on the switching module.

  • Page 11: Dismounting

    DO NOT fix cables to the heated pipeline. 3.4.7. To provide electrical connection, it is necessary to connect the pipeline sections cut in the wafer type MFT mounting location by wires (jumpers) via a terminal located on the BE; wires should be of 4 mm cross section as a minimum (see Appendix A).

  • Page 12: Putting Into Operation

    Immediately after PFC is dismounted from the pipeline, install the clamping plates with the tightening stud (bolt) on PFC covered by fluoroplastic with the protection rings removed - Install the simulator in the pipeline instead of PFC. 4.2. On installing the simulator, check mating surfaces for leakage. Replace gaskets, if necessary.

  • Page 13: Appendix A. Mounting Wafer Type Flowmeters Into The Pipeline

    APPENDIX A. Mounting wafer type Flowmeters into the pipeline Flow direction 1 – taper adaptor; 2 – adaptor pipe; 3 – mating flange; 4 – MFT (PFC dimension simulator); 5 – wires (electrical jumpers) connecting the flowmeter’s case and pipeline Fig.A.1.
  • Page 14 1 – revision to F; 2 – threaded hole М5 Fig.A.2. Modifications made for flanges for mounting MFT's of wafer type When welding flanges shown in Fig.A.2 to the pipeline, adaptor pipes shall be used (see Fig.A.3). The length of the adaptor pipes should be no less than the length of the straight pipeline run (see Table 1 of this manual).
  • Page 15 Fig.A.3. Adaptor pipes Table A.3. Adaptor pipeline dimensions DN, mm d1, mm d2, mm d3, mm c, mm L, mm L1, mm 11.6 +0,5 Fig.A.4. Welding flanges to adaptor pipes...

  • Page 16: Appendix B. Mounting Flowmeters Of Flanged Type Into The Pipeline

    Flow direction 1 – taper adaptor; 2 – straight pipe run; 3 – rubberized asbestos fabric gaskets; 4 – mating pipeline flange; 5 – PFC flange; 6 – MFT (PFC dimension simulator) 7- wires connecting flowmeter’s flanges to the pipeline Fig.B.1.
  • Page 17 Cont. of Table B.1 1074 1066 1114 1106 1174 1166 1104 1096 1354 1346 1324 1316 1614 1606 1324 1316 1384 1376 1314 1306 1124 1116 1404 1396 1404 1396 1824 1816 1824 1816 1844 1836 1924 1916 1844 1836 1564 1556 2004...
  • Page 18 * - reference dimensions without processing tolerances ** - adaptor is made from two concentric adaptors Flat welded (slip-on) flanges supplied with the set of fittings should be modified as follows: a threaded M5 hole is drilled for fixing a wire on the cylindrical surface of a flange.

  • Page 19: Appendix C. Mounting Secondary Converter

    APPENDIX C. Mounting Secondary converter Fig.C1. Wall bracket. Fig.C2. Top plate Fig.C3. Detachable coupling...
  • Page 20 Fig.C4. The secondary converter is mounted on the bracket...

  • Page 21: Appendix D. Signal Cables Pfc-Sc

    APPENDIX D. Signal cables PFC-SC Fig.D.1 Wiring diagram of the flow meter signal cables in the remote version im_mft_eng.doc1.4...
