- Page 1 ULTRASONIC FLOW METER AFLOWT UF (with cut-in converters) VERSION UF-5xx d INSTALLATION MANUAL ISO 9001:2015...
-
Page 2: Table Of Contents
CONTENTS Page INTRODUCTION ..................... 3 1. SAFETY INSTRUCTIONS ................... 4 2. MOUNTING PREPARATION ................4 3. MOUNTING REQUIREMENTS ................5 3.1. Requirements for Mounting the Primary converter ........5 3.1.1. General Requirements................5 3.1.2. Placing the PEA pair for single-beam sounding ........5 3.1.3. -
Page 3: Introduction
The present manual covers procedures for on-site mounting and dismounting of AFLOWT UF ultrasonic flowmeters of UF-510 d, -520 d, -522 d, -530 d, -540 d, -542 d, -544 d models. In the course of work, al- so refer to manuals "ULTRASONIC FLOW METER AFLOWT UF (with cut-in converters). -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS 1.1. The flowmeter should be mounted (dismounted) by the qualified tech- nical staff: - Certified for performing work of this type on the site where the flowmeter is installed and authorized by the manufacturer - Authorized to work with electrical installations up to 1000 V - Upon reading all the instructions for the flowmeter and the auxiliary equipment used for mounting and dismounting. -
Page 5: Mounting Requirements
3. MOUNTING REQUIREMENTS 3.1. Requirements for Mounting the Primary converter 3.1.1. General Requirements. 3.1.1.1. The following requirements should be observed on-site of CP mounting: - Liquid pressure in the pipeline and operation conditions must not be of values that may facilitate gas (air) release and/or accumulation - When the flowmeter is operated, the pipeline should be fully filled with liquid - Flow turbulence and pulsations are minimal. -
Page 6: Placing The Pea Pair For Two-Beam Sounding
3.1.3. Placing the PEA pair for two-beam sounding In case of two-beam scanning, the wetted PEAs should be mount- ed on the CP along two chords. The CP should be mounted so that the chords are directed horizontally (Fig.3). PEA1.1-PEA1.2 pair – 1st beam PEA2.1-PEA2.2 pair –... -
Page 7: Length Requirements For Straight Pipe Runs
3.2. Length requirements for straight pipe runs 3.2.1. For proper flowmeter’s operation, before the first and the last PEA with respect to the flow direction, there should be straight pipe runs of corre- sponding length with the DN equal to the DN of the CP. The “type” in- stallation minimum values of relative length of the straight pipe runs for various PEA installation configurations and types of hydraulic resistance are shown in Table A.1 of Appendix A... -
Page 8: Mounting The Flowmeter
4. MOUNTING THE FLOWMETER 4.1. Mounting the Primary Converter 4.1.1. In order to install the CP into the pipeline the following fittings are to be delivered: companion flanges, pipe adaptors, taper adaptors (if the DN of the primary converter is less than the DN of the pipeline intended for mounting the CP). -
Page 9: Wiring The Flowmeter
4.3. Wiring the Flowmeter 4.3.1. When connecting PEAs to the CS, it is necessary to provide that the el- ements of the measuring channel (PEAs and communications cables) be in correspondence with the characteristics of the channel. PEA serial numbers with the measurement channel indicated are specified in the flowmeter’s Passport. - Page 10 4.3.8. The need for protective grounding is determined by power supply and environment conditions under which the flow meter is operated. The protective grounding and earthing device should correspond to the rules on design of power electric installations. Do not use the light- ning protection system for grounding since in could result in device's failure.
-
Page 11: Start-Up Procedure
5. START-UP PROCEDURE 5.1. Before start-up you should check that flowmeter’s operation parameters specified in the Passport correspond to data entered in the flowmeter memory. 5.2. Parameters of PEA are entered according to the Operation Manual, Sections 2.1 Part II. 5.3. -
Page 12: Dismounting
6. DISMOUNTING 6.1. To dismount the flowmeter, do the following: - Switch off the flowmeter - Before dismounting the CP, cut off liquid flow in the pipeline section where they are located, ensure there is no pressure in the pipeline and drain the liquid - Disconnect cables leading to the CS (PEAs) - Dismount the CP and CS. -
Page 13: Appendix A. Relative Length Of Straight Pipe Runs
APPENDIX A. Relative length of straight pipe runs Table A.1 shows minimum values of relative length of pipeline straight runs for type installation, different scheme of sounding depend- ing on local hydraulic resistance types. Table A.1 Relative length of a straight run, N, minimum Type of local hydraulic single-beam "diame- two-beam "chord"... - Page 14 Table A.1 (cont'd) Control valve Control valve Not fully-open ball valve Pump Pump DN1 / DN DN1 / DN In case of various types of hydraulic resistance in the pipeline, the length of a pipeline straight run related to the resistance nearest to the PEAs should be no less than the value specified in the table, and the distance from the PEAs to the other hydraulic resistances should be no less than the value specified in the table for hydraulic resistance of this...
-
Page 15: Appendix B. Report On Mounting And Start-Up Procedure
(recommended) REPORT on mounting and start-up procedure for AFLOWT UF flowmeter, serial No. ________(sheet __ of ____) UF-5__ d design version, channel No. _____ Beam 1 – PEA1.1 No. ______ / PEA1.2 No. _______ ; Beam 2 – PEA2.1 No. ______ / PEA2.2 No. _______ ;... - Page 16 5. Measurement channel parameters 5.1. Zero offset, dT = _________ ms 5.2. Additional delay, P = _________ ms Note: _________________________________________________________________ _________________________________________________________________ Representative of start-up organization ____________________ / ______________________ / Signature name and initials " ___ " ______________ 20__ Customer representative ____________________ / ______________________ / Signature name and initials...
-
Page 17: Appendix C. Kinematic Viscosity Ratio Of Water
APPENDIX C. Kinematic viscosity ratio of water Table C.1 t, C t, C t, C t, C t, C ·10 ·10 ·10 ·10 ·10 0.00 1.7905 35.00 0.7247 70.00 0.4137 105.0 0.2807 140.0 0.2125 1.00 1.7307 36.00 0.7107... -
Page 18: Appendix D. Straightening Vane Design
APPENDIX D. Straightening vane design 1. Fig.D.1 shows the design of type A straightening vane that is manufac- tured according to the following rules: a) straightening vane plate thickness is equal to the diameter of the holes; depending on material, the plate can be made of one or several sheets b) all the diameters of the holes in the plate are equal c) holes are spread more thickly in the center of the plate, and more rare-... - Page 19 Fig.D.2. Design of type B flow straightening vane. 3. Hole marking in straightening vanes is shown in Table D.1. Table D.1. Coordinates of the holes in straightening vanes of A and B type (D – pipeline internal diameter) Item X axis Y axis 0.142D 0.283D...
