Pathway Light Installation

1
Installing the stake
□ Push the ground stake (CC) into the ground. Using rubber mallet, insert ground stake (CC) deep enough into the
ground to ensure fully assembled pathway light (AA) is stable and does not tip over.
CC
2
Installing the Pathway Light
□ Align the pathway light (AA) with the slot on the 12 in. pole (BB). Slide the pathway light
(AA) downward then turn clockwise.
□ Align the ground stake (CC) slot with the rivet indicator on the pathway light.
Slide the pathway light (AA) base downward and then turn clockwise.
IMPORTANT: Do not push on the pathway
light (AA) or you may damage the device.
3
Removing the insulating tab
□ The light will not operate without pulling out the insulating tab.

Operation without Remote

This OneSync fixture works on its own or with remote/smart bridge for grouping and expanded control.
1
Turning on the fixture
□ Turn the on the pathway light (AA) by pressing the button located on the base, below the light.
2
Selecting a Color
□ To cycle through the colors, push the button.
□ Colors are: Soft White, Bright White, Cool White, Daylight, Deluxe Daylight,
Red, Blue, Green, Yellow, Orange, Purple, Teal, and Pink.
□ The pathway light will remember the color setting when next turned on.
IMPORTANT: Light brightness is determined by the charge
level of the batteries. Brightness will decrease during operation
to extend battery life
NOTE: When installing product in hard or dry
soil, water the soil several hours beforehand to
make the installation easier. You can also
break up the ground lightly with a stake or a
fork. Don't force stake into the ground as
excess force can break or bend the stake.
5
AA
BB
CC
Button
